Summary of Contents for KBA PolyExpo III Combi
- Page 1 Pre-installation Guide PolyExpo III Combi IMPORTANT Please follow the instructions in this guide when preparing the installation site prior to arrival and installation of the equipment. June 19th, 2018 Edition BA, Part No 10078782 English (en-us) Original version...
- Page 2 ( Blank ) Pre-installation Guide PolyExpo III Combi June, 2018...
-
Page 3: About This Manual
About this manual About this manual This manual applies to the combined unit PolyExpo III Combi. This manual is published by: Glunz & Jensen A/S Lindholm Havnevej 29 5800 Nyborg Denmark Phone: +45 57 68 81 81 E-mail: gjhq@glunz-jensen.com Internet: www.glunz-jensen.com Copyright ©... -
Page 4: Table Of Contents
Heating and ventilation Installation kit Space requirements Free space around the equipment Dimensions and connections Exhaust connection Electrical requirements Main power outlet Power cable Electrical specifications Power supply requirements Power consumption PolyExpo Checklist Pre-installation Guide PolyExpo III Combi June, 2018... -
Page 5: Introduction
The operator must observe and/or act according to the information in order to CAUTION avoid any mechanical or electrical damage to the equipment. The operator must observe and/or act according to the information in order to WARNING avoid any personal injury. June, 2018 Pre-installation Guide PolyExpo III Combi... - Page 6 Pre-installation Guide PolyExpo III Combi June, 2018...
-
Page 7: Transportation
The crate Crate Dimensions PolyExpo III Combi Length (L) 1708 mm (67.2") Width (W) 1970 mm (77.6") Height (H) 1368 mm (53.9") June, 2018 Pre-installation Guide PolyExpo III Combi... -
Page 8: Weight
Report any damage of the crate to the shipping company and notify the insurance agent, if appropriate, before the mishandled package is opened. Handling the crate The icons on the crate indicate how to handle the crate during transport and storage: Pre-installation Guide PolyExpo III Combi June, 2018... -
Page 9: Lifting The Crate
The Service Technician has to unpack the equipment. (69.7") CAUTION: May require machine moving skates suitable for transport of very heavy equipment. more than Please refer to "Weight" on the previous page. 1620 mm (63.8") June, 2018 Pre-installation Guide PolyExpo III Combi... - Page 10 Pre-installation Guide PolyExpo III Combi June, 2018...
-
Page 11: Installation Requirements
17°C (63°F) and a relative humidity (non condensing) of min. 20 % and max. 80%. For heat emission see "Power consumption" on page 16. Installation kit Installation kit is included with the equipment. It comprise the parts necessary to make the installation. June, 2018 Pre-installation Guide PolyExpo III Combi... -
Page 12: Space Requirements
Decide for a proper installation site for the equipment and make sure that the free space around the equipment makes servicing possible. The recommended minimum free space around the equipment is specified in the next illustration. Pre-installation Guide PolyExpo III Combi June, 2018... -
Page 13: Dimensions And Connections
Installation requirements 3-13 Dimensions and connections June, 2018 Pre-installation Guide PolyExpo III Combi... -
Page 14: Exhaust Connection
Make sure that the airflow is correct and minimum exhaust capacity is according to the Exhaust specification table. III Combi Dryer, min. 100 m³/h (59 ft³/min) Exposure, min. blowing directly to the room Light finisher, min. 800 m³/h (470 ft³/min) Pre-installation Guide PolyExpo III Combi June, 2018... -
Page 15: Electrical Requirements
Please be aware of double pole/neutral fusing. CAUTION: The conductors in the power supply cable should be of copper. Provide for additional cable protection, e.g. cable covers, if cable is exposed to heavier transport such as fork-lift trucks etc. June, 2018 Pre-installation Guide PolyExpo III Combi... -
Page 16: Electrical Specifications
WARNING: Please be aware of double pole/neutral fusing. CAUTION: The fuses must have a breaking capacity of min. 100 kA. Power consumption PolyExpo III Combi In operate by 230 VAC 9500 W (32415 BTU) (±10%) per phase, max. Pre-installation Guide PolyExpo III Combi June, 2018... -
Page 17: Checklist
Are there any known problems in the building where the equipment will be installed? If YES, please describe which: Connections Is air condition/ventilation available according to the requirements as described in chapter "Exhaust connection" on page 14.? June, 2018 Pre-installation Guide PolyExpo III Combi...
