Milkcan Geneva 258 Instructions

O U T D O O R D E S I G N S
Geneva Parcel Letterbox
Contents
Your carton should contain the following parts:
1 x Front Panel
1 x Back Box (Upper + Lower)
1 x Mounting Bracket (attached to the inside of the letterbox)
1 x Accessories Bag
Choosing a Suitable Location
The letterbox can be either mounted into a timber fence, or built into
a brick or block wall. You will need to install it in a location that is
easily accessible to Australia Post and couriers. The recommended
height for the mail slot is 90 to 120cm from the ground.
Timber Fence Installation
Tools Required
- Drill + Timber Drill Bit - Pencil
- Tape Measure - Spirit Level
- Jigsaw
1. Open the parcel door. Detach the front panel from the upper
box by unscrewing the 4 bolts pictured below.
2. Detach the lower box from
the upper box by
unscrewing the 6 external
bolts using the allen key
supplied.
Open the parcel door, then
open the rear door and
unscrew the last 2 internal
bolts.
Front
Panel
Mounting Bracket
(fence installation only)
This step requires 2 people
3. 1st person - Press the upper
box against the fence. Use a
spirit level to ensure the box
is level.
2nd person - Mark the fence
around the box perimeter.
Safety Tip
Ensure you wear safety
goggles before proceeding
with the next step
4. Using a jigsaw, cut along the
fence marking.
5. Gently push the upper box
through the fence cutout as
far in as possible.
Mark where to cut out the
notches in the fence.
Remove the upper box and
using a jigsaw, cut out the
marked locations.
Rear View
Upper
Box
Parcel
Door
Lower
Box
