Summary of Contents for d&b audiotechnik DN1
- Page 1 Manual 1.2 en...
- Page 2 All previous versions of this document are hereby no longer valid. Version 1.2: Most current feature set. General information DN1 Manual Version: 1.2 en, 05/2024, D2759.EN .01 Copyright © 2024 by d&b audiotechnik GmbH & Co. KG; all rights reserved.
- Page 3 10. Lay all cables connected to the unit carefully so that they cannot be crushed by vehicles or other equipment and that no one can either step on them or trip over them. d&b DN1 Manual 1.2 en...
-
Page 4: Table Of Contents
4.4.2 Operating mode selection............ 11 4.4.3 LED indicators................ 12 4.5 Rear panel................12 Rack wiring diagrams............. 13 Manufacturer's declarations......... 14 6.1 Declaration of conformity............14 6.2 WEEE Declaration (Disposal)..........14 6.3 Licenses & credits..............14 d&b DN1 Manual 1.2 en... -
Page 5: Dn1 Ethernet Switch
DN1 Ethernet switch DN1 Ethernet switch 1.1 Intended use The d&b DN1 is an AVB-enabled 11 port Ethernet switch (3 x ® etherCON /8 x RJ 45). It is mainly intended for use in the d&b Touring rack assemblies and can be configured using the d&b R1 Remote control software. -
Page 6: Scope Of Supply
NEMA 5-15P KS C8305 AS 3112 Z2612.060 Z2612.070 Z2612.100 Z2612.110 Z2612.120 Z2612.130 3-pin China 3-pin Swiss 3-pin South Africa 3-pin Argentina 3-pin Brazil 3-pin India GB 2099 SEV1011/T23 SANS 164-1 IRAM 2073 NBR 14136 IS 1293 d&b DN1 Manual 1.2 en... - Page 7 However, keep the removed inserts in a safe place as they must be reinserted and fixed again to restore the delivery state when separating the devices for any other intended purpose. d&b DN1 Manual 1.2 en...
-
Page 8: Technical Specifications
PRI / SEC LED indicator Magenta / Cyan Dimensions and weight Height x width x depth 1 RU x 241 mm x 145 mm 1 RU x 9.5" x 5.7" Weight 1.4 kg / 3.1 lb d&b DN1 Manual 1.2 en... -
Page 9: Startup
Used when mounted underneath a mobile amplifier the 19" adapter for installation racks. a mobile amplifier and in combination with the 19" in combination with the 19" adapter for mobile adapter for mobile touring racks. touring racks. d&b DN1 Manual 1.2 en... -
Page 10: Mains Connection
A mains connector socket [1] is fitted on the rear panel and an appropriate power cord [1.1] is supplied. d&b DN1 Manual 1.2 en... -
Page 11: Front Panel
If the device is operated within an AVB network, you must configure all switches for use in a primary or secondary network. The DN1 recognizes a primary or secondary connection of the connected AVB device and indicates an error if a primary port has been connected to a secondary switch and vice versa. -
Page 12: Led Indicators
LED flashing Data traffic PoE Error 4.5 Rear panel ETH 1 - ETH 8 For the internal rack wiring, 8 x RJ 45 ports are provided at the rear of the device. d&b DN1 Manual 1.2 en... -
Page 13: Rack Wiring Diagrams
Rack wiring diagrams Rack wiring diagrams d&b DN1 Manual 1.2 en... -
Page 14: Manufacturer's Declarations
Manufacturer's declarations 6.1 Declaration of conformity This declaration applies to: d&b Z4001 DN1 AVB network switch by d&b audiotechnik GmbH & Co. KG. All product variants are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications. - Page 16 www.dbaudio.com...
