Bitspower BPM-MBCR140 Manual

Mount bracket for cr reservoir

Advertisement

Quick Links

BPM-MBCR140
Bitspower Mount Bracket for CR Reservoir 140 Series
Accessories
1
BPM-MBCR140
2
M4x48mm Screw
3
M4x10mm Screw
1 PCS
4 PCS
2 PCS
EN ver.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BPM-MBCR140 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bitspower BPM-MBCR140

  • Page 1 EN ver.1 BPM-MBCR140 Bitspower Mount Bracket for CR Reservoir 140 Series Accessories BPM-MBCR140 1 PCS M4x48mm Screw 4 PCS M4x10mm Screw 2 PCS...
  • Page 2 As such, if you feel uncomfortable with the steps involved in installing this product, please reach out to our customer support for assistance. We recommend the use of a leak tester, such as our Bitspower Digital Leak Detector, after completing the assembly of your liquid cooling loop to make sure there are no leaks prior to filling up your loop with coolant.
  • Page 3 Assembly steps Installation Follow the right sequence to install. This product does not include the reservoir. Method A step 1 step 2 Assemble the M4x10mm screws. Lock the Mount Bracket. Not included step 3 Use M4x48mm screws to fix the product together with the Mount Bracket into the chassis.
  • Page 4 Assembly steps Installation Follow the right sequence to install. This product does not include the reservoir. Method B step 1 step 2 Assemble the M4x10mm screws. Lock the Mount Bracket. Not included step 3 Use M4x48mm screws to fix the product together with the Mount Bracket into the chassis.
  • Page 5 TC ver.1 BPM-MBCR140 Bitspower Mount Bracket for CR Reservoir 140 Series 配件 BPM-MBCR140 1 個 M4x48mm 螺絲 4 支 M4x10mm 螺絲 2 支...
  • Page 6 知識。 因此,如果您對安裝的步驟感到不了解, 請聯繫我們的客戶支援以獲得幫助。 我們建議在組裝完您的水路系統後使用測漏計測試,例如我們的 Bitspower 數位測漏計,以 免在注入水冷液後發生洩漏狀況。 禁止在水路有水或水泵運作時使用測漏計。 使用測漏計時,壓力不得超過 0.5 kg/cm 或 7.0 PSI。對您的水冷系統施加過高的壓力可能 會造成您的水冷零件損壞。 Bitspower 不對使用測漏計造成的任何潛在損壞負責。 在安裝任何零件時絕對不要過度擰緊,除非在說明中另有說明,否則過度擰緊會導致您的零 件損壞。 建議使用我們的 Bitspower 透明水冷液來獲得最佳的冷卻效果,同時使用 Bitspower 染料 來達成您想要的顏色。我們建議不要使用純蒸餾水,因為長時間使用可能會導致水垢與藻類 的產生。請避免使用任何其他非推薦的水冷液或液體。使用非推薦的水冷液或液體可能會導 致異常狀況,如硬體塗層剝落、沉積物或殘渣積聚導致管路或 O 圈的損壞和變形及水泵的不 正常運作。Bitspower 不因使用非推薦水冷液而出現的任何問題負責。 絕對不要混用或使用不同種類的金屬製成的零件至您的水冷系統中。絕對不要使用鋁底的水 冷零件與 Bitspower 產品一起使用,會導致您的水冷零件嚴重損壞和漏水,並使您的保固失 效。如果您對使用的零件有任何疑問或問題,請聯繫我們的客戶支援以獲得幫助。 Bitspower 保留更改我們產品設計和解釋的權利,恕不另行通知。產品的實際設計和顏色可 能與我們的網站上顯示的不同。 [ 6 ]...
  • Page 7 組裝步驟 使用說明 請按照正確的順序進行安裝 本產品不包括水箱。 方法 A 步驟 1 步驟 2 安裝 M4x10mm 螺絲。 鎖緊支架。 不包括 步驟 3 使用 M4x48mm 螺絲將產品與安裝支架一起固定在機殼中。 [ 7 ]...
  • Page 8 組裝步驟 使用說明 請按照正確的順序進行安裝 本產品不包括水箱。 方法 B 步驟 1 步驟 2 安裝 M4x10mm 螺絲。 鎖緊支架。 不包括 步驟 3 使用 M4x48mm 螺絲將產品與安裝支架一起固定在機殼中。 [ 8 ]...
  • Page 9 SC ver.1 BPM-MBCR140 Bitspower Mount Bracket for CR Reservoir 140 Series 配件 BPM-MBCR140 1 个 M4x48mm 螺丝 4 支 M4x10mm 螺丝 2 支...
  • Page 10 知识。因此,如果您对安装的步骤感到不了解, 请联系我们的客户支援以获得帮助。 我们建议在组装完您的水路系统后使用测漏计测试,例如我们的 Bitspower 数位测漏计,以 免在注入水冷液后发生泄漏状况。 禁止在水路有水或水泵运作时使用测漏计。 使用测漏计时,压力不得超过 0.5 kg/cm 或 7.0 PSI。对您的水冷系统施加过高的压力可能 会造成您的水冷零件损坏。 Bitspower 不对使用测漏计造成的任何潜在损坏负责。 在安装任何零件时绝对不要过度拧紧,除非在说明中另有说明,否则过度拧紧会导致您的零 件损坏。 建议使用我们的 Bitspower 透明水冷液来获得最佳的冷却效果,同时使用 Bitspower 染料 来达成您想要的颜色。我们建议不要使用纯蒸馏水,因为长时间使用可能会导致水垢与藻类 的产生。请避免使用任何其他非推荐的水冷液或液体。使用非推荐的水冷液或液体可能会导 致异常状况,如硬体涂层剥落、沉积物或残渣积聚导致管路或 O 圈的损坏和变形及水泵的不 正常运作。 Bitspower 不因使用非推荐水冷液而出现的任何问题负责。 绝对不要混用或使用不同种类的金属制成的零件至您的水冷系统中。绝对不要使用铝底的水 冷零件与 Bitspower 产品一起使用,会导致您的水冷零件严重损坏和漏水,并使您的保固失 效。如果您对使用的零件有任何疑问或问题,请联系我们的客户支援以获得帮助。 Bitspower 保留更改我们产品设计和解释的权利,恕不另行通知。产品的实际设计和颜色可 能与我们的网站上显示的不同。 [ 10 ]...
  • Page 11 组装步骤 使用说明 请按照正确的顺序进行安装 本产品不包括水箱。 方法 A 步骤 1 步骤 2 安装 M4x10mm 螺丝。 锁紧支架。 不包括 步骤 3 使用 M4x48mm 螺丝将产品与安装支架一起固定在机壳中。 [ 11 ]...
  • Page 12 组装步骤 使用说明 请按照正确的顺序进行安装 本产品不包括水箱。 方法 A 步骤 1 步骤 2 安装 M4x10mm 螺丝。 锁紧支架。 不包括 步骤 3 使用 M4x48mm 螺丝将产品与安装支架一起固定在机壳中。 [ 12 ]...
