LEHMANN GIRO Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GB
www.lehmann-locks.com
GIRO Keypad
(GIRO TA)
Operating Instructions
Content
Page
General Description ................................................................................................................. 2
Functional Description ............................................................................................................. 3
System components and package contents .............................................................................4
Dimensions............................................................................................................................... 5
Change direction of rotating ....................................................................................................6
Mounting on wood / Mounting on metal surfaces ..................................................................7
on wood / Mounting GIRO with the status indicator on metal ................................................8
Structure of the keypad / Factory Settings .............................................................................10
Switching to Free Code Mode ................................................................................................13
Changing the Master Code .....................................................................................................14
Changing the emergency opening code .................................................................................15
Emergency Opening / Resett to Factory Settings ...................................................................16
Automatic locking in Fixed Code mode ..................................................................................17
Automatic opening in Free Code mode .................................................................................18
Activation and deactivation of acoustic signals ......................................................................19
Configuration of the lock with the NFC-App ..........................................................................20
Battery warning / Update of firmware / Disposal ..................................................................22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GIRO and is the answer not in the manual?

Questions and answers

Summary of Contents for LEHMANN GIRO

  • Page 1: Table Of Contents

    Change direction of rotating ....................6 Mounting on wood / Mounting on metal surfaces ..............7 Assembly instructions for the status indicator / Mounting GIRO with the status indicator on wood / Mounting GIRO with the status indicator on metal ..........8 Emergency opening with service key / Getting started and changing batteries ......9 Structure of the keypad / Factory Settings ................10...

  • Page 2: General Description

    GENERAL DESCRIPTION The GIRO TA lock is a battery-operated electronic furniture lock with a keypad, which is intended for the inside of buildings. These operating instructions provide you with information on how to operate the locking system without errors. Keep the operating instructions in an easily accessible place. Improper use can destroy the locking system and lead to the loss of any warranty claims.

  • Page 3: Technical Specifications / Safety Precautions / Care And Maintenance Functional Description

    FUNCTIONAL DESCRIPTION With the GIRO TA locking system you can conveniently lock and unlock your furniture. To do this, the lock is turned manually by the user. A PIN code is used as the “key”. Two operating modes are available:...

  • Page 4: System Components And Package Contents

       Components: 7. Bolt (e.g. type 040) 1. Lock GIRO TA 8. Screw TX20n 2. Fixing element 1619 9. Striker plate 3011 with screws 3 x 15 3. Screws 3 x 15 for fixing element 10. Battery (CR123A)) 4.

  • Page 5: Dimensions

          Components: 5. Bolt (e.g. type 031) 1. Lock GIRO TA 6. Screw TX20n 2. Sealing ring 7. Battery (CR123A) 3. Nut (AF22) 8. Service key (optional) 4. Limiting plate L/R setting DIMENSIONS Lock Giro TA...

  • Page 6: Change Direction Of Rotating

    Striker plate 3011 Status indicator (optional) Fixing element 1619 CHANGE DIRECTION OF ROTATING The lock can be used for right hand doors and left hand doors. For right hand doors: For left hand doors: All dimensions in mm.

  • Page 7: Mounting On Wood / Mounting On Metal Surfaces

    MOUNTING ON WOOD ATTENTION: Install the lock only when it is unlocked. Carry out all programming processes and functional checks with the cabinet door open. When mounting on wood, the fixing element 1619 is required. Dimensions refer to bolt type 039. MOUNTING ON METAL SURFACES Dimensions refer to bolt type 031.

  • Page 8: Assembly Instructions For The Status Indicator / Mounting Giro With The Status Indicator On Wood / Mounting Giro With The Status Indicator On Metal

    When mounting the lock with the status indicator on wood, the fixing element 1619 is required. Dimensions refer to bolt type 040. MOUNTING GIRO WITH STATUS INDICATOR ON METAL SURFACES Dimensions refer to bolt type 039. All dimensions in mm.

  • Page 9: Emergency Opening With Service Key / Getting Started And Changing Batteries

    EMERGENCY OPENING WITH SERVICE KEY 1. Turn the key 45° 2. Turn the turn to the left knob by 45° 3. Turn the key 45° to 4. Lock is open the right GETTING STARTED AND CHANGING BATTERIES Inserting the battery Battery is inserted correctly in the battery compartment.

  • Page 10: Structure Of The Keypad / Factory Settings

    STRUCTURE OF THE KEYPAD LED-display Numbers 0 - 9 Cancel Enter Service cylinder You can cancel any process at any time using the Cancel button . When the cancel button is pressed, there is one short red flashing and an acoustic signal. Any input already made is deleted. During operation, make sure that each key input is acknowledged by an optical signal at the LED display and by an acoustic signal! If an optical light signal does not appear, the key input was not accepted.

  • Page 11: Locking & Unlocking In Free Code Mode / Switching To Fixed Code Mode

    LOCKING & UNLOCKING IN FREE CODE MODE The lock must be in open position. You can enter any 3 to 10 digit code for locking. When entering, make sure that each key input is acknowledged by a light signal at the LED display and by an acoustic signal. After opening by entering the correct code, the previous code will be deleted.

  • Page 12: Locking And Unlocking In Fixed Code Mode / User Changes The Fixed Code

    Enter of new fixed code (example: 1-4-5-6) Keys When the LED display turns off, the Optical signals new fixed code is valid. Acoustic signals If you cancel the enter process of a new fixed code with the cancel button or if you enter an incorrect code (invalid code length), the code 1-2-3 will automatically be valid.

  • Page 13: Switching To Free Code Mode

    After the buttons are pressed simultaneously, the LED will turn to a continuous green light until a new fixed code is entered. Now enter your new personal fixed code immediately. When entering, make sure that each key input is acknowledged by a light signal at the LED display and by an acoustic signal. Enter of new fixed code (example: 1-2-3-4-5) Keys When the LED...

  • Page 14: Changing The Master Code

    CHANGING THE MASTER CODE It is highly recommended that you change the default master code and to choose the longest possible and secure master code. The lock must be in open position. There must be no battery warning. The master code must be 3 to 10 digits. If you have already changed the default master code, enter your valid master code here.

  • Page 15: Changing The Emergency Opening Code

    CHANGING THE EMERGENCY OPENING CODE It is highly recommended that you change the default emergency opening code and to choose the longest possible and secure emergency opening code. The lock must be in open position. There must be no battery warning. The emergency opening code must be 3 to 10 digits.

  • Page 16: Emergency Opening / Resett To Factory Settings

    EMERGENCY OPENING If you have already changed the default emergency opening code, enter your valid emergency opening code here. Enter emergency opening code (example: factory settings) Keys Optical The lock is unlocked. signals Acoustic signals After an emergency opening in the Fixed Code mode, the lock can be used again normally with the previously programmed fixed code.

  • Page 17: Automatic Locking In Fixed Code Mode

    AUTOMATIC LOCKING IN FIXED CODE MODE The lock must be in open position. There must be no battery warning. This feature can only be activated in Fixed Code mode. If you have already changed the default master code, enter your valid master code here. In order to confirm the master code, press the keys simultaneously.

  • Page 18: Automatic Opening In Free Code Mode

    AUTOMATIC OPENING IN FREE CODE MODE The lock must be in open position. There must be no battery warning. This feature can only be activated in Free Code mode. If you have already changed the default master code, enter your valid master code here. In order to confirm the master code, press the keys simultaneously.

  • Page 19: Activation And Deactivation Of Acoustic Signals

    ACTIVATION AND DEACTIVATION OF ACOUSTIC SIGNALS The lock must be in open position. There must be no battery warning. If you have already changed the default master code, enter your valid master code here. In order to confirm the master code, press the keys simultaneously.

  • Page 20: Configuration Of The Lock With The Nfc-App

    CONFIGURATION OF THE LOCK WITH THE NFC-APP The lock Giro TA can be configured either manually or with the LEHMANN Config app. After putting the app into operation on an Android smartphone or Apple iPhone, configuration changes can be made via the app.
  • Page 21 To transfer configurations or direct commands to the lock, first check the position of the NFC antenna on your smartphone. Activate the NFC interface on your smartphone. Click on the „Transfer“ button in the LEHMANN Config App. Hold the NFC antenna of your smartphone at the marked location on the corresponding lock. The NFC antenna in the lock is located in this area.

  • Page 22: Battery Warning / Update Of Firmware / Disposal

    You have the option of updating the firmware of the locking system. A special adapter is required for the firmware update. Firmware updates for this locking system are only made available on the website www.lehmann-locks.com necessary (e.g. technical necessity). Further information on implementation and installation will be provided together with the firmware update.
  • Page 23 NOTE...
  • Page 24 LEHMANN Vertriebsgesellschaft mbH & Co. KG Postfach 26 20 • D-32383 Minden Fon +49 571 / 50 599-0 • Fax +49 571 / 50 599-822 info@lehmann-locks.com • www.lehmann-locks.com DIN EN ISO 9001:2015 zertifiziert...
