AudioCodes Kramer KAC-SCD-10 Meeting Room Scheduler
1. Product Introduction
Thank you for purchasing AudioCodes Kramer KAC-SCD-10
Meeting Room Scheduler!
The AudioCodes Kramer KAC-SCD-10 Meeting Room
Scheduler is a purpose-built Microsoft Teams Panel with an
intuitive touchscreen display.
Neatly installed right at the entrance to the meeting room,
the KAC-SCD-10's brightly colored status LED enables you to
quickly see the meeting room's availability from a distance.
You can also view the meeting details on its sleek and clear
LCD screen and reserve a meeting room on the spot.
For more information on the KAC-SCD-10, click here.
2.
Shipped Items
Make sure you received the following items in the shipped box:
KAC-SCD-10
Ethernet cable – approximately 9 feet (~3m)
1 screw placement template (for wall mount)
4 screws and 4 wall anchors
Mounting bracket and adhesive tape (for glass partition mount)
12V Power Adapter (AC 100-240V)
PN
2900-301726QS REV 1
Quick Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kramer KAC-SCD-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for AudioCodes Kramer KAC-SCD-10

  • Page 1 AudioCodes Kramer KAC-SCD-10 Meeting Room Scheduler Quick Guide 1. Product Introduction Thank you for purchasing AudioCodes Kramer KAC-SCD-10 Meeting Room Scheduler! The AudioCodes Kramer KAC-SCD-10 Meeting Room Scheduler is a purpose-built Microsoft Teams Panel with an intuitive touchscreen display. Neatly installed right at the entrance to the meeting room, the KAC-SCD-10’s brightly colored status LED enables you to...
  • Page 2 3. Mounting the KAC-SCD-10 Position the KAC-SCD-10 at the entrance to a conference room. The KAC-SCD-10 can be mounted on wall using screws, or it can be mounted on partition glass using a mounting bracket and adhesive tape. Mounting KAC-SCD-10 to Wall Mounting KAC-SCD-10 to Glass Use the supplied template to mark locations for Make sure the surface is clean and dry.
  • Page 3 SCD-10 LAN/PoE to any PoE Ethernet switch. 6. Managing KAC-SCD-10 KAC-SCD-10 is managed by AudioCodes Kramers One Voice Operations Center | Device Manager. It can also be managed by Microsoft Teams Admin Center (TAC). Management includes (but not limited to): ✓...
  • Page 4 7. Using the KAC-SCD-10 Use the table below as reference to the following figure: Item Description Space availability status LED, viewable from a distance: ◼ Green indicates meeting space is available; optionally, reserve it right now. ◼ Red or purple indicates meeting space unavailable. ◼...
  • Page 5 To enable advanced meeting functions: Click the Device Pairing option in ‘Teams Admin Settings’ menu, and then select your device (to pair it at the Teams level): Select the Wallpapers option to choose a wallpaper. P a g e...
  • Page 6: Specifications

    Select the LED settings option to choose the LED color for indicating a busy state. Select the Meetings option to define advanced meeting check-in functions. 8. Specifications For KAC-SCD-10 technical specifications, refer to the KAC-SCD-10 Datasheet. P a g e...
  • Page 7 FCC Caution Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 8: Notice Information

    Website: https://www.kramerav.com/ ©2023 AudioCodes Ltd. All rights reserved. AudioCodes, AC, HD VoIP, HD VoIP Sounds Better, IPmedia, Mediant, MediaPack, What’s Inside Matters, OSN, SmartTAP, User Management Pack, VMAS, VoIPerfect, VoIPerfectHD, Your Gateway To VoIP, 3GX, VocaNom, AudioCodes One Voice, AudioCodes Meeting Insights and AudioCodes Room Experience are trademarks or registered trademarks of AudioCodes Limited.
