WTC-8J0

Industrial BOX

USER'S MANUAL

JUL 05 2023

V1.1

All other brand names are registered trademarks of their respective owners.

The information contained in this document is subject to change without notice

Table of Contents

Need help?

Do you have a question about the WTC-8J0 and is the answer not in the manual?

Questions and answers

Summary of Contents for ICP WTC-8J0

Page 1 WTC-8J0 Industrial BOX USER’S MANUAL JUL 05 2023 V1.1 Copyright©,2023. All rights reserved All other brand names are registered trademarks of their respective owners. The information contained in this document is subject to change without notice...
Page 2 Version Change History Date Version Description Remark 2023/5/15 First release 2023/6/30 Modify Product model name...
Page 3 Acknowledgments  Intel® Celeron processor is registered trademarks of Intel® Corporation.  IBM, PC/AT, PS/2 are trademarks of International Business Machines Corporation. ® ®  Microsoft Windows is a registered trademark of Microsoft Corporation.  RTL is a trademark of Realtek Semi-Conductor Co., Ltd. ...
Page 4 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. This equipment generates, uses and can radiate radio frequency energy.
Page 5 Safety Instructions Intended use The WTC-8J0 is intended to serve as an industrial monitor which is designed for general purpose for industrial environment. Intended User profile The equipment is intended for infant or adults by profession Health care professionals. Greeting & Setup Thank you for purchasing the WTC-8J0 unit.
Page 6 contact a service technician for repairs. Continual use of the unit may result cause a fire or electric shock. Also, do not repair the unit on your own. Having two or more people transporting the display unit is recommended. In addition, when installing the unit by suspending it also requires two or more people.
Page 7 If the unit is not going to be in use for an extended period of time, remember to disconnect the unit. 10. The industrial BOX unit uses voltage between 100-240VAC. Connect the unit to a power source with the same numerical value as shown. Please use only the power cord provided by the dealer to ensure safety and EMC compliance.
Page 8 Operating principle A Industrial BOX has four main components: the arithmetic  logic unit (ALU), the control unit, the memory, and the input and output devices (collectively termed I/O). These parts are interconnected by buses, often made of groups of wires. The control unit, ALU, and registers are collectively known as ...
Page 9 If the unit is not functioning properly, observe the performance level of the display closely to determine what type of servicing is needed. Do not attempt to repair the industrial BOX unit on your own. Disassembling the cover exposes users’ to high voltages and other dangerous conditions.
Page 10 EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power cords. When you need to dispose of your display products, please follow the guidance of your local authority, or ask the shop where you purchased...
Page 11 Caution: DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW -20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE EQUIPMENT. This equipment shall not be used in life support systems. The user is not to touch SIP/SOPs and the patient at the same time.
Page 12: Table Of Contents
Features ................3 Specifications ..............4 Getting Started ............ 7 System Set Up ............... 7 Dimension WTC-8J0 M12 ........... 8 Dimension WTC-8J0 Cable Gland ......9 System View ..............10 Disconnect Device ............12 BIOS Setup ............13 Appendix .............. 26...
Page 13: Introduction
Introduction Product Description The WTC-8J0 Industrial BOX is based on Intel ElkHart Lake SoC Processor J6412, it accommodates one 2.5” SATA III hard disk drive, one M.2 SATA SSD and up to 32GB DDR4 SODIMM. The high brightness LCD, Fanless solution, integrated multimedia...
Page 14: Package List
Package list Before you begin installing your Industrial Station, please make sure that the following items have been shipped:  The WTC-8J0 Industrial Box PC unit  User's manual, chipset drivers  Power Adapter x 1 (type/model: LSU120A-108)  Power cord –US type, or other type in UK, EU…etc.
Page 15: Features
Features   Intel® ElkHart Lake J6412 BOX  Low Power Fanless Thermal Solution  Res or P-Cap Touch with IP69K Design  Optional Cable Gland for External I.O.  Special Inspection of 100% Waterproof Guarantee WTC-8J0 User’s manual...
Page 16: Specifications
(Default is RS232 , RS232/422/485 can be adjusted in BIOS setup utility) LAN –1 x 1 Gigabit LAN, 1 x 2.5 Gigabit LAN Audio - 2 (Line-out, and Mic-in) Video output - HDMI2.0b x 1, VGA x 1 WTC-8J0 User’s manual...
Page 17 Non-operating: 50g/1.76 oz, 11 ms, half sine wave Operating: 5 ~ 17 Hz , Amplitude：0.117 ~ 500Hz , Shock Acceleration：1.0G Non-operating:10~55Hz/0.15g, 55~500Hz/2.0g Operational: up to 3000 m (9842 feet) Altitudes Shipping: up to 12192 m (40000 feet) WTC-8J0 User’s manual...
Page 18 700 – 1060 hPa (Operation) Pressure 186 – 1060 hPa (Storage) 186 – 1060 hPa (Transportation) CE / FCC / VCCI Class A (M12) EMI / Safety CE / FCC / VCCI Class B (Cable gland) IP69K Noise Fanless WTC-8J0 User’s manual...
Page 19: Getting Started
“F11” key, go into BIOS quick boot menu, select “USB-CD ROM”, WAIT FOR 20 SECONDS, then press enter, system OS will boot up from USB-CD/DVD drive directly. Notice: The installation is only to be carried out by manufacturer trained and authorized personnel. WTC-8J0 User’s manual...
Page 20: Dimension Wtc-8J0 M12
Dimension WTC-8J0 M12 WTC-8J0 User’s manual...
Page 21: Dimension Wtc-8J0 Cable Gland
Dimension WTC-8J0 Cable Gland WTC-8J0 User’s manual...
Page 22: System View
System View  View M12_back Cable Gland_back WTC-8J0 User’s manual...
Page 23 I/O parts Cable Gland WTC-8J0 User’s manual...
Page 24: Disconnect Device
Unplug the power cord from the power adapter jack to disconnect the device. Turn off the system: Turning off WTC-8J0 properly is important for system reliability. 1. On the start menu, click “Shut down” and select “OK” WTC-8J0 User’s manual...
Page 25: Bios Setup
<PgUp> and <PgDn> keys to change entries, <F1> for help and <Esc> to quit. When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices. WTC-8J0 User’s manual...
Page 26 Set the Date. Use Tab to switch between Date elements. Default Ranges: Year: 1998-9999 Months: 1-12 Days: Dependent on month Range of Years may vary. System Time Set the Time. Use Tab to switch between Time elements. WTC-8J0 User’s manual...
Page 27 Intel SpeedStep Technology Allows more than two frequency ranges to be supported. Intel Turbo Boost Technology Intel Turbo Boost Technology enables the processor to run above its base operating frequency when the operating system requests the highest performance state. WTC-8J0 User’s manual...
Page 28 If [Power On] is selected, the system will start to boot up when the power recovers. Storage Configuration Configure Storage devices. SATA Controllers(s) Enables/disable the SATA controllers. SATA Mode Selection WTC-8J0 User’s manual...
Page 29 Suspend to RAM It is recommended to select auto for ACPI S3 power saving. PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. RTC Alarm Power On WTC-8J0 User’s manual...
Page 30 TCG_2: Support new TCG2 protocol and event format for Win10 or later Physical Presence Spec Version Select to Tell O.S. to support PPI Spec Version 1.2 or 1.3. Note some HCK tests might not support 1.3. TPM 2.0 InterfaceType WTC-8J0 User’s manual...
Page 31 TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated Instant Flash Save UEFI files in your USB storage device and run Instant Flash to update your UEFI. Please note that your USB storage device must be FAT32/16/12 file system. WTC-8J0 User’s manual...
Page 32 H/W Monitor CPU_FAN1 Setting Quiet Fan Function Control CHA_FAN1 Setting Quiet Fan Function Control Case Open Feature Enable or disable the feature of Case Open. WTC-8J0 User’s manual...
Page 33 Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset Secure Boot Mode Secure Boot mode options: Standard or Custom. In Custom mode, Secure Boot Policy variables can be configured by a WTC-8J0 User’s manual...
Page 34 Key Management Enables expert users to modify Secure Boot Policy variables without full authentication Intel(R) Platform Trust Technology Enabled/Disabled Intel PTT function, Enabled: Enable Intel PTT in ME, Disabled: Disable Intel PTT in ME, Use discrete TPM Module. WTC-8J0 User’s manual...
Page 35 Boot From Onboard LAN Boot From Onboard LAN Setup Prompt Timeout Configure the number of seconds to wait for the UEFI setup utility. Bootup Num-Lock Select whether Num Lock should be turned on or off when the WTC-8J0 User’s manual...
Page 36 Full Screen Logo Enable to display the boot logo or disable to show normal POST messages WTC-8J0 User’s manual...
Page 37 F7 key can be used for this operation. Load UEFI Defaults Load UEFI Default values for all the setup questions. F9 key can be used for this operation. Launch EFI Shell from filesystem device Copy shellx64.efi to the root directory to launch EFI Shell. WTC-8J0 User’s manual...
Page 38: Appendix
Appendix A. Jumper settings and Connectors WTC-8J0 User’s manual...
Page 39 WTC-8J0 User’s manual...
