Power Panel 65
User's manual
Version: 2.30 (January 2020)
Order no.: MAPP65-ENG
Translation of the original documentation
All values in this manual are current as of its creation. We reserve the right to change the contents of this manual
without notice. B&R Industrial Automation GmbH is not liable for technical or editorial errors and defects in this
manual. In addition, B&R Industrial Automation GmbH assumes no liability for damages that are directly or indirectly
attributable to the delivery, performance or use of this material. We point out that the software and hardware
designations and brand names of the respective companies used in this document are subject to general trademark,
brand or patent protection.
Power Panel 65 User's manual V2.30
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Panel 65 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vicpas Power Panel 65

  • Page 1 We point out that the software and hardware designations and brand names of the respective companies used in this document are subject to general trademark, brand or patent protection. Power Panel 65 User's manual V2.30...
  • Page 2 Table of contents Power Panel 65 User's manual V2.30...

  • Page 3: Table Of Contents

    6.7 Dimensions..............................44 7 4PP065.0571-X74............................45 7.1 Order data..............................45 7.2 Technical data............................45 7.3 Supported interface modules........................47 7.4 Diagnostic LEDs............................48 7.5 Connection elements..........................49 7.6 Operating mode and node number switches..................... 50 Power Panel 65 User's manual V2.30...
  • Page 4 9.7 Operating mode and node number switches..................... 67 9.8 Dimensions..............................68 Chapter 3 Interface modules..................69 1 General information............................69 2 Overview................................69 3 Power Panel 65 support..........................69 4 4PP065.IF10-1..............................70 4.1 Order data..............................70 4.2 Technical data............................70 4.3 LED status indicators..........................71 4.4 RS232 interface............................
  • Page 5 Chapter 6 Accessories....................97 1 Overview................................97 2 Replacement batteries............................. 98 2.1 Order data..............................98 2.2 Technical data............................98 2.3 Contents of delivery............................98 3 TB103 3-pin power supply connector......................99 3.1 Order data..............................99 3.2 Technical data............................99 Power Panel 65 User's manual V2.30...
  • Page 6 3.2 Inserting the CompactFlash card......................107 4 Preventing screen burn-in on LCD/TFT displays..................108 4.1 How can this be avoided?........................108 Chapter 8 Environmentally friendly disposal............109 1 Separation of materials..........................109 Chapter 9 Abbreviations..................111 1 General information............................111 2 Overview.................................111 Power Panel 65 User's manual V2.30...

  • Page 7: Chapter 1 General Information

    October 2014 Updated chapter "Accessories". 2.00 February 2014 Updated the following chapters: • Technical data in chapter 2 "Power Panel 65" • Technical data in chapter 3 "PP65 interface modules" • Chapter 5 "Standards and certifications" • Chapter 6 "Accessories"...

  • Page 8: General Safety Guidelines

    Electrical assemblies with housing • Do not touch the connector contacts on the device (bus data contacts). • Do not touch the connector contacts of connected cables. • Do not touch the contact tips on circuit boards. Power Panel 65 User's manual V2.30...

  • Page 9: Transport And Storage

    This can otherwise lead to dust deposits that affect the functionality of the device. Sufficient cooling may then no longer be ensured, especially in systems with an active cooling unit (fan). Power Panel 65 User's manual V2.30...
  • Page 10 Internet poses a potential threat to the system. It is the user's own responsibility to avert these dangers and to take appropriate measures such as virus protection programs, firewalls, etc. to protect against them and to use only software from trustworthy sources. Power Panel 65 User's manual V2.30...

  • Page 11: Cybersecurity Disclaimer For Products

    The term "control systems" refers to all types of B&R products such as controllers (e.g. X20), HMI systems (e.g. Power Panel T30), process control systems (e.g. APROL) and supporting systems such as engineering workstations with Automation Studio. Power Panel 65 User's manual V2.30...

  • Page 12: Terminology

    PP65, PP100/200, PP300/400, MP100/200, EC20, EC21, AC140, AC141, ARsim, ARwin, ARemb, APC620, APC700, APC810 System Generation Compact CPUs (SGC) - CPUs with Motorola processors (Embedded µP) The following CPUs belong to this series: CP0201, CP0291, CP0292, XC0201, XC0202, XC0292 Table 1: Terminology Power Panel 65 User's manual V2.30...

  • Page 13: Chapter 2 Device Description

    Ethernet, POWERLINK and X2X Link are used for the communication system. Additionally, these devices have been equipped with a slot for interface modules. Depending on requirements, the Power Panel 65 can be expanded with CAN bus, a PROFIBUS DP slave or an RS485/RS232 interface, making it perfectly suited for demanding tasks.

  • Page 14: General Technical Data

    Sodium bisulphate Brake fluid Aviation fuel Gasoline Water Sea water Decon Information: The specified characteristics, features and limit values only apply to this individual component and can deviate from those specified for the complete system. Power Panel 65 User's manual V2.30...

  • Page 15: Overview

    4PP065.0351-X74 4PP065.0571-P74 4PP065.0571-X74 4PP065.0571-P74F 4PP065.0571-X74F Figure Display TFT color Resolution QVGA Display size 3.5" 5.7" Touch screen Analog resistive Keys Slot for interface mod- ules Interfaces Ethernet 10/100 POWERLINK X2X Link USB 2.0 Page Power Panel 65 User's manual V2.30...

  • Page 16: Topologies

    2 Topologies 2.1 Power Panel as intelligent HMI, networked with X2X Link and CAN In this topology, the control program and visualization application run on the Power Panel 65. I/O peripherals and drives are connected via CAN bus or X2X.

  • Page 17: Power Panel As Intelligent Hmi, Networked With Powerlink

    Device description • Topologies 2.2 Power Panel as intelligent HMI, networked with POWERLINK In this topology, the control program runs on the Power Panel 65. I/O peripherals and drives are connected to the Power Panel via POWERLINK. Ethernet TCP/IP Line communication...

  • Page 18: System Overview

    Device description • System overview 3 System overview 33 MHz 66 MHz 48 MHz 33 MHz Power Panel 65 User's manual V2.30...

  • Page 19: 4Pp065.0351-P74

    Service life 4 years Removable Yes, accessible from the outside Variant Lithium ion Power button Reset button Backup capacitor Buffer time 10 min Certifications cULus E115267 Industrial control equipment Table 3: 4PP065.0351-P74 - Technical data Power Panel 65 User's manual V2.30...
  • Page 20 Ethernet Quantity Controller Intel 82551ER Variant Shielded RJ45 port (10/100 Base-T) Transfer rate 10/100 Mbit/s Max. baud rate 100 Mbit/s Cables S/STP (Category 5) LED status indicators Link/Activity Table 3: 4PP065.0351-P74 - Technical data Power Panel 65 User's manual V2.30...

  • Page 21: Supported Interface Modules

    Weight including fasteners and battery (46.5 g) but without an interface module. 4.3 Supported interface modules Support for interface modules is provided starting with the following Automation Runtime versions: Interface modules 4PP065.IF10-1 4PP065.IF23-1 4PP065.IF24-1 4PP065.IF33-1 Automation Runtime version A3.01 A3.01 A3.07 A3.01 Power Panel 65 User's manual V2.30...

  • Page 22: Diagnostic Leds

    This means that the configured station number lies within the range 0x01 - 0xFD. Blink code System error: The red blinking LED signals an error code (see "System failure error codes" on page 24). Power Panel 65 User's manual V2.30...
  • Page 23 Controlled node (CN) No output data is being produced, and no input data is being received. It is only possible to switch to or leave this state after the manager has given the appropriate command. Power Panel 65 User's manual V2.30...

  • Page 24: Connection Elements

    POWERLINK interface 4.5.1 POWERLINK interface Interface Pinout Terminal POWERLINK Receive signal POWERLINK interface RXD\ Receive signal inverted Transmit signal Termination Termination Termination Termination TXD\ Transmit signal inverted Shielded RJ45 port Termination Termination Termination Termination Power Panel 65 User's manual V2.30...
  • Page 25 Device description • 4PP065.0351-P74 4.5.2 USB interface This Power Panel 65 features a USB 2.0 (Universal Serial Bus) host controller with two USB interfaces that are accessible externally for the user. USB port 1 USB port 2 USB interface Transfer rate Low speed (1.5 Mbit/s), full speed (12 Mbit/s), high speed (480 Mbit/s)

  • Page 26: Key Assignments

    4.7 Operating mode and node number switches The Power Panel 65 is equipped with 2 hex switches that can be used as operating mode or node number switches. Switch positions 0x01 to 0xFE are used to set the INA node number of the Ethernet interface.

  • Page 27: Dimensions

    Device description • 4PP065.0351-P74 4.8 Dimensions 109.5 27.3 Installation cutout: 188 ±0.5 mm x 130 ±0.5 mm Power Panel 65 User's manual V2.30...

  • Page 28: 4Pp065.0351-X74

    Battery Type Renata 950 mAh Service life 4 years Removable Yes, accessible from the outside Variant Lithium ion Power button Reset button Backup capacitor Buffer time 10 min Table 5: 4PP065.0351-X74 - Technical data Power Panel 65 User's manual V2.30...
  • Page 29 Ethernet Quantity Controller Intel 82551ER Variant Shielded RJ45 port (10/100 Base-T) Transfer rate 10/100 Mbit/s Max. baud rate 100 Mbit/s Cables S/STP (Category 5) LED status indicators Link/Activity Table 5: 4PP065.0351-X74 - Technical data Power Panel 65 User's manual V2.30...

  • Page 30: Supported Interface Modules

    Weight including fasteners and battery (46.5 g) but without an interface module. 5.3 Supported interface modules Support for interface modules is provided starting with the following Automation Runtime versions: Interface modules 4PP065.IF10-1 4PP065.IF23-1 4PP065.IF24-1 4PP065.IF33-1 Automation Runtime version C2.96 C2.96 A3.07 C2.96 Power Panel 65 User's manual V2.30...

  • Page 31: Diagnostic Leds

    There are two additional LEDs for the Ethernet interface. (green) (orange) Color Status Description Orange No Ethernet activity on the bus. Blinking Ethernet activity on the bus. Green Link established to the remote station Power Panel 65 User's manual V2.30...

  • Page 32: Connection Elements

    Accessory terminal block, 4-pin, cage clamp terminal block, 2.5 mm² 4-pin male multipoint connector 5.5.2 USB interface This Power Panel 65 features a USB 2.0 (Universal Serial Bus) host controller with two USB interfaces that are accessible externally for the user. USB interface 1...

  • Page 33: Key Assignments

    The functional ground must be connected to ground (e.g. control cabinet) using the shortest possible path. Using the largest possible conductor cross section on the power supply connector is recom- mended. 5.6 Key assignments ◄ ↵ ▲ ► ▼ Power Panel 65 User's manual V2.30...

  • Page 34: Operating Mode And Node Number Switches

    5.7 Operating mode and node number switches The Power Panel 65 is equipped with 2 hex switches that can be used as operating mode or node number switches. Switch positions 0x01 to 0xFE are used to set the INA node number of the Ethernet interface.

  • Page 35: Dimensions

    Device description • 4PP065.0351-X74 5.8 Dimensions 109.5 27.3 Installation cutout: 188 ±0.5 mm x 130 ±0.5 mm Power Panel 65 User's manual V2.30...

  • Page 36: 4Pp065.0571-P74

    Yes, accessible from the outside Variant Lithium ion Backup capacitor Buffer time 10 min Certifications cULus E115267 Industrial control equipment Controller Bootloader, operating system PP65 supported starting with version Automation Runtime, A3.01 Table 7: 4PP065.0571-P74 - Technical data Power Panel 65 User's manual V2.30...
  • Page 37 Transfer rate 100 Mbit/s Transfer 100 Base-T (ANSI/IEEE 802.3) Status LED Link/Activity Cable length Max. 100 m between two stations (segment length) Electrical properties Nominal voltage 24 VDC ±25% Table 7: 4PP065.0571-P74 - Technical data Power Panel 65 User's manual V2.30...

  • Page 38: Supported Interface Modules

    A3.01 A3.01 A3.07 A3.01 6.4 Diagnostic LEDs There are four diagnostic LEDs on the back of the PP65. Information: The behavior of the Status LED has changed starting with AR J2.96, E3.01 and B3.06. Power Panel 65 User's manual V2.30...
  • Page 39 If an error occurs in the following statuses, then the green LED blinks over the red LED: • BASIC_ETHERNET • PRE_OPERATIONAL_1 • PRE_OPERATIONAL_2 • READY_TO_OPERATE Example: Status (green) Error (red) EPL LED Power Panel 65 User's manual V2.30...
  • Page 40 ... 600 ms Pause ... 2 second delay Error description Error code displayed by red EPL LED RAM error ● ● ● Pause ● ● ● Pause Hardware error ● ● Pause ● ● Pause Power Panel 65 User's manual V2.30...

  • Page 41: Connection Elements

    POWERLINK interface 6.5.1 POWERLINK interface Interface Pinout Terminal POWERLINK Receive signal POWERLINK interface RXD\ Receive signal inverted Transmit signal Termination Termination Termination Termination TXD\ Transmit signal inverted Shielded RJ45 port Termination Termination Termination Termination Power Panel 65 User's manual V2.30...
  • Page 42 Device description • 4PP065.0571-P74 6.5.2 USB interface This Power Panel 65 features a USB 2.0 (Universal Serial Bus) host controller with two USB interfaces that are accessible externally for the user. USB port 1 USB port 2 USB interface Transfer rate Low speed (1.5 Mbit/s), full speed (12 Mbit/s), high speed (480 Mbit/s)

  • Page 43: Operating Mode And Node Number Switches

    6.6 Operating mode and node number switches The Power Panel 65 is equipped with 2 hex switches that can be used as operating mode or node number switches. Switch positions 0x01 to 0xFE are used to set the INA node number of the Ethernet interface.

  • Page 44: Dimensions

    Device description • 4PP065.0571-P74 6.7 Dimensions 109.5 27.3 Installation cutout: 188 ±0.5 mm x 130 ±0.5 mm Power Panel 65 User's manual V2.30...

  • Page 45: 4Pp065.0571-X74

    Renata 950 mAh Service life 4 years Removable Yes, accessible from the outside Variant Lithium ion Backup capacitor Buffer time 10 min Certifications cULus E115267 Industrial control equipment Table 9: 4PP065.0571-X74 - Technical data Power Panel 65 User's manual V2.30...
  • Page 46 Ethernet Quantity Controller Intel 82551ER Variant Shielded RJ45 port (10/100 Base-T) Transfer rate 10/100 Mbit/s Max. baud rate 100 Mbit/s Cables S/STP (Category 5) LED status indicators Link/Activity Table 9: 4PP065.0571-X74 - Technical data Power Panel 65 User's manual V2.30...

  • Page 47: Supported Interface Modules

    Weight including fasteners and battery (46.5 g) but without an interface module. 7.3 Supported interface modules Support for interface modules is provided starting with the following Automation Runtime versions: Interface modules 4PP065.IF10-1 4PP065.IF23-1 4PP065.IF24-1 4PP065.IF33-1 Automation Runtime version C2.96 C2.96 A3.07 C2.96 Power Panel 65 User's manual V2.30...

  • Page 48: Diagnostic Leds

    There are two additional LEDs for the Ethernet interface. (green) (orange) Color Status Description Orange No Ethernet activity on the bus. Blinking Ethernet activity on the bus. Green Link established to the remote station Power Panel 65 User's manual V2.30...

  • Page 49: Connection Elements

    Accessory terminal block, 4-pin, cage clamp terminal block, 2.5 mm² 4-pin male multipoint connector 7.5.2 USB interface This Power Panel 65 features a USB 2.0 (Universal Serial Bus) host controller with two USB interfaces that are accessible externally for the user. USB interface 1...

  • Page 50: Operating Mode And Node Number Switches

    7.6 Operating mode and node number switches The Power Panel 65 is equipped with 2 hex switches that can be used as operating mode or node number switches. Switch positions 0x01 to 0xFE are used to set the INA node number of the Ethernet interface.

  • Page 51: Dimensions

    Device description • 4PP065.0571-X74 7.7 Dimensions 109.5 27.3 Installation cutout: 188 ±0.5 mm x 130 ±0.5 mm Power Panel 65 User's manual V2.30...

  • Page 52: 4Pp065.0571-P74F

    Yes, accessible from the outside Variant Lithium ion Backup capacitor Buffer time 10 min Certifications cULus E115267 Industrial control equipment Controller Bootloader, operating system PP65 supported starting with version Automation Runtime, A3.01 Table 11: 4PP065.0571-P74F - Technical data Power Panel 65 User's manual V2.30...
  • Page 53 100 Mbit/s Transfer 100 Base-T (ANSI/IEEE 802.3) Status LED Link/Activity Cable length Max. 100 m between two stations (segment length) Keys Variant Membrane keypad with metallic snap-action disks Table 11: 4PP065.0571-P74F - Technical data Power Panel 65 User's manual V2.30...

  • Page 54: Supported Interface Modules

    Weight including fasteners and battery (46.5 g) but without an interface module. 8.3 Supported interface modules Support for interface modules is provided starting with the following Automation Runtime versions: Interface modules 4PP065.IF10-1 4PP065.IF23-1 4PP065.IF24-1 4PP065.IF33-1 Automation Runtime version A3.01 A3.01 A3.07 A3.01 Power Panel 65 User's manual V2.30...

  • Page 55: Diagnostic Leds

    This means that the configured station number lies within the range 0x01 - 0xFD. Blink code System error: The red blinking LED signals an error code (see "System failure error codes" on page 57). Power Panel 65 User's manual V2.30...
  • Page 56 Controlled node (CN) No output data is being produced, and no input data is being received. It is only possible to switch to or leave this state after the manager has given the appropriate command. Power Panel 65 User's manual V2.30...

  • Page 57: Connection Elements

    POWERLINK interface 8.5.1 POWERLINK interface Interface Pinout Terminal POWERLINK Receive signal POWERLINK interface RXD\ Receive signal inverted Transmit signal Termination Termination Termination Termination TXD\ Transmit signal inverted Shielded RJ45 port Termination Termination Termination Termination Power Panel 65 User's manual V2.30...
  • Page 58 Device description • 4PP065.0571-P74F 8.5.2 USB interface This Power Panel 65 features a USB 2.0 (Universal Serial Bus) host controller with two USB interfaces that are accessible externally for the user. USB port 1 USB port 2 USB interface Transfer rate Low speed (1.5 Mbit/s), full speed (12 Mbit/s), high speed (480 Mbit/s)

  • Page 59: Key Assignments

    8.7 Operating mode and node number switches The Power Panel 65 is equipped with 2 hex switches that can be used as operating mode or node number switches. Switch positions 0x01 to 0xFE are used to set the INA node number of the Ethernet interface.

  • Page 60: Dimensions

    Device description • 4PP065.0571-P74F 8.8 Dimensions 109.5 27.3 Installation cutout: 188 ±0.5 mm x 130 ±0.5 mm Power Panel 65 User's manual V2.30...

  • Page 61: 4Pp065.0571-X74F

    Red/Green Orange User Green Battery Type Renata 950 mAh Service life 4 years Removable Yes, accessible from the outside Variant Lithium ion Backup capacitor Buffer time 10 min Table 13: 4PP065.0571-X74F - Technical data Power Panel 65 User's manual V2.30...
  • Page 62 Ethernet Quantity Controller Intel 82551ER Variant Shielded RJ45 port (10/100 Base-T) Transfer rate 10/100 Mbit/s Max. baud rate 100 Mbit/s Cables S/STP (Category 5) LED status indicators Link/Activity Table 13: 4PP065.0571-X74F - Technical data Power Panel 65 User's manual V2.30...

  • Page 63: Supported Interface Modules

    Weight including fasteners and battery (46.5 g) but without an interface module. 9.3 Supported interface modules Support for interface modules is provided starting with the following Automation Runtime versions: Interface modules 4PP065.IF10-1 4PP065.IF23-1 4PP065.IF24-1 4PP065.IF33-1 Automation Runtime version C2.96 C2.96 A3.07 C2.96 Power Panel 65 User's manual V2.30...

  • Page 64: Diagnostic Leds

    There are two additional LEDs for the Ethernet interface. (green) (orange) Color Status Description Orange No Ethernet activity on the bus. Blinking Ethernet activity on the bus. Green Link established to the remote station Power Panel 65 User's manual V2.30...

  • Page 65: Connection Elements

    Accessory terminal block, 4-pin, cage clamp terminal block, 2.5 mm² 4-pin male multipoint connector 9.5.2 USB interface This Power Panel 65 features a USB 2.0 (Universal Serial Bus) host controller with two USB interfaces that are accessible externally for the user. USB interface 1...

  • Page 66: Key Assignments

    The functional ground must be connected to ground (e.g. control cabinet) using the shortest possible path. Using the largest possible conductor cross section on the power supply connector is recom- mended. 9.6 Key assignments Power Panel 65 User's manual V2.30...

  • Page 67: Operating Mode And Node Number Switches

    9.7 Operating mode and node number switches The Power Panel 65 is equipped with 2 hex switches that can be used as operating mode or node number switches. Switch positions 0x01 to 0xFE are used to set the INA node number of the Ethernet interface.

  • Page 68: Dimensions

    Device description • 4PP065.0571-X74F 9.8 Dimensions 109.5 27.3 Installation cutout: 188 ±0.5 mm x 130 ±0.5 mm Power Panel 65 User's manual V2.30...

  • Page 69: Chapter 3 Interface Modules

    Chapter 3 • Interface modules 1 General information Depending on the installed interfaces (Ethernet, X2X, USB), Power Panel 65 devices also provide an extra slot for interface modules. Depending on requirements, the Power Panel 65 can be expanded with CAN bus, a PROFIBUS DP slave or an RS485/RS232 interface, making it perfectly suited for demanding tasks.

  • Page 70: 4Pp065.If10-1

    10 to 90%, non-condensing Storage 10 to 90%, non-condensing Transport 10 to 90%, non-condensing Mechanical properties Weight 49 g Slot PP65 insert Torque for mounting screw Max. 0.6 Nm Table 15: 4PP065.IF10-1 - Technical data Power Panel 65 User's manual V2.30...

  • Page 71: Led Status Indicators

    Module receiving data via the RS232 interface Orange Module sending data via the RS232 interface 4.4 RS232 interface Interface Pinout RS232 RS232 interface Receive signal Transmit signal Ground Request To Send 9-pin male DSUB connector Clear To Send Power Panel 65 User's manual V2.30...

  • Page 72: 4Pp065.If23-1

    500 m Max. transfer rate 115.2 kbit/s Network-capable FIFO buffer 16 bytes in transmit and receive direction Terminating resistor Integrated in the module Controller UART type 16C550 compatible Table 17: 4PP065.IF23-1 - Technical data Power Panel 65 User's manual V2.30...

  • Page 73: Led Status Indicators

    Module transmitting data via the X2X Link interface IF1 ... RS232 interface IF3 ... CAN bus interface 5.4 CAN bus node number The node number for the CAN bus interface is set with the two hex switches. Power Panel 65 User's manual V2.30...

  • Page 74: Rs232 (If1) Or Rs485/Rs422 (If2) Interface

    IF2 (RS485/RS422) and IF3 (CAN bus). IF2 (RS485/RS422) IF3 (CAN bus) Interface Switch position Description IF2 (RS485/RS422) Terminating resistor enabled (150 Ω) Terminating resistor disabled IF3 (CAN bus) Terminating resistor enabled (120 Ω) Terminating resistor disabled Power Panel 65 User's manual V2.30...

  • Page 75: I/O Mapping In Automation Studio

    Hexadecimal value of the node number switch. TerminatingResistor BOOL State of the switch for the IF3 terminating resistor: 0 ... OFF: Terminating resistor disabled 1 ... ON: Terminating resistor enabled TerminatingResistor only available in Automation Runtime A4.32 and later. Power Panel 65 User's manual V2.30...

  • Page 76: 4Pp065.If24-1

    500 m Max. transfer rate 115.2 kbit/s Network-capable FIFO buffer 16 bytes in transmit and receive direction Terminating resistor Integrated in the module, switchable Controller UART type 16C550 compatible Table 19: 4PP065.IF24-1 - Technical data Power Panel 65 User's manual V2.30...

  • Page 77: Led Status Indicators

    IF3 ... PROFIBUS DP slave interface 6.4 PROFIBUS DP slave node number The node number for the PROFIBUS DP slave interface is set with the 2 hex switches. The AsL2DP library is used for the 4PP065.IF24-1. Power Panel 65 User's manual V2.30...

  • Page 78: Rs232 (If1) Or Rs485/Rs422 (If2) Interface

    Interface Switch position Description Terminating resistor switched on (170 Ω between pin 1 and pin 9) Terminating resistor disabled Terminating resistor switched on (170 Ω between pin 1 and pin 9) Terminating resistor disabled Power Panel 65 User's manual V2.30...

  • Page 79: I/O Mapping In Automation Studio

    1 ... ON: Terminating resistor enabled TerminatingResistor only available in Automation Runtime A4.32 and later. I/O mapping for IF3 Interface IF3 is not shown in the I/O mapping in Automation Studio. This interface is operated using library AsL2DP. Power Panel 65 User's manual V2.30...

  • Page 80: 4Pp065.If33-1

    250 kbit/s Bus length ≤1000 m 50 kbit/s Operating conditions Degree of protection IP20 Ambient conditions Temperature Operation 0 to 50°C Storage -25 to 70°C Transport -25 to 70°C Table 21: 4PP065.IF33-1 - Technical data Power Panel 65 User's manual V2.30...

  • Page 81: Led Status Indicators

    The node number for the CAN bus interfaces is set with the two hex switches. The configured node number applies to both interfaces. 7.5 CAN bus interface (IF1 and IF2) Interface Pinout CAN bus CAN bus interface CAN_H CAN high CAN⊥ CAN ground CAN_L CAN low SHLD Shield 4-pin male multipoint connector Power Panel 65 User's manual V2.30...

  • Page 82: Terminating Resistors

    Hexadecimal value of the node number switch (identical with NodeSwitch of IF1). TerminatingResistor BOOL State of the switch for the IF2 terminating resistor: 0 ... OFF: Terminating resistor disabled 1 ... ON: Terminating resistor enabled TerminatingResistor only available in Automation Runtime A4.32 and later. Power Panel 65 User's manual V2.30...

  • Page 83: Chapter 4 Commissioning

    Power Panel device. The minimum specified spacing is indicated in the following diagrams. This applies to all Power Panel variants. Rear view At least At least 40 mm spacing 40 mm spacing Table 22: Spacing for air circulation - Rear view Power Panel 65 User's manual V2.30...
  • Page 84 Commissioning • Installation instructions Side view Air outlet At least 80 mm spacing Air intake Table 23: Spacing for air circulation - Side view Power Panel 65 User's manual V2.30...

  • Page 85: Mounting Orientations

    2) Remove the cover. 3) Insert the interface module into the PP65. 4) Apply light pressure until the interface module is inserted all the way. 5) Secure the interface module with the screws (max. 0.6 Nm). Power Panel 65 User's manual V2.30...

  • Page 86: Touch Screen Calibration

    It is possible to rotate the contents of the screen by 90° using the graphic driver's screen rotation function. This function is supported by Automation Runtime. In Automation Studio 2.7.x or 3.0.x, the screen orientation can be defined when a project is created or later when editing the project. Power Panel 65 User's manual V2.30...

  • Page 87: Chapter 5 Standards And Certifications

    • EMC directive 89/336/EEC • Low-voltage directive 73/23/EEC • Machine directive 98/37/EC 2 Overview of standards Power Panel 65 devices meet the following standards: Standard Description EN 55011 Electromagnetic compatibility (EMC), radio disturbance product standard, industrial, scientific, and medical high-frequency de- Class A, B vices (ISM devices), limit values and measurement procedure;...

  • Page 88: Emission Requirements

    10 m Quasi-peak value 216 to 960 MHz <210 dB (μV/m) measured at a distance of 10 m Quasi-peak value >960 MHz <300 dB (μV/m) measured at a distance of 10 m Quasi-peak value Power Panel 65 User's manual V2.30...

  • Page 89: Requirements For Immunity To Disturbances

    3 seconds, criteria A 1 kHz, duration 3 seconds, criteria A 1 kHz, duration 3 seconds, criteria A 800 to 960 MHz (GSM), 10 V/m, pulse modulation with 50% duty cycle, criteria A Power Panel 65 User's manual V2.30...

  • Page 90: High-Speed Transient Electrical Disturbances (Burst)

    AC power inputs Voltage dip <5% (>95% reduction), 250 periods, criteria C AC power inputs 20 interruptions, 0.5 periods, criteria A DC mains inputs 20 interruptions for 10 ms, <UN - 15%, criteria A Power Panel 65 User's manual V2.30...

  • Page 91: Damped Vibration

    Devices: Drop/topple on each edge Weight Required Weight Required Weight Required <20 kg <20 kg <20 kg 20 to 100 kg 20 to 100 kg 20 to 100 kg >100 kg >100 kg >100 kg Power Panel 65 User's manual V2.30...

  • Page 92: Free Fall (Packaged)

    Limits in accordance with dance with EN 61131-2 EN 60068-2-14 Large temperature fluctuations 3 hours at -40°C and 3 hours at 70°C for 2 cycles, then 2 hours acclimatization and function testing, duration approx. 14 hours Power Panel 65 User's manual V2.30...

  • Page 93: Temperature Fluctuations In Operation

    NEMA 250 type 4X UL 508 Sprayed water (front side) Sprayed with a 25.4 mm (diameter) nozzle Distance: 3 to 3.7 m (all angles), water volume: 246 liters/minute Duration: 48 seconds, 5 seconds minimum Power Panel 65 User's manual V2.30...

  • Page 94: Safety

    24 VDC -15% 48 VDC +20% 125 VDC 24 VAC -15% 48 VAC +10% 100 VAC 110 VAC 120 VAC 200 VAC 230 VAC 240 VAC 400 VAC Table 24: Safety - Voltage range Power Panel 65 User's manual V2.30...

  • Page 95: Other Tests

    ISO, IEC and CENELEC, as well as national standards from organizations such as UL, CSA, VDE, ÖVE, etc. We are committed to ensuring the reliability of our products in an industrial environment. Certifications Europe This mark certifies that all harmonized EN standards for the applicable directives have been met. Power Panel 65 User's manual V2.30...
  • Page 96 Accessories Power Panel 65 User's manual V2.30...

  • Page 97: Chapter 6 Accessories

    0G0001.00-090 PC - PLC/PW cable, RS232, online cable ● ● ● 0AC913.93 Bus adapter, CAN, 2 CAN interfaces, including 30 cm attachment cable (TB704) ● ● 0G1000.00-090 Bus connector, RS485, for PROFIBUS networks ● Power Panel 65 User's manual V2.30...

  • Page 98: Replacement Batteries

    Storage 0 to 95% Transport 0 to 95% Table 26: 0AC201.91, 4A0006.00-000 - Technical data 2.3 Contents of delivery Quantity Component 1 or 4 Lithium batteries Table 27: 0AC201.91, 4A0006.00-000 - Contents of delivery Power Panel 65 User's manual V2.30...

  • Page 99: Tb103 3-Pin Power Supply Connector

    Yes, although applies only if all components installed in the complete system have this certification and are listed on the associated DNV GL certificate for the product family. Cage clamp terminal blocks cannot be used side-by-side. The limit data for each I/O module must be taken into consideration. Power Panel 65 User's manual V2.30...
  • Page 100 Accessories • TB103 3-pin power supply connector 3.3 Contents of delivery Quantity Component Power connector in desired design. Table 30: 0TB103.9, 0TB103.91 - Contents of delivery Power Panel 65 User's manual V2.30...
  • Page 101 Push-in terminal blocks cannot be used side-by-side. The respective limit data of the I/O modules must be taken into account! 4.3 Contents of delivery Quantity Component Terminal in desired design. Table 33: 0TB704.9, 0TB704.91 - Contents of delivery Power Panel 65 User's manual V2.30...
  • Page 102 6 Data storage media For technical data and additional information about storage media, see the corresponding documentation. This can be downloaded from the B&R website (www.br-automation.com) under the respective order number of the storage medium. Power Panel 65 User's manual V2.30...
  • Page 103 Cleaning the label on the back of the unit is only permitted with a dry cloth. This ensures readability of the thermal print during the service life of the device. Information: The display with the touch screen should be cleaned at regular intervals. Power Panel 65 User's manual V2.30...
  • Page 104 • Touch the housing or ground connection in order to discharge any electrostatic charge from your body. • Remove the battery cover from the top of the Power Panel device using a screwdriver (1). Figure 2: Replacing the battery - Removing the battery cover Power Panel 65 User's manual V2.30...
  • Page 105 • Reconnect the power supply to the Power Panel. • Reset the date and time (using B&R Automation Studio). Warning! Lithium batteries are considered hazardous waste. Used batteries should be disposed of in accordance with applicable local regulations. Power Panel 65 User's manual V2.30...
  • Page 106 Rotate the orange CompactFlash safety latch away from the CompactFlash slot (1). Then press the CompactFlash ejection lever (2) with a screwdriver until the CompactFlash card is ejected. The CompactFlash card can now be removed by hand (3). Power Panel 65 User's manual V2.30...
  • Page 107 If inserted incorrectly, the CompactFlash card will not go in all the way and the ejection lever will not extend out. Finally, rotate the safety latch over the CompactFlash slot (3) to secure the CompactFlash card (4). Power Panel 65 User's manual V2.30...
  • Page 108 • Use screensavers (animated) if the display is not in use. • Frequent picture change • Turn off the display when not in use. Turning off the backlight does not help prevent screen burn-in. Power Panel 65 User's manual V2.30...
  • Page 109 Electronics recycling Operating and monitoring devices Uninterruptible power supplies Batteries and rechargeable batteries Cables Paper/Cardboard packaging Paper/Cardboard recycling Plastic packaging material Plastic recycling Disposal must be carried out in accordance with applicable legal regulations. Power Panel 65 User's manual V2.30...
  • Page 110 Abbreviations Power Panel 65 User's manual V2.30...
  • Page 111 A normally open relay contact To be defined Used in technical data tables when certain information is not yet available. The value will be provided later. Table 37: Abbreviations used in this user's manual Power Panel 65 User's manual V2.30...
  • Page 112 Model number index 0AC201.91................................98 0TB103.9................................99 0TB103.91................................99 0TB704.9................................101 0TB704.91................................101 4A0006.00-000............................... 98 4PP065.0351-P74..............................19 4PP065.0351-X74..............................28 4PP065.0571-P74..............................36 4PP065.0571-P74F..............................52 4PP065.0571-X74..............................45 4PP065.0571-X74F..............................61 4PP065.IF10-1............................... 70 4PP065.IF23-1............................... 72 4PP065.IF24-1............................... 76 4PP065.IF33-1............................... 80 Power Panel 65 User's manual V2.30...

This manual is also suitable for:

Pp65

Table of Contents
