HYBRID

SOLARINVERTERS

Powering Tomorrow, Today!

USER MANUAL

Solar Hybrid Inverter

R6KL1D-G2 | R8KL1D-G2

6000W | 8000W | | 230VAC/50Hz | Lithium/Lead Acid | 48VDC

500VDC | Max. 7500W / Max. 12000W

Supplied with CT & WIFI Dongle | Supports Paralell Operation

Table of Contents

Need help?

Do you have a question about the R3KL1D-G2 and is the answer not in the manual?

Questions and answers

Summary of Contents for SupaSol R3KL1D-G2

Page 1 HYBRID SOLARINVERTERS Powering Tomorrow, Today! USER MANUAL Solar Hybrid Inverter R6KL1D-G2 | R8KL1D-G2 6000W | 8000W | | 230VAC/50Hz | Lithium/Lead Acid | 48VDC 500VDC | Max. 7500W / Max. 12000W Supplied with CT & WIFI Dongle | Supports Paralell Operation...
Page 2: Notes On This Manual
Powering Tomorrow, Today! 1. NOTES ON THIS MANUAL 1.1 SCOPE OF VALIDITY This manual is an integral part of Energy storage inverter, it describes the assembly, installation, commissioning, maintenance, and failure type of the product. Please read it carefully before operating.
Page 3: Target Group
Powering Tomorrow, Today! 1.2 TARGET GROUP This manual is for qualified electricians. The tasks described in this manual only can be performed by qualified electricians. 1.3 SYMBOLS USED The following types of safety instructions and general information appear in this document as described below: Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 4: Important Safety Instructions
Powering Tomorrow, Today! 2. SAFETY 2.1 IMPORTANT SAFETY INSTRUCTIONS DANGER! • Danger to life due to high voltages in the inverter! • All work must be carried out by qualified electrician. • The appliance is not to be used by children or persons with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
Page 5 Powering Tomorrow, Today! 2. SAFETY WARNING! • Authorized service personnel must disconnect both AC and DC power from inverter before attempting any maintenance or cleaning or working on any circuits connected to inverter. WARNING • Do not operate the inverter when the device is running. WARNING •...
Page 6 Powering Tomorrow, Today! 2. SAFETY • Never touch either the positive or negative pole of PV connecting device. Strictly prohibit touching both at the same time. • The unit contains capacitors that remain charged to a potentially lethal voltage after the MAINS, battery and PV supply has been disconnected.
Page 7 Powering Tomorrow, Today! 2. SAFETY • To protect the DC system, surge suppression device (SPD type2) should be fitted at the inverter end of the DC cabling and at the array located between the inverter and the PV generator, if the voltag e protection level (VP) of the surge arrester is greater than 1100V, an additional SPD type 3 required for surge protection for electrical devices.
Page 8: Explanation Of Symbol
Powering Tomorrow, Today! 2. SAFETY Incorrect grounding can cause physical injury, death or equipment malfunction and increase electromagnetic. • Battery Safety Instructions Hybrid Series inverter should be worked with low voltage battery, for the specific parameters such as battery type, nominal voltage and nominal capacity etc., please refer to section 4.3. As accumulator batteries may contain potential electric shock and short circuit current danger,to avoid accidents that might be thus resulted, the fol lowing warnings should be observed during battery replacement: 1.
Page 9: Battery Maintenance
Powering Tomorrow, Today! 2.3 MAINTENANCE RELATED INFORMATION The maintenance instructions should include the following content: • Intervals and instructions for any Preventive maintenance required to maintain safety (For example, replacing the air filter or regularly retightening the terminals) • Instructions for accessing the operator’s access area (if present), including warning not to enter other areas of the equipment •...
Page 10 Powering Tomorrow, Today! 2.5 LOW VOLTAGE EARTH ING SYSTEM The grounding of the power system is directly related to the personal and property safety of users, as well as the normal operation of electrical and electronic equipment.According tothe regulations of International Electrotechnical Commissi on (IEC), low voltage distribution system is called TT system, TN system and IT system according to different grounding modes.
Page 11 Powering Tomorrow, Today! 2.5.1 TN SYSTEM 3)TN-C-S system In the whole system, N line and PE line are usually integrated only before the power incoming point of low voltage electrical device, and they are divided into two lines after the power incoming point 2.5.2 TT SYSTEM TT system is a system where the neutral point of the power supply is directly grounded, and the exposed conductive part of the electrical equipment is also directly grounded.The grounding of the neutral point of...
Page 12: Basic Features
Powering Tomorrow, Today! 2.5.3 IT SYSTEM IT system is a system where the neutral point of the power supply is not grounded, and the exposed conductive part of the electrical equipment is directly grounded.IT system can set neutral wires, but IEC does not recommend setting neutral wires .If a neutral line is set and a ground fault occurs at any point of the N line in the IT system, the system will no longer be an IT s ystem.
Page 13: System Diagram
Powering Tomorrow, Today! 3.2 SYSTEM DIAGRAM R3KL1 G2~R8KL1 G2 R3KL1 AC~R8KL1 A All switches and RCD devices in the figure are for reference only, and the specific installation shall be subject to local regulations. Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 14 Powering Tomorrow, Today! 3.2 SYSTEM DIAGRAM NOTE! • Please control the home loads, and make sure it’s within the “BACK UP output rating” under BACK UP mode, otherwise the inverter will shut down with an “overload fault” warning. • Please confim with the mains grid operator whether there is any special regulations for grid connection.
Page 15: Work Modes
Powering Tomorrow, Today! 3.3 WORK MODES Schematic diagram Inverter provides multiple work modes based on different requirements. Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 16 Powering Tomorrow, Today! 3.3 WORK MODES NOTE! • If set anti-Reverse function allowable, Once on the work mode of Self use, Peak shift, battery priority,the system will not feed power to grid. Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 17 Powering Tomorrow, Today! 3.4 DIMENSION 1) Energy storage inverter with LED indicator light R8KL1-G2: 2) Energy storage inverter with color screen R8KL1-G2: Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 18 Powering Tomorrow, Today! 3.5 TERMINALS OF PV INVERTER NOT CURRENTLY SUPPORTED WARNING! Qualified electrician will be required for the installation. Not currently supported Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 19 Powering Tomorrow, Today! 3.5 TERMINALS OF PV INVERTER NOT CURRENTLY SUPPORTED Port Function Qualified electrician will be required for the installation. • CAN1/CAN2: Communication interface for connecting inverter. • CAN_BMS/485_ BMS: BMS communication for lithium batteries. • CT: For external grid side CT to detect current size. •...
Page 20: Technical Parameters
Powering Tomorrow, Today! 4. TECHNICAL PARAMETERS 4.1 INVERTER SPECIFICATION R3KL1 ( G2~R8KL1 ( G2 Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 21 Powering Tomorrow, Today! 4. TECHNICAL PARAMETERS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 22 Powering Tomorrow, Today! 4. TECHNICAL PARAMETERS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 23 Powering Tomorrow, Today! 4. TECHNICAL PARAMETERS R3KL1 ( AC ~R8KL1 ( AC Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 24 Powering Tomorrow, Today! 4. TECHNICAL PARAMETERS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 25 Powering Tomorrow, Today! 4. TECHNICAL PARAMETERS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 26 Powering Tomorrow, Today! 4. TECHNICAL PARAMETERS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 27: Installation
Powering Tomorrow, Today! 5. INSTALLATION 5.1 CHECK FOR PHYSICAL DAMAGE Make sure the inverter is intact during transportation. If there is any visible damage, such as cracks, please contact your dealer immediately. 5.2 PACKING LIST Open the package and take out the product, please check the accessories first .The packing list shown as below.
Page 28 Powering Tomorrow, Today! 5.3 MOUNTING • Installation Precaution Inverter is designed for in door installation (IP 65).Make sure the installation site meets the following conditions: • Not in direct sunlight. • Not in areas where highly Flammable materials are stored. •...
Page 29 Powering Tomorrow, Today! 5.3 MOUNTING • Installation Tools required for installation. Installation tools : crimping pliers for binding post and RJ45, screwdriver, manual wrench etc Step 1: Drill 3 holes on the wall with a depth of 50 60mm based on the following distance dimensions.
Page 30 Powering Tomorrow, Today! 5.3 MOUNTING Step 3: Tighten the screws on the right hanging bracket. Step 4: Remove the wiring waterproof box under the machine using a cross screwdriver .(The following figure shows an 8KW energy storage inverter with a color screen and LED indicator light) Step 5: After installation, to ensure that the machine does not fall off, please double check if the machine is fixed to the rack...
Page 31: Electrical Connection
Powering Tomorrow, Today! 6. ELECTRICAL CONNECTION 6.1 PV CONNECTION Energy storage inverter can be connected in series with 2/3 strings PV modules for 3kW, 3.6kW, 4kW,4.6 k W ,5 Kw,6Kw, 8kW.Select PV modules with excellent function and reliable quality. Open circuit voltage of module arrays connected in series should be <Max . DC input voltage; operating voltage should be conformed to MPPT voltage range.
Page 32 Powering Tomorrow, Today! 6.1 PV CONNECTION CONNECTION STEPS: Step 1 : Checking PV Module Use multimeter to measure module array voltage. 2. Check the PV+ and PV from the PV string combiner box correctly. 3. Please make sure the impedance bewteen the positive pole and negative pole of PV to earth. (Warning:should be M Ω...
Page 33 Powering Tomorrow, Today! 6.1 PV CONNECTION Step 5: Plug the PV conntector into the corresponding PV connector on inverter. 6.2 GRID CONNECTION (GEN CONNECTION) Step 1: Check the grid voltage. Check the grid voltage and compare with the permissive voltage range (Please refer to technical data).
Page 34 Powering Tomorrow, Today! 6.1 PV CONNECTION 2. Choose the wire to connect with the cold-pressed terminal.(Remove 18mm of insulation from the end of wire.) 3. Insert the stripped wire into asuitable tube terminal. Press the tube terminal on cable conductor core tightly with a hexagonal wrench.
Page 35 Powering Tomorrow, Today! 6.3 BACK UP:LOAD CONNECTION Load port: When the battery is not sufficient, the load on this interface will power down 1) For inverter, the standard PV installation typically consists of the connection of the inverter with both panels and batteries.
Page 36 Powering Tomorrow, Today! 6.3 BACK UP:LOAD CONNECTION NOTE! In case of discrepancies between wiring mode of local policy and theoperation guide above especially for the wiring of neutral line, grounding and RCD, please contact us before any operation! - Back- Up: Load Connection: When using the off grid function, please add off grid AC breaker in off grid output cable to ensure safety.
Page 37 Powering Tomorrow, Today! 6.3 BACK UP:LOAD CONNECTION NOTE! The absence of AC breaker on back up side will lead to inverter damage if an electrical short circuit happens on back up side. Step 1: Make BACK UP wires. Step 2: Connect the cables to the BACK UP:Load port of the inverter.
Page 38: Battery Connection
Powering Tomorrow, Today! 6.3 BACK UP:LOAD CONNECTION - Requirements for BACK-UP load WARNING! • Make sure the BACK-UP load power rating is within BACK UP output rating, otherwise the inverter will shut down with an“over load” warning. • When an “over load” is appeared, adjust the load power to make sure it is within the BACK-UP output power range, then turn the inverter back on.
Page 39 Powering Tomorrow, Today! 6.4 BATTERY CONNECTION - Battery connection diagram - Power Connection Battery 1) Choose the appropriate wire. Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 40 Powering Tomorrow, Today! 6.4 BATTERY CONNECTION 2) Strip the cable to 15mm and select two O-terminals with an aperture of M4.Insert the stripping line into the O terminal and clamp it with a crimping clamp. 3) Strip the cable to 15mm and select two O-terminals with an aperture of M4.Insert the stripping line into the O terminal and clamp it with a crimping clamp.
Page 41 Powering Tomorrow, Today! 6.4 BATTERY CONNECTION - BMS PIN Definition Communication interface between inverter and battery is RS485 or CAN with a RJ45 connector. When using RS485 protocol, please note that PIN2 must be disconnected! NOTE! The battery communication can only work when the battery BMS is compatible with the inverter.
Page 42 Powering Tomorrow, Today! 6.5 COLOR SCREEN OPERATION GUIDANCE 6.5.1 HOME PAGE Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 43: Working Status
Powering Tomorrow, Today! 6.5.2 WORKING STATUS 1) ENERGY STORAGE INVERTER Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 44 Powering Tomorrow, Today! 6.5.2 WORKING STATUS 2) PV 3) GRID Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 45 Powering Tomorrow, Today! 6.5.2 WORKING STATUS 4) BATTERY Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 46 Powering Tomorrow, Today! 6.5.2 WORKING STATUS 5) LOAD LOAD PAGE ONE LOAD PAGE TWO Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 47 Powering Tomorrow, Today! 6.5.2 WORKING STATUS 6) GENERATOR Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 48 Powering Tomorrow, Today! 6.5.3 SETTING - ENTER SETTING 1) INPUT PASSWORD 2) ENTER THE SETTINGS INTERFACE Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 49 Powering Tomorrow, Today! 6.5.3 SETTING SETTING OPTION 1)SYSTEM SETTING SYSTEM SETTING/ PAGE ONE: Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 50 Powering Tomorrow, Today! 6.5.3 SETTING Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 51 Powering Tomorrow, Today! 6.5.3 SETTING Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 52 Powering Tomorrow, Today! 6.5.3 SETTING SYSTEM SETTING/ PAGE TWO: Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 53 Powering Tomorrow, Today! 6.5.3 SETTING SYSTEM SETTING/PAGE THREE: SYSTEM SETTING/PAGE FOUR: Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 54: Parallel Setting
Powering Tomorrow, Today! 6.5.3 SETTING 2)PARALLEL SETTING Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 55: Battery Settings
Powering Tomorrow, Today! 6.5.3 SETTING 3)BATTERY SETTINGS BATTERY SETTINGS/PAGE ONE Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 56 Powering Tomorrow, Today! 6.5.3 SETTING BATTERY SETTINGS/PAGE TWO ated capacity Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 57: Grid Settings
Powering Tomorrow, Today! 6.5.3 SETTING 4)GRID SETTINGS BATTERY SETTINGS/PAGE ONE Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 58 Powering Tomorrow, Today! 6.5.3 SETTING GRID SETTING PAGE TWO Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 59 Powering Tomorrow, Today! 6.5.3 SETTING GRID SETTING PAGE THREE GRID SETTING PAGE FOUR Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 60 Powering Tomorrow, Today! 6.5.3 SETTING 5)GENERATOR SETTING Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 61: Machine Information
Powering Tomorrow, Today! 6.5.3 SETTING 6)MACHINE INFORMATION MACHINE INFORMATION PAGE ONE MACHINE INFORMATION /PAGE TWO Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 62: Wifi Connection (Optional)
Powering Tomorrow, Today! 6.6 LED GUIDANCE B B A A T T G G r r i i d d N N o o r r m m a a l l G G r r e e e e n n ...
Page 63: Bluetooth Connection (Optional)
Powering Tomorrow, Today! 6.7 WIFI CONNECTION (OPTIONAL) 2)WIFI CONNECTION : Step 1 : Plug WiFi into WiFi port at the bottom of the inverter. Step 2 : Build the connection between the inverter and router. Step 3 : Create a user account online.(Please check the WiFi user manual for more details). 6.8 BLUETOOTH CONNECTION (OPTIONAL) If you need to set a mode, check the device status You can connect locally via Bluetooth Inverter provides a WiFi Bluetooth included port which can collect data from inverter and transmit it to mobile terminal...
Page 64 Powering Tomorrow, Today! 6.8 BLUETOOTH CONNECTION (OPTIONAL) Step 4: Click local Mode, The scan code is added or Enter SN code. As shown in the figure Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 65: Gprs Connection
Powering Tomorrow, Today! 6.9 GPRS CONNECTION (OPTIONAL) Energy storage inverter provides a GPRS( radio frequency) interface which control the switch time of a designated load via an exteral Smart Plug (purchase the product from supplier if needed.) so that the load mostly consumes PV energy and incurs the lowest possible energy costs during operation.
Page 66 Powering Tomorrow, Today! 6.10 CT INSTALLATION INSTRUCTIONS CT is short for current transform is used to detect G rid current. NOTE! • If CT is not installed or installed reversely, the functions of “Anti reflux”, “Self-use”, “Peak-shift “… will not be realized. •...
Page 67: App Operation
Powering Tomorrow, Today! 6.10 CT INSTALLATION INSTRUCTIONS 7. APP OPERATION 7.1 HOME PAGE Language switching Home Page includes Wi Fi configuration ,Logger Diagnosis,Local Mode, (Users can click on the upper right corner to switch languages),Change API. Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 68 Powering Tomorrow, Today! 7.1 HOME PAGE When using the Smart SetApp, our main goal is to be able to view the relevant status of the device in real time and wirelessly control the device.Two connection methods are provided for users, namely IOT remote mode (Users configu re-according to the user manual for solarman Smart APP) and local mode.
Page 69: Local Mode
Powering Tomorrow, Today! 7.2 LOCAL MODE 7.2.1 ADD A LOGGER Method 1: Enter logger SN manually. Method 2: Click the icon in the right and scan to enter logger SN.You can find logger SN in the external packaging or on the logger body. Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 70 Powering Tomorrow, Today! 7.2 LOCAL MODE 7.2.2 BLUETOOTH ON Local mode supports Bluetooth connection.Users can turn on Bluetooth in advance ,or add a logger first and then turn on Bluetooth according to the page prompts.If the connection fails, the user needs to reconnect.
Page 71 Powering Tomorrow, Today! 7.2 LOCAL MODE 7.2.3 ENTER THE LOCAL MODE INTERFACE Users can view the device’s working status and set parameters 7.2.4 WORKING STATUS Users can view the working status of devices on the APP, including Solar , grid, B attery, Load, other (Display software version, SN code, fault information, working mode, device temperature, inverter temperature, etc,),I nver sion,BMS,GEN,DEBUG,HomeLoad,Parallel 3Phase.
Page 72: Set Parameters
Powering Tomorrow, Today! 7.2 LOCAL MODE 7.2.5 SET PARAMETERS Users can set the working parameters of the device according to their needs .The parameters set by the user need to be within the specified range. 1) GRID SETTINGS AND GRID PROTECT SET Entering the grid settings requires entering a password.
Page 73: Active Control
Powering Tomorrow, Today! 7.2 LOCAL MODE 2) BATTERY SET , BATTERY MANAGEMENT-CUSTOM MODEL AVAILABLE AND BATTERY 485 COMMUNICATION PARAMETER 3) ACTIVE CONTROL Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 74 Powering Tomorrow, Today! 7.2 LOCAL MODE 4) SETUP AND ADVANCE In the Setup interface, users can set work mode and PV input type, language, date/time, etc 5)PEAK SHIFT Setting of charging and discharging time for Peak Shift.When the working mode is Peak Shift, users need to enter this interface to set the charging and discharging time.And Users need to manually input the start charge/discharge time and the end charge/discharge time.
Page 75 Powering Tomorrow, Today! 7.2 LOCAL MODE 6) Parallel Set ,Generator Set, Advance Work Mode Set, Custom Function and AC Couple Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 76: Fault Diagnosis And Solutions
Powering Tomorrow, Today! 8. FAULT DIAGNOSIS AND SOLUTIONS The inverter is easy to maintain. When you encounter the following problems, please refer to the Solutions below, and contact the local distributor if the problem remains unsolved. The following table lists some of the basic problems that may occur during the actual operation as well as their corresponding basic solutions.
Page 77 Powering Tomorrow, Today! 8. FAULT DIAGNOSIS AND SOLUTIONS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 78 Powering Tomorrow, Today! 8. FAULT DIAGNOSIS AND SOLUTIONS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 79 Powering Tomorrow, Today! 8. FAULT DIAGNOSIS AND SOLUTIONS Longmeadow: 010 202 3300 | Germiston: 011 418 9600 | Cape Town: 021 492 2000 | Riverhorse: 031 492 4800 | Pinetown: 031 700 4215...
Page 80 Powering Tomorrow, Today! 8. FAULT DIAGNOSIS AND SOLUTIONS NOTE! If an error occurs that is not listed in the table, Please Contact customer service. NOTICE: The information in this document includ ing software, etc. is subject to change without notice. Every effort has been made to ensure the accuracy of the contents during the preparation of this document, but all statements, information and suggestions in this document do not constitute any express or implied warranty in any form.
