WaterBridge Thermostatic Exposed Showers are available in four standard wall-mounted configurations:
WB-SHW-940
WB-SHW-950
WB-SHW-970
WB-SHW-980
Custom showers are available by special order. Please contact Sonoma Forge for more info.
MODEL
940
It is strongly recommended that this, and all fixtures, be installed by a professional plumber.
Waterbridge Thermostatic Exposed Showers are installed onto 3/4" pipe thread, 10-3/4" center-to-center.
Oct 2017
Rain head only
Rain head and handshower
Rain head and tub filler / footwash
Rain head, handshower, and tub filler / footwash
MODEL
950
|
800.330.5553
f 707.789.9201
INSTALLATION GUIDE
Waterbridge 900-Series Exposed Showers
MODEL
970
|
info@sonomaforge.com
MODEL
980
Advertisement
Summary of Contents for Sonoma Forge Waterbridge 900 Series
- Page 1 Rain head and handshower WB-SHW-970 Rain head and tub filler / footwash WB-SHW-980 Rain head, handshower, and tub filler / footwash Custom showers are available by special order. Please contact Sonoma Forge for more info. MODEL MODEL MODEL MODEL It is strongly recommended that this, and all fixtures, be installed by a professional plumber.
- Page 2 INSTALLATION GUIDE Waterbridge 900-Series Exposed Showers Oct 2017 800.330.5553 f 707.789.9201 info@sonomaforge.com...
- Page 3 INSTALLATION GUIDE Waterbridge 900-Series Exposed Showers Oct 2017 1) Determine a height for the rain head. The face of the rain head is 36” from the center of the inlets. 2) Additional framing should be installed in the wall behind the mounting bracket for support. 3) Plumb 3/4"...
- Page 4 11) Check volume controls and shut-off valves for proper function. Care & Maintenance: No abrasives should be used to clean Sonoma Forge products. Mild soap and water can be used, and 100% carnauba wax can be applied to protect the finish.
