MODEL 8TDB FOR THE 4'x4' SINGLE BLIND
Quantity
MODEL 8TDB
IMPORTANT NOTICE
User is responsible for proper assembly, setup & anchoring
Updated July 2018
PARTS LIST FOR 8 FT. TOWER / SINGLE BLIND
Part Name
4
8 T L
4
M 8
4
N 8
4
O 8
4
J
2
P
7
Q
1
U
18
Bolt
18
Lock Washer
18
Nut
48
Bolt
48
Lock Washer
48
Nut
4
U Bolt
© Copyright 2018, Texas Hunter Products, Inc. Questions? Call (800) 969-3337
Texas Hunter Products
3350 IH 35 North
San Antonio, TX 78219
210-734-5189 800-969-3337
www.TexasHunter.com
Description
2" Angle Legs
1" Angle Horizontal Braces (Lower)
1" Angle Horizontal Braces (Upper)
1" Angle Diagonal Braces
Feet
3/4" Angle Ladder Runners
3/4" Angle Ladder Rungs
Hand Bar
1/4" x 3/4" Bolt
1/4" Split Lock Washer
1/4" Hex Nut
5/16" x 3/4" Bolt
5/16" Split Lock Washer
5/16" Hex Nut
5/16" "U" Bolts w/Hardware to
Secure Ladder to Tower Braces
Page 1 of 5
Advertisement
Summary of Contents for TEXAS HUNTER 8TDB
- Page 1 5/16” “U” Bolts w/Hardware to U Bolt Secure Ladder to Tower Braces MODEL 8TDB IMPORTANT NOTICE Page 1 of 5 User is responsible for proper assembly, setup & anchoring Updated July 2018 © Copyright 2018, Texas Hunter Products, Inc. Questions? Call (800) 969-3337...
- Page 2 Tower assembly until all bolts are installed. Step 1: Attach the (8TL) Legs to the Blind Assembly. (Figure 1 ) Figure 1 Page 2 of 5 Updated July 2018 © Copyright 2018, Texas Hunter Products, Inc. Questions? Call (800) 969-3337...
- Page 3 Diagonal Bracing meets Upper Horizontal Bracing (N 8) on all four sides. (Figure 3) Step 4: Attach the (J) Feet (Figure 3) Step 5: Tighten all bolts/nuts securely. Figure 2 Figure 3 Page 3 of 5 Updated July 2018 © Copyright 2018, Texas Hunter Products, Inc. Questions? Call (800) 969-3337...
- Page 4 Attach top two holes in ladder runners using existing bolts used to attach the “Z” plate, underneath the blind (opposite the “Z” and behind the angle iron supporting the floor). (Fig. 4). Step 8: Tighten all bolts/nuts securely. Page 4 of 5 Updated July 2018 © Copyright 2018, Texas Hunter Products, Inc. Questions? Call (800) 969-3337...
- Page 5 Page 5 of 5 IMPORTANT: After placing the blind/tower into position, it must be anchored. Updated July 2018 Updated July 2018 © Copyright 2018, Texas Hunter Products, Inc. Questions? Call (800) 969-3337 © Copyright 2018, Texas Hunter Products, Inc. Questions? Call (800) 969-3337...
- Page 6 The cables should criss-cross. See Figure 2. 8. Adjust the turnbuckles to remove slack from cables. Figure 1 Figure 2 DANGER! Do not use blind in high wind conditions. Thank you for choosing Texas Hunter Products. Questions? Call us at 800.969.3337 www.TexasHunter.com...
