- Page 1 NOVA-AFCP-RP INTELLIGENT ADDRESSABLE FIRE DETECTION CONTROL REPEATER PANEL AFCP-RP INSTALLATION AND USER GUIDE WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE OPERATING OR PUTTING THE DEVICE INTO OPERATION...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................................2 FUNCTIONAL SPECIFICATIONS ............................. 2 2.1. PRODUCT FEATURES (TABLE-1) ..........................3 TECHNICAL SPECIFICATIONS ..............................3 SAFETY AND INSTALLATION ..............................4 PUTTING INTO OPERATION ..............................5 PANEL INDICATOR VE CONTROL KEYS ..........................6 6.1. LED Indicators ................................ 11 6.2. -
Page 3: Introduction
Nova series panels. 2. FUNCTIONAL SPECIFICATIONS NOVA-AFCP-RP can take any address between 1 and 96 as one of up to 96 usable parts of the network. • It can work as a Loop or Line in the network. The repeater panel receives and displays data from all panels on the network. -
Page 4: Safety And Installation
4. SAFETY AND INSTALLATION Installation must only be done by authorized personnel. Make sure that the panel has not been damaged due to poor shipping or improper storage. Please pay attention to the permissible environmental conditions. • Do not install in environments that may be exposed to dust and high temperatures. •... -
Page 5: Putting Into Operation
5. PUTTING INTO OPERATION NOVA-AFCP-RP can take any address between 1 and 96 as one of up to 96 usable parts of the network. It can operate as a Loop or Line in the network. The first thing to do is to assign an unused ID to the repeater panel in the network. -
Page 6: Led Indicators
6.1. LED Indicators System Fault LED (Yellow) The system fault led becomes active when the SD card fails, the voltage of the panel drops below 20 Volts or the microprocessor fails. In case of fault, the buzzer is activated as an audible warning. Power Fault LED (Yellow) When there is no mains voltage, it becomes active together with the general fault led. - Page 7 Siren Active / Mute Button Depending on the panel model connected to the network, Siren 1, Siren 2, Siren 3 and Siren 4 outputs and AS, AB, ASB and SAM devices connected to the loops, control of the device w/ relay and Sensor PIL control in Menu 4.7 on the main panels, including devices w/ relays and PILs activated from the menu, are enabled or muted when the the siren active/mute button is pressed.
-
Page 8: Logs
7. HOW TO USE THE PANEL MENU AND ITS FEATURES MAIN DISPLAY TIME PANEL NAME DATE LINE 25/09/20 7:46 NOVA AFCP-RP LINE ALARM:(0000) ERROR:(0000) MSG:(0000) LINE LINE When the panel is energized for the first time, current alarms, errors and messages are checked. If there are any notifications, they are displayed on the main screen. - Page 9 : Log Number INFO : Log Information 7.1.1.1. ACTIVE ALARM In this menu, current (active) alarm logs are displayed. Scroll through the logs with the Up/Down buttons. If there is no current alarm, the warning screen is displayed stating that there is no log. If there are any current alarms, the log information screen is displayed.
-
Page 10: Configuration
07:46 NOVA AFCP-RP 25/09/2020 2.1 - REPETITIVE CONFIGURATION 2.2 - RELAY CONFIGURATION 2.3 – CONFIGURATION: PASSWORD Detail viewing menu screen display 07:46 NOVA AFCP-RP 25/09/2020 2.4 - REPETITIVE CONFIGURATION 2.5 - RELAY CONFIGURATION 2.6 - CONFIGURATION: PASSWORD 07:46 NOVA AFCP-RP 25/09/2020 2.1 –... - Page 11 7.2.1.2. SET : REPETER NAME A new name can be assigned to the repeater panel from this menu. After entering the menu, type the desired name with the alphanumeric keys and forward and backward keys and press the OK button. After the confirmation screen, the operation takes place and returns to the main screen.
-
Page 12: Configuration: Password
7.2.3. CONFIGURATION : PASSWORD This menu is used to change the access passwords. Follow the menu steps. 7.2.4. CONFIGURATION : TIME / DATE This menu is used to adjust time and date. 7.2.4.1. SET : TIME After entering this menu, confirm with the OK button and follow the menu steps. Enter the hour and minute information with the alphanumeric keys. -
Page 13: Configuration: Language
7.2.6. CONFIGURATION : LANGUAGE This menu is used to change the panel language. There are 6 different languages and a total of 12 options for each language, either uppercase or all lowercase. Arrow keys are used to make selections. 7.2.6. CONFIGURATION : VOLTAGE In this menu, the supply, system and grounding voltage values are displayed on the screen. -
Page 14: Repeater Card Features
REPEATER CARD FEATURES 1. ALARM RELAY A The dry contact output connection terminal that is active in case of fire 2. ALARM RELAY B The dry contact output connection terminal that is active in case of fault 3. FAULT RELAY Panel supply socket from network card 4. -
Page 15: Repeater Panel Connections
REPEATER PANEL CONNECTIONS ACCESS PASSWORDS AND LEVELS LEVEL INFO PASSWORD LEVEL 1 PASSWORD NOT REQUIRED LEVEL 2 MONITORING & FOLLOW-UP 1991 LEVEL 3 PUTTING INTO OPERATION 2016 LEVEL 4 CUSTOM SETTINGS 7007 LEVEL 5 TECHNIC CONTACT THE MANUFACTURER LEVEL 6 ENGINEERING &... - Page 16 Republic of Turkey, Ministry of Trade, Turkish Competition Authority. MANUFACTURER / IMPORTER COMPANY TITLE : ELEKS ELEKTRİK ELEKTRONİK SİSTEMLERİ SANAYİ VE TİCARET LİMİTED ŞİRKETİ ADDRESS: Şerifali Mah. Bayraktar Cad. Emin Sok. No:3 Y.Dudullu - Ümraniye / ISTANBUL : 0216 463 47 28-29- 30...
- Page 17 WARRANTY TERMS AND CONDITIONS The warranty period starts from the delivery date of the product and is 2 (two) years. The entire product, including all parts, is under the guarantee of our company. In case of malfunction of the product within the warranty period, the time spent in the repair is added to the warranty period.
