❶ Home Screen
Battery Type
❻
Load Operating Mode
❺
Display Interface Parameter Setting
Browser Interface
Short press on the menu key
to cycle through the various
sectors and parameters.
Setting Parameters
Under the interface 2-6 Press
the menu key to modify the
parameter settings at this time
the number will blink, press the
up and down keys to adjust
the
automatically return to the
main interface of the voltage
display after 3 seconds after
completion.
value,
and
then
❷ Float Charge Voltage
Discharge Recovery Voltage
❸
Discharge Cutoff Voltage
❹
Advertisement
Related Manuals for PowerHome PH-PWM-10
Summary of Contents for PowerHome PH-PWM-10
- Page 1 Display Interface Parameter Setting Browser Interface ❷ Float Charge Voltage ❶ Home Screen Short press on the menu key to cycle through the various sectors and parameters. Setting Parameters Under the interface 2-6 Press the menu key to modify the parameter settings at this time the number will blink, press the Discharge Recovery Voltage...
- Page 2 Troubleshooting Guide Anomalies Possible Causes Prescription Sunny but not charging PV panel open or reversed Reconnect the photovoltaic panels Load marking not illuminated Mode setting error Retrieve Battery voltage too low Recharge Load marking slow flash Load overcurrent Reducing load power Load marking flash Short circuit protection Remove short circuit, automatic recovery...
