- Page 1 PERATING NSTRUCTIONS 24 WA3E Series 24 WA23 Series...
-
Page 2: Table Of Contents
Picture .............38 Table of Contents Subtitle.............38 Safety Information ..........2 Supported DVI Resolutions ......... 39 Features ..............4 Wireless LAN Transmitter Specifications .... 40 Stand Installation & Wall Mounting ....... 4 Licences .............. 40 Antenna Connection..........5 Disposal Information ........... 41 Turning On/Off the TV(**) ........ -
Page 3: Safety Information
• Do not expose the TV to direct sunlight or do Safety Information not place open flames such as lit candles on the top of or near the TV. • Do not place any heat sources such as electric CAUTION heaters, radiators, etc. - Page 4 WARNING WALL MOUNTING WARNINGS Do not ingest the battery, Chemical Burn Hazard This product or the accessories supplied with the • Read the instructions before mounting your TV product may contain a coin/button cell battery. If the on the wall. coin/button cell battery is swallowed, it can cause •...
-
Page 5: Features
Options>Settings>Device Preferences>Inputs Introduction menu as EDID 2.1 or Auto EDID in order to watch HDR/HLG content, if the HDR/HLG content is received Thank you for choosing our product. You’ll soon be through an HDMI input. The source device should also enjoying your new TV. -
Page 6: Antenna Connection
Antenna Connection Connect the aerial or cable TV plug to the aerial input (ANT) socket or satellite plug to the satellite input (LNB) socket located on the rear side of the TV. Rear side of the TV If you want to connect a device to the TV, make sure that both the TV and the device are turned off before making any connection. - Page 7 Other Connections If you want to connect a device to the TV, make sure that both the TV and the device are turned off before making any connection. After the connection is done, you can turn on the units and use them. To enable VGA audio, you will need Connector Type...
-
Page 8: Turning On/Off The Tv(**)
consumption. In order to minimise energy consumption Turning On/Off the TV(**) switch your TV into standby mode as explained above. Turning On/Off the TV(**) Connect power IMPORTANT: The TV set is designed to operate on Connect power 220-240V AC, 50 Hz socket. IMPORTANT: The TV set is designed to operate on After unpacking, allow the TV set to reach the ambient 220-240V AC, 50 Hz socket. -
Page 9: Tv Control & Operation(**)
If the TV is in standby mode the standby LED lights To change source in Live TV mode: Press the up. To switch on the TV from standby mode either: centre of the joystick in, the TV options menu will be displayed. - Page 10 will appear on the screen. Scroll through the stored To turn on the TV: Press the control button, the TV channels by pushing the control switch up or down. will turn on. Note: Live TV settings menu OSD in Live TV mode cannot be To turn the TV off (Quick Standby): Press the centre displayed via the control button.
-
Page 11: Remote Control (**)
Standby: Quick Standby / Standby / On Remote Control (**) Numeric buttons: Switches the channel in Live TV mode, enters a number in the text box on the screen Language: Switches among sound modes (analogue TV), displays and changes audio language (digital TV, where available) Volume +/-: Increases/decreases the volume level Microphone: Activates the microphone on the remote if... - Page 12 Remote Control (**) Standby: Quick Standby / Standby / On Numeric buttons: Switches the channel in Live TV mode, enters a number in the text box on the screen Language: Switches among sound modes (analogue TV), displays and changes audio language (digital TV, where available) Mute: Completely turns off the volume of the TV Volume +/-: Increases/decreases the volume level...
-
Page 13: Initial Setup Wizard
If you did priorly connect your TV to the Internet via Initial Setup Wizard Ethernet a message will be displayed stating that you are connected. You can choose to continue with wired Note: Follow the on-screen instructions to complete the initial connection or change the network. - Page 14 which this information can also be viewed, in case 13. Chromecast built-in always available internet access is not available. Select your chromecast availability preference. If set as 9. Google Services On your TV will be detected as a Google Cast device and allow Google Assistant and other services to wake Select each to learn more about each service, such as your TV up to respond to Cast commands, even when...
-
Page 15: Home Screen
If the Satellite option is selected, the Antenna Type LNB Configurations: Set the parameters for LNB. screen will be displayed next. If you have a Direct For DiSEqC antenna type select the correct DiSEqC satellite system, you can proceed to the next step port corresponding to your satellite system. -
Page 16: Live Tv Mode Menu Content
Screen. You can also select the Android TV Home and recommendations from streaming apps. In the option from the Inputs menu to switch to Home Discover tab recommendations from streaming Screen. To open the Inputs menu, press the Source services will be displayed. In the Apps tab, all the button on the remote or press the Menu button on the apps installed on your TV will be displayed and you remote when the TV is in Live TV mode, highlight the... - Page 17 Mute and Standby buttons. These buttons will Cookie Settings: Set your cookie setting function normally. preference for HBBTV services. No Signal Auto Power Off: Set the behaviour of Persistent Storage: Turn the Persistent Storage the TV, when no signal is detected from the currently function on or off.
-
Page 18: Record
Wow: Turn this function on and off. This function allows Record you to turn on or awaken your TV via wireless network. Record List: The recordings will be displayed if any Wol: Turn this function on and off. This function allows available. - Page 19 When the second channel is selected, the position of LCN: Set your preference for LCN. LCN is the Logical this channel will be replaced with the position of the Channel Number system that organises available first selected channel. You can press the Yellow button broadcasts in accordance with a recognisable channel and enter the number of the channel you want to select.
- Page 20 tion. Highlight OK and press OK to proceed. Highlight on the remote. Highlight the desired channel/s on the Cancel and press OK to cancel. list and press OK to select/unselect. Input Source - Satellite Channel Swap: Replace the positions of the two selected channels in the channel list.
-
Page 21: Accounts & Sign In
on the remote. Highlight the desired channel/s on the an operator installation. Set to General Satellite to list and press OK to select/unselect. watch other satellite channels, if you have performed a normal installation. Channel Swap: Replace the positions of the two selected channels in the channel list. -
Page 22: Apps
advertising ID, reset it and turn on/off the personalised Apps advertisings based on your interests. Using the options of this menu, you can manage the Factory reset: Reset all TV settings to the factory apps on your TV. defaults. Highlight Factory reset and press OK. Information on this operation will be displayed, Recently opened apps select Factory reset to proceed with resetting. - Page 23 Power Display Mode: Set the aspect ratio of the screen. Select one of the predefined options according to Sleep Timer: Define a time after which you want your preference. your TV to enter sleep mode automatically. Set as Off to disable. Advanced Video Picture Off: Select this option and press OK to DNR: Dynamic Noise Reduction (DNR) is the...
- Page 24 this option and press OK to turn the ALLM function like spreadsheets or paragraphs or text in smaller on or off. fonts. PC Mode: PC Mode is the mode which cuts down Reset to Default: Reset the video settings to factory some of the picture processing algorithms to keep default settings.
- Page 25 Dolby Audio Processing: Highlight this option You can use this option to format it again in order and press OK to turn this function on/off. Some to use it with other devices. Before proceeding with options may not be available if this option is not the formatting, you may consider backing up the turned on.
-
Page 26: Bluetooth(**) Remotes And Accessories
Chromecast Built-in: Set your remote control notifi- Restart: A confirmation message will be displayed, cation preference. Highlight Let others control your select Restart to proceed with restarting. The TV will cast media and press OK. Always, While Casting switch off/on first. Select Cancel to exit. and Never options will be available. -
Page 27: Programme Guide
the channel list. Available options may differ depending Electronic Programme Guide is available in Live TV on the operator selection. mode. To switch to Live TV mode you can either press the Exit button or highlight the Live TV app from the Note: If any option except All channels is selected in Apps row on the Home Screen and press OK. - Page 28 Broadband ISP connection LAN (Ethernet) cable Broadband ISP connection LAN input on the rear side of the TV A network with hidden SSID (network name) can not be detected by other devices. If you want to connect You might be able to connect your TV to a network to a network with hidden SSID, highlight the Add new wall socket depending on your network’s configuration.
-
Page 29: Multi Media Player
protocol in order to avoid any possible problems while will be displayed in a small window on the left side of watching videos. the screen if the browse mode is set to List View. You can also use Programme +/- buttons to jump directly You must change your modem’s SSID when there are to the first and last folder or file if the view style is set any other modems around with the same SSID. -
Page 30: From Usb Connection
show. The slide show will stop after the last listed file is Rotate: Rotate the image. The image will be rotated displayed and media player screen will be displayed. 90 degrees clockwise each time you press OK. You can also press the Green button to rotate. This option Info: Display the info bar. -
Page 31: Usb Auto Play Feature
This feature is used to start playing the media content function could lead to copyright infringement of installed on a removable device automatically. It uses authors' rights. Toshiba asks you to respect the the Multi Media Player application. The media content intellectual property rights of third parties. -
Page 32: Disk Format
mode. In Manual mode, if you prefer, you can format In order to make use of the CEC functionality the your USB storage device and specify the storage space related option in the menu should be switched on. that will be used for timeshift function. When the setup To check, switch on or off the CEC function, do the is complete, the Disk Setup Result will be displayed. -
Page 33: Hbbtv System
You can get the network name of your TV from the a small red button icon will appear on the screen in Settings>Device Preferences>About menu on the order to notify the user that there is an HbbTV appli- Home screen. Device name will be one of the shown cation on that channel. -
Page 34: Troubleshooting & Tips
No sound / poor sound Troubleshooting & Tips • Make sure that the sound settings are correctly set. TV does not switch on • Make sure that all cables are properly connected. • Make sure the power cord is plugged in securely to •... -
Page 35: Vga Input Typical Display Modes
VGA Input Typical AV and HDMI Signal Display Modes Compatibility The following table is an illustration of some of the Source Supported Signals typical video display modes. Your TV may not support all resolutions. SECAM Composite Index Resolution Frequency / Back AV NTSC4.43 NTSC3.58 640x480... -
Page 36: Supported File Formats For Usb Mode
Supported File Formats for USB Mode Video Decoder Video Codec Resolution Bit Rate Profile Container Profile 0 (420 8-bit) 4096x2176@60fps 100Mbps MKV (.mkv), WebM (.webm) Profile 2, (420, 10-bit) Main (8-bit)/Main10 MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), (10-bit) MPEG transport stream (.ts, .trp, .tp), HEVC/H.265 4096x2176@60fps 100Mbps... -
Page 37: Video Encoder
Video Encoder Max Bit Video Codec Max Resolution Profile Note Rate H.264 1920x1080@30fps 12Mbps Main profile, level 4.1 Hardware video encoder Audio Audio Codec Sample rate Channel Bit Rate Container Note MP3 (.mp3), AVI (.avi), ASF (.asf), WMV (.wmv), MKV (.mkv, .mka), 3GPP (.3gpp, .3gp), MP4 (.mp4, 32Kbps ~ MPEG1/2 Layer1... - Page 38 Audio Codec Sample rate Channel Bit Rate Container Note ASF (.asf), WMV (.wma, .wmv), WMA 10 Pro M1 8KHz ~ 48KHz Up to 5.1 < 384Kbps AVI (.avi), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov) ASF (.asf), WMV (.wma, .wmv), WMA 10 Pro M2 8KHz ~ 96KHz Up to 5.1 <...
-
Page 39: Picture
Picture Resolution Image Photo (width x height) Base-line 15360 x 8640 JPEG Progressive 1024 x 768 9600 x 6400 9600 x 6400 6400 x 4800 WebP 3840 x 2160 HEIF 4000 x 3000 Subtitle Internal File Extension Container Subtitle Codec DVB Subtitle Teletext ts, trp, tp... -
Page 40: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using a DVI converter cable (DVI to HDMI cable - not supplied), you can refer to the following resolution information. 56Hz 60Hz 66Hz 70Hz 72Hz 75Hz 640x480 800x600 1024x768 1280x768 1280x960 1360x768... -
Page 41: Wireless Lan Transmitter Specifications
use of such marks by Vestel Elektronik Sanayi ve Wireless LAN Transmitter Ticaret A.S. is under licence. Other trademarks and trade names are those of their respective owners. Specifications DVB is a registered trademark of the DVB Project. Max Output [1] EIA/CEA-861-D compliance covers the transmission Frequency Ranges Power... -
Page 42: Disposal Information
Disposal Information The following information is only for EU-member states: Disposal of products The crossed out wheeIed dust bin symbol indicates that products must be collected and disposed of separately from household waste. Integrated batteries and accumulators can be disposed of with the product. They will be separated at the recycling centres. -
Page 43: Reach Information
Restriction of Chemicals), entered into force on 1 June 2007. Toshiba will meet all REACH requirements and is committed to provide our customers with information about the presence in our articles of substances included on the candidate list according to REACH regulation.
