User Manual
Mars Eco 6 & 10 kVA
R/T & Tower
200/210/220/230/240 Online UPS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mars Eco MS-ECO6002 and is the answer not in the manual?

Questions and answers

Related Manuals for Abrelex Mars Eco MS-ECO6002

Summary of Contents for Abrelex Mars Eco MS-ECO6002

  • Page 1 User Manual Mars Eco 6 & 10 kVA R/T & Tower 200/210/220/230/240 Online UPS...
  • Page 2 SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. The UPS models that are covered in this manual are intended for installation in an environment within 0 to 50°C, free of conductive contaminant. Certification standards •...
  • Page 3 Safety of persons RISK OF VOLTAGE BACKFEED. The system has its own power source (the battery). ⚫ Isolate the UPS and check for hazardous voltage upstream and downstream during lockout-tagout operation. Terminal blocks may be energized even if the system is disconnected from the AC power source. Dangerous voltage levels are present within the system.
  • Page 4 An additional AC contactor is used for back feed protection and must comply ⚫ with IEC/EN 62040-1 (the creep age and clearance distances shall meet the basic insulation requirements for pollution degree 2). Disconnection and overcurrent protection devices shall be provided by others ⚫...

  • Page 5: Table Of Contents

    Contents 1. Introduction ....................1 1.1 Environmental protection ................1 2. Presentation ....................3 2.1 Front panel ....................... 3 2.2 Rear panels ...................... 4 2.3 Circuit diagram ....................6 3. Installation ....................7 3.1 Inspecting the equipment ................7 3.2 Unpacking the Unit ..................7 3.3 Checking the accessory kit ................
  • Page 6 7.4 Replacing batteries..................41 7.5 Recycling the used equipment ................ 42 8. Troubleshooting ..................43 8.1 Typical alarms and faults................43 8.2 Silencing the alarm ..................47 9. Specifications ..................... 48 9.1 Model specifications ..................48 10 Glossary ....................53...

  • Page 7: Introduction

    1. Introduction Thank you for selecting UPS to protect your electrical equipment. The UPS has been designed with the utmost care. We recommend that you take the time to read this manual to take full advantage of the many features of your UPS (Uninterruptible Power System). Before installing your UPS, please read the booklet presenting the safety instructions.
  • Page 8 Product The product is made up of recyclable materials. Dismantling and destruction must take place in compliance with all local regulations concerning waste. At the end of its service life, the product must be transported to a processing center for electrical and electronic waste. Battery The product contains lead-acid batteries that must be processed according to applicable local regulations concerning batteries.

  • Page 9: Presentation

    2. Presentation 2.1 Front panel Tower model: Tower UPS 6KS/10KS Tower UPS 6K/10K Tower EBC RT model: RT UPS 6K/10K UPS RT EBC...

  • Page 10: Rear Panels

    2.2 Rear panels Tower model: Tower UPS 6KS Tower UPS 10KS Tower UPS 6K Tower UPS 10K Tower EBC 1. Intelligent slot version, one is 5 Pole. Another is 7pole. 2. USB 7pole add bat+, bat-, and no external 3. RS232 battery connector #10.) 4.
  • Page 11 RT model: RT UPS(6K/6KS/10K/10KS) RT EBM 1. Intelligent slot 10. Input/Output terminal 2. USB (4pole IPL, IPN, OPL, OPN. 3. Dry IN/OUT PE is screw) 4. RS232 11. Input breaker (optional) 5. EPO 12. EBM connector 6. RJ11 (connect to PDU, only 13.

  • Page 12: Circuit Diagram

    2.3 Circuit diagram...

  • Page 13: Installation

    3. Installation It is recommended to move the equipment to the installation site by using a pallet jack or a truck before unpacking. The system may be installed only by qualified electricians in accordance with applicable safety regulations. The cabinet is heavy, please install it with at least two peoples. 3.1 Inspecting the equipment If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for...
  • Page 14 ◆ RT UPS ◆ RT EBM Note: The cabinet is heavy, please see spec weight provided on the carton/label. Do not lift the unit’s front panel and rear panel. Discard or recycle the packaging in a responsible manner, or store it for future use.

  • Page 15: Checking The Accessory Kit

    3.3 Checking the accessory kit Verify that the following additional items are included with the unit: RT UPS 6K/10K RT EBC Tower Battery power cable USB cable RS232 cable Parallel cable Dry contractor EPO contractor Stabilizer bracket Extension plate of Stabilizer bracket Ear bracket Rail kit...
  • Page 16 3. Install the unit to a surface (optional): place 4pcs bolts (M8 is recommended) to the final location previously, bolt’s position please refer to below, then fix the unit to the bolts. ◆ EBC model 1. Install the EBC model ----- Refer to UPS model installation as above. 2.
  • Page 17 3.4.2 RT model: Rack position installing This procedure is suitable for 19 inch rack cabinet installation with a minimum of 800mm depth. ◆ UPS model Identify the final position and keep ‘2U’ space for this installing. Note that you already installed a ‘rail kit’ to rack cabinet for this operation, and ‘1U’...
  • Page 18 3. Connect EBC to UPS with ‘Battery power cable’. Note: This ‘Battery power cable’ may have different plug according to the number of battery inside of this unit, please check the ‘Voltage’ parameter on rear-panel if it matches the UPS before connection. The battery number can be adjusted from ‘16pcs*1 strings’...
  • Page 19 ◆ EBC model 1. Set up the ‘Extension plate’ as below and install to ‘Stabilizer bracket’ from UPS. 2. Take the UPS& EBC into ‘Stabilizer bracket’ individually. 3. Connect to UPS with ‘Battery power cable’--- Refer to rack position installing. Note: This unit is recommended to be installed to UPS’s right side.

  • Page 20: Power Cables Connection

    4. Power cables connection Recommended protective devices and cable cross-sections Recommended upstream protection UPS power rating Upstream circuit breaker 6000VA D curve – 63A 10000VA D curve – 100A to UPS Normal AC / Bypass AC source N(L2) G N(L2) L1 Read the Safety instructions page 3 regarding backfeed protection requirements.

  • Page 21: Access To Terminal Blocks(Ac Source To Ups)

    4.1 Access to terminal blocks (AC source to UPS) High leakage current: Earth connection essential before connecting supply. Common input/output sources connection This type of connection must be carried out by qualified electrical personnel Before carrying out any connection, check that the upstream protection devices (Normal AC source and Bypass AC source) are open "O"...

  • Page 22: Access To Terminal Blocks(Pdu Source To R/T Ups)(Optional)

    ◆ R/T model: 3. Tie up the AC cable to the rear panel. 4. Install back the cover of terminal block. 4.2 Access to terminal blocks (PDU source to R/T UPS) (Optional) If you ordered PDU model, please connect the UPS’s terminal blocks from PDU’s source, detail operation please refer to PDU’s user manual.
  • Page 23 How to install a new parallel UPS system: 1) Before installing a new parallel UPS system, please prepare the input /output wires, breakers, and a main maintenance mechanical switch or static switch. 2) Independent battery packs for each UPS. 3) Remove the cover plate of parallel port on the UPS, connect each UPS one by one with parallel cable, and make sure the cable is screwed tightly.
  • Page 24 4) Install ‘cable locker’ to protect the ‘parallel cable’ for each UPS. 5) Connect the input and output wires and make sure all the breakers are turned off. ◆ Tower model:...
  • Page 25 ◆ Rack model: 6) Turn on the input breakers for the parallel UPS. 7) Pressing button continuously for more than 1 second for one UPS of the system, then the system will turn to line mode. 8) Regulate the output voltage of the each UPS separately, and check if the difference of output voltage is less than 0.5V among the parallel system.
  • Page 26 2. How to join a new UPS to parallel system: 1) Firstly, a main maintenance mechanical switch or static switch should be installed for the parallel system. 2) Regulate the output voltage of the new UPS: check if the output voltage difference between the new UPS and the parallel system is less than 0.5V.
  • Page 27 3. How to remove all the UPS from parallel system: 1) Firstly, a main maintenance mechanical switch or static switch should be installed for the parallel system. 2) Ensure the bypass is normal and the auto bypass setting is “enable”, press button to turn off the UPS system, and the UPS system will turn to bypass mode.

  • Page 28: Operation

    5. Operation 5.1 Control panel The UPS has a graphical LCD with five-button. It provides useful information about the UPS itself, load status, events, measurements and settings. The following table shows the indicator status and description: Indicator Status Description Normal The UPS is operating normally on Online or on High (Green) Efficiency mode.
  • Page 29 The following table shows the Control Button Functions: The Button Function Illustration Press this button for >100ms&<1s can power on Power on the ups without utility input at the condition of battery connected. When the unit is powered on and stayed is in Turn on Bypass mode, press this button for >1s can turn on the UPS.

  • Page 30: Lcd Description

    The Buzzer definition as below： UPS condition Buzzer status Fault active Continuous Over Load 2 Beep every second Warning active Other Warning active Beep every second Beep every 4 seconds, if battery low, buzzer Beep every second Battery output Beep every 2 minutes Bypass output 5.2 LCD description The LCD backlight automatically dims after 2 minutes of inactivity (except UPS is...
  • Page 31 Online mode The UPS is operating The UPS is powering and protecting the normally. equipment. Battery mode A utility failure has The UPS is powering the equipment with occurred, and the UPS is the battery power. on Battery mode. Prepare your equipment for shutdown. 1 beep every 4 seconds End of backup time...
  • Page 32 Converter mode The UPS is operating In converter mode, the UPS would free run on converter mode. with fixed output frequency (50Hz or 60Hz). Once the mains is loss or abnormal, the UPS would transfer to battery mode and the load is supplied continuously. 1.

  • Page 33: Display Functions

    5.3 Display functions Use the two middle buttons ( ) to scroll through the menu structure. Press the Enter ( ) button to select an option. Press the ESC button to cancel or return to the previous menu. When starting the UPS, the display is in the default UPS status summary screen. Main menu Submenu Display information or Menu function...

  • Page 34: Ups Startup And Shutdown

    Power strategy [normal] [high efficiency] [converter] [normal] Auto bypass [enabled] [disabled] [enabled] Auto restart [enabled] [disabled] [enabled] Authorize the product to restart automatically when mains recover after a complete battery discharge. Dry in [Disabled] [SON] [SOFF] [Maintain bypass] [Disabled] Dry out [Load powered] [On battery mode] [Battery [Load powered] low] [Battery disconnected] [Bypass output]...
  • Page 35 A few seconds later, the UPS turns into Line mode. If the utility power is abnormal, the UPS will transfer to Battery mode without output interruption of the UPS. Starting the UPS on Battery Before using this feature, the UPS must have been powered by utility power with output enabled at least once.

  • Page 36: Lcd Operation

    5.6 LCD operation Except the default UPS status summary screen, the user can get more useful information about UPS status, detailed various measurements, previous event records which ever occurred, UPS own identification, and could change the settings to fit the user own requirements, optimize the function of UPS. The main menu In the default UPS status summary screen, when pressing <300ms,...
  • Page 37 The UPS status menu By pressing on the menu of “UPS status”, the display would enter the next UPS status menu tree. The content of UPS status menu tree is same as the default UPS status summary menu. By pressing ESC >300ms, the display would return the last main menu tree.
  • Page 38 The measurement menu By pressing on the menu of “Measurement”, the display would enter the next measurement menu tree. A lot of detailed useful information could be checked here, Ex. the output voltage and frequency, the output current, the load capacity, the input voltage and frequency, etc.
  • Page 39 The event log menu By pressing on the menu of “Event log”, the display would enter the next event menu tree. All the previous events, alarm and fault have been recorded here. The information includes the illustration, the event code, and the precise time of UPS when the event happened.
  • Page 41 The identification menu By press on the menu of “Identification”, the display would enter the next identification menu tree. The identification information includes UPS serial number, firmware serial number, model type, would be shown here. By press ESC >300ms, the display would return the last main menu tree. The setting menu Please contact your local distributor for further information before using the settings.
  • Page 43 Example: set rated output voltage value Setting menu tree By press <1s The option would flash Output voltage Output voltage <230V> <230V> By press <1s By press >100ms, to select the wanted option Output voltage <220V> By press >1s, to confirm the setting The option would stop flashing Output voltage after being confirmed...

  • Page 44: Communication

    6. Communication 6.1 Communication ports RS232 or USB communication ports The RS232 and USB communication ports cannot operate simultaneously. 1. Communication cable to the serial or USB port on the computer. 2. Connect the other end of the communication cable to the RS232 or USB communication port on the UPS.

  • Page 45: Network Management Card (Optional)

    6.2 Intelligent Card (Optional) Intelligent Card allow the UPS to communicate with different types of devices in variety of networking environments. The Online series has one available communication bay for the following connectivity cards: 1. Connect UPS-MS Web/SNMP Card – has SNMP and HTTP capabilities as well as monitoring through a Web browser interface;...

  • Page 46: Ups Maintenance

    7. UPS maintenance 7.1 Equipment care For the best preventive maintenance, keep the area around the equipment clean and dust free. If the atmosphere is very dusty, clean the outside of the system with a vacuum cleaner. For full battery life, keep the equipment at an ambient temperature of 25°C (77°F).

  • Page 47: Replacing Batteries

    7.4 Replacing batteries DO NOT DISCONNECT the batteries while the UPS is in Battery mode. Consider all warnings, cautions, and notes before replacing batteries. Servicing should be performed by qualified service personnel with ⚫ knowledgeable of batteries and required precautions. Keep unauthorized personnel away from batteries.

  • Page 48: Recycling The Used Equipment

    For RT module, if PDU is connected with the UPS, should turn the MBS to bypass and switch off the input and then replace the EBC(s). If PDU is not connected with the UPS, should turn off the UPS and then replace the EBC. To replace the EBC(s): 1.

  • Page 49: Troubleshooting

    8. Troubleshooting The UPS is designed for durable, automatic operation and also alert you whenever potential operating problems may occur. Usually the alarms shown by the control panel do not mean that the output power is affected. Instead, they are preventive alarms intended to alert the user. Events are silent status information that are recorded into the Event log.
  • Page 50 No battery The batteries are disconnected. Verify that all batteries are Fault (Red) LED is Flash properly connected. 1beep every 1 second If the condition persists, Code: A011 contact your service representative. Bypass mode An overload or a fault has Equipment is powered but Bypass (Orange) LED is occurred, or a command has...
  • Page 51 In HE Mode The UPS is on bypass while The equipment transferred Line (green) LED is on. operating on the High to bypass utility power as a Code: E063 Efficiency setting. normal function of High Efficiency operation. Battery mode is available and your equipment is protected.
  • Page 52 BUS Over Voltage Indicates that the UPS get BUS The UPS transfers to Fault (Red) LED is On. over voltage fault because of Bypass mode if supporting Beep continuous. BUS. the load Code: F021 BUS Under Voltage Indicates that the UPS get BUS The UPS transfers to Fault (Red) LED is On.

  • Page 53: Silencing The Alarm

    Battery Over Voltage Indicates that the battery The UPS will turn off the Fault (Red) LED is On. voltage is too high charger until the battery Beep continuous. voltage is normal Code: F016 Negative power Fault In parallel system，power of Redundancy mode，the Fault (Red) LED is On.

  • Page 54: Specifications

    9. Specifications 9.1 Model specifications Table 1. Power Module model list Model Power Ratings MS-ECO6002 6000VA / 6000W MS-ECO10002 10000VA / 10000W MS-ECO6002RT 6000VA / 6000W MS-ECO10002RT 10000VA / 10000W Table 2. Extended Battery Module model list Model Configuration Battery voltage For power ratings Tower EBC Tower...
  • Page 55 Model Default input Selectable input Voltage Voltage (Voltage/Current) range at 100% Load MS-ECO6002 / RT 230V / 31.2A 208/220/230/240V 176~276Vac MS-ECO10002 / RT 230V / 49.9A 208/220/230/240V 176~276Vac Table 5. Electrical input connections Model Input connection Input cable MS-ECO60002 / RT Hardwired Not provided MS-ECO10002 / RT...
  • Page 56 Table 7. Electrical output connections Model Output connection Output cable Tower 6K/6KS RT 6K/6KS Hardwired Not provided Tower 10K/10KS RT 10K/10KS Table 8. Environmental and safety Certifications EN 62040-1 IEC/EN 62040-2: Cat. C3 IEC/EN 62040-3 EN 60950-1 EMC (Emissions)* Conduction: C3 IEC/EN 62040-2 Radiation: C3 IEC/EN 62040-2 EMC (Immunity) IEC 61000-4-2, Level 3...
  • Page 57 Table 9. Battery EBMs Rack / Tower 240Vdc 20 x 12V, 7Ah configuration 240Vdc 20 x 12V, 9Ah 192Vdc 16 x 12V, 7Ah 192Vdc 16 x 12V, 9Ah Fuses 100A for 10kVA models and EBM Type Sealed, maintenance-free, valve-regulated, lead-acid, with minimum 3-year float service life at 25°C (77°F).

  • Page 58: Glossary

    10 Glossary Bypass AC source Source supplying the bypass line. The equipment can be transferred to the bypass line if an overload occurs on the UPS output, for maintenance or in the event of a malfunction. Frequency converter Operating mode used to convert the AC-power frequency between the UPS input and output (50Hz ->...
  • Page 59 Special instruction - UPS enclosure IP rating: IP20 - Protective class I - Certification standards • Safety: IEC/EN 62040-1 • EMC: IEC/EN 62040-2 • Performance: IEC/EN 62040-3 - Output short-circuit current max RMS & delay time: 40A/70ms; The max peak value: 76A - This UPS can be used in and supplied to load TN/TT power system.
  • Page 60 614-02166-04...
