CyberData Ethernet IV Printer Module Specifications

Ethernet IV Printer Module
The CyberData Ethernet IV Printer Module is
a lower-cost alternative for EPSON POS
printers. The CyberData Ethernet IV module
works "out of the box" with no special drivers
or configuration requirements to work with
Epson T88 and H6000 printers.
Implementing an ethenet-based printer
solution allows multiple workstations to print
from a single Epson printer, proving
significant cost savings and increased
productivity. Utilizing CyberData's Ethernet
IV module management software provides
remote management and reporting
capabilities of networked printers.
Features
Customizable remote management software
Field-programmable
Up to 230K baud rate
Windows 2000/XP, WePOS, OPOS, Linux
compliant
Support of Epson POS printers with
Connect-It interfaces
DHCP Support
Compatibility Overview
The CyberData Ethernet IV Module was
designed for a retail POS specific environment.
Compatibility with retail application interfaces
include:
OPOS
JPOS
Epson TM Flash Logo (TMFLOGO)
Epson Tool Kit
Epson APD
Port 9100
CyberData Corporation
CyberData Corporation 2555 Garden Road
(831) 373-2601 (831) 373-4193 www.cyberdata.net
CyberData Corporation
For Epson POS Printers
Ethernet IV Printer Module Specifications
Baud Rate
Ethernet Port
Standard Protocol
RoHS Compliant
Operating Temperature
Non-Operating Temperature
Operating Humidity
Regulatory Compliance
Warranty
Part Number
Typical Installation
Ethernet Cable
Retail Computer
Monterey, California 93940
Up to 230K baud
10Base-T
TCP/IP
Yes
-30C to 55C (-22F to 131F)
-40C to 80C (-40F to 176F)
0% to 95% (non-condensing)
FCC Class B, UL 60950, CE
2 years limited
010748B
Ethernet IV Module
Printer
PSU
930201A/080108
