Fandis CCU Series Instruction Manual

Cooling units
Hide thumbs Also See for CCU Series:

Advertisement

Available languages

Available languages

Quick Links

Condizionatori
series CCU
Manuale istruzioni unità da tetto
Roof unit instruction manual
Cooling units
CCU series

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCU Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Fandis CCU Series

  • Page 1 Condizionatori series CCU Manuale istruzioni unità da tetto Roof unit instruction manual Cooling units CCU series...
  • Page 3: Table Of Contents

    Combinazione di tasti e relative funzioni ........11 Messaggi di diagnostica ..............12 AVVIAMENTO DEL CONDIZIONATORE............ 12 PRIMI CONTROLLI DOPO L’AVVIO ............12 MANUTENZIONE ..................13 SMANTELLAMENTO DELL’APPARECCHIO ..........13 GARANZIA ....................14 ANOMALIE RISCONTRABILI ED AZIONI CORRETTIVE ......14 3 Fandis Fandis 3...
  • Page 4: Avvertenze

    ○ Condensatore: All’esterno dell’armadio, il condensatore cede il calore del fluido refrigerante compresso all’ambiente, facendolo condensare in forma liquida. ○ Organo di laminazione: L’organo di laminazione, noto anche come capillare o valvola termostatica, riduce la pressione del fluido refrigerante liquido, permettendone l’evaporazione nell’evaporatore. 4 Fandis...
  • Page 5 Il fluido refrigerante liquido ad alta pressione passa attraverso l’organo di laminazione, dove la sua pressione viene ridotta. h. Il fluido refrigerante liquido a bassa pressione entra nuovamente nell’evaporatore, completando il ciclo. 5 Fandis Fandis 5...
  • Page 6: Ricevimento E Stoccaggio

    Assicurarsi che all’interno dell’imballo non siano rimaste parti o documenti importanti. 2. Verifica della tensione di alimentazione: Confrontare la tensione di alimentazione indicata sulla targhetta identificativa del condizionatore con quella effettivamente disponibile nel luogo di installazione. 6 Fandis...
  • Page 7: Montaggio Meccanico

    Prima di procedere con il collegamento elettrico, è fondamentale verificare che la tensione di alimentazione riportata sulla targhetta identificativa del condizionatore corrisponda effettivamente a quella disponibile nel punto di installazione. Un’alimentazione con tensione errata potrebbe danneggiare seriamente il condizionatore e rappresentare un pericolo per la sicurezza. 7 Fandis Fandis 7...
  • Page 8: Componenti Di Comando, Controllo E Sicurezza

    È assolutamente vietato tentare di bypassare elettricamente i componenti di sicurezza. Tale operazione, oltre ad essere pericolosa per l’incolumità delle persone, invalida la garanzia del prodotto e potrebbe aggravare il guasto. 8 Fandis...
  • Page 9: Pressostato Di Sicurezza Alta Pressione

    è danneggiata o presenta incrostazioni che potrebbero ostruire il corretto deflusso dell’acqua. Se necessario, pulire accuratamente la vaschetta per eliminare eventuali depositi o detriti. 3. Ispezione del sistema di rievaporazione: Verificare che il sistema di rievaporazione dell’acqua funzioni correttamente. 9 Fandis Fandis 9...
  • Page 10: Termostato Di Regolazione Elettronico

    (con PSW) spegnimento allarme sonoro (buzzer) Tabella 2 - Tabella LED Funzionamento normale funzione Lampeggiante Avvio simbolo In attesa (tempo di ritardo Compressore attivo spento accesa riaccensione) Allarme (temperatura attivo spento accesa alta/bassa) Uscita allarme attiva spenta accesa 10 Fandis...
  • Page 11: Combinazione Di Tasti E Relative Funzioni

    (AL=0; allarme simbolo LO con la temperatura sul display e disabilitato) l'icona di allarme accesa. NON USATO Differenziale 0°C 19°C 2°C Calibrazione della -50°C 50°C 0°C sonda Seleziona sonda/ NON DEVE ESSERE MODIFICATO ingresso visualizzato (*) 11 Fandis Fandis 11...
  • Page 12: Messaggi Di Diagnostica

    Verifica del flusso d’aria Dopo l’avvio del condizionatore, è importante assicurarsi che l’aria in uscita dal ventilatore del condensatore non venga riaspirata dalla macchina stessa. Per evitare questo problema, è fondamentale rispettare le distanze minime di installazione indicate nell’immagine. 12 Fandis...
  • Page 13: Manutenzione

    Lo smantellamento del condizionatore deve essere effettuato da un’azienda autorizzata e qualificata per la gestione dei rifiuti elettronici e pericolosi. Il fluido frigorigeno e l’olio contenuti nel circuito frigorifero devono essere recuperati e riciclati in conformità alle normative vigenti per la tutela dell’ambiente e la prevenzione dell’inquinamento. 13 Fandis Fandis 13...
  • Page 14: Garanzia

    MANUALE ISTRUZIONI UNITÀ DA TETTO - SERIE CCU GARANZIA Condizioni di validità Come da condizioni generali di vendita reperibili sul sito www.fandis.com ANOMALIE RISCONTRABILI ED AZIONI CORRETTIVE Identificazione e risoluzione dei problemi Questa tabella fornisce una guida per l’identificazione e la risoluzione dei problemi più comuni che possono verificarsi con il condizionatore.
  • Page 15 ROOF UNIT INSTRUCTION MANUAL - CCU SERIES Cooling units CCU series ROOF UNIT INSTRUCTION MANUAL I N D E X CAUTION ....................16 GENERAL SAFETY INSTRUCTIONS ............16 OPERATING PRINCIPLE ................16 ACCEPTANCE AND STORAGE ..............18 HANDLING ....................18 INSTALLATION ..................
  • Page 16: Caution

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES CAUTION Safety and Installation • Installation, operation and maintenance of this cooling unit should be carried out exclusively by qualified personnel with the necessary technical skills and experience. • Keep this manual in a clean and dry place to consult it when necessary.
  • Page 17 ROOF UNIT INSTRUCTION MANUAL - CCU SERIES 3. Cooling cycle: a. The low-pressure cooling fluid enters the evaporator. b. Absorbing heat from the air inside the cabinet, the cooling fluid evaporates, removing heat from the environment and cooling it. c. The low-pressure cooling vapour is drawn into the compressor.
  • Page 18: Acceptance And Storage

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES ACCEPTANCE AND STORAGE Verify the transport conditions Upon arrival of the goods, it is crucial to make sure that the cooling unit has traveled in its correct position, as indicated by the arrows and symbols present on the packaging. Improper transport could damage the cooling unit and causing its inaccurate operation.
  • Page 19: Mechanical Mounting

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES MECHANICAL MOUNTING Positioning and orientation It is essential to install it in a horizontal position, with the compressor at the bottom, and with a maximum deviation of 2° from the vertical. Protection requirements Before installation, ensure that the electrical cabinet has a minimum protection degree of IP54 to avoid problems due to condensation of external humidity.
  • Page 20: Control, Monitoring And Safety Components

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES Electrical cables connection The roof cooling unit is typically equipped with two electrical cables that come out from the bottom of the unit: • Power Cable (L N PE / L1 L2 PE): This cable is intended for connecting the electrical power supply to the unit.
  • Page 21: High Pressure Safety Switch

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES HIGH PRESSURE SAFETY SWITCH The high-pressure safety switch is an essential component for the cooling unit’s safety. Its function is to stop the compressor operation if the pressure of the circuit exceeds the calibration level (24 bar).
  • Page 22: Electronic Thermostat

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES ELECTRONIC THERMOSTAT Operation • It indicates the enclosure internal temperature during operation. • The setpoint temperature is pre-set at 35°C with a differential of 2°C. • The cooling unit activates at the default temperature plus a differential (37°C) and it deactivates at the default temperature (35°C).
  • Page 23: Use Of Button Combinations And Their Functions

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES Use of button combinations and their functions Setting the set point (desired temperature) • Press SET for 1s, the set value will start flashing after a few moments; • Increase or decrease the value using UP or DOWN (minimum value of 30°C; maximum value of 40°C);...
  • Page 24: Diagnostic Code Table

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES Diagnostic code table Probe 1 error=control External alarm (door contact open) Low temperature alarm High temperature alarm High condensate level START-UP Waiting for lubricant oil re-distribution After completing the cooling unit installation, it is recommended to wait at least 30 minutes before starting the unit.
  • Page 25: Maintenance

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES MAINTENANCE Qualified personnel and scheduled interventions The ordinary and extraordinary maintenance operations of the cooling unit must be carried out exclusively by qualified personnel. This ensures the safety and efficiency of the system, preventing malfunctions and serious damage.
  • Page 26: Warranty

    ROOF UNIT INSTRUCTION MANUAL - CCU SERIES WARRANTY Validity conditions As per the General Sales Conditions available on the website www.fandis.com ANOMALIES AND CORRECTIVE ACTIONS Problem recognition and resolution This table provides a guideline for identifying and solving the most common problems that may occur with the cooling unit.
