GEA GFAPC120V Installation Instructions

Installation
Instructions
If you have any questions, call GE Appliances at 800.626.2000 or visit our Website at: GEAppliances.com
NOTE: This product Is Intended ONLY for use with GE Appliances Combo model PFQ97. This product
allows connection of one or two separate Combo units to a single NEMA 14-30R 30 Amp, 4-Wire electric
dryer outlet receptacle. This product will not work in a 3-Wire 240 VAC dryer electric outlet. For any other
WARNING
Disconnect power before installing. Failure to do
so could result in serious injury or death.
WARNING
Do not alter or modify this product in any way.
•
Carefully inspect the product before
•
installation.
Never use a damaged power cord, adapter
•
plug, or plug.
Keep pets and children away from the installed
•
power cord adapter plug.
Never crush/squeeze a power cord adapter
•
between an appliance and a wall or any other
surface after installation. Carefully place
appliance in position after installation of this
adapter.
Always turn off any appliance before inserting
•
the AC power cord into any outlet.
Failure to follow all general safety warnings
•
and installation instructions may result in
electrical shock or injury.
TROUBLESHOOTING INSTRUCTIONS
NOTE: This power cord adapter plug contains an independent automatic circuit breaker inside each of the 115 VAC
outlet receptacles. After checking all other possible sources of AC power loss, examine the small red reset button on
the receptacle plug(s). Under certain circumstances, pressing this red power reset button MAY restore AC power to the
appliance(s) that are connected to this power cord adapter. If AC power is lost to the appliance (but other home/domicile
AC power is present), wait at least one minute after power loss to the laundry appliance before pressing this red reset
button. This MAY reset the internal power plug circuit breaker to the normal position. If pressing the red reset button fails
to restore normal 115 VAC power to the appliance, or the power cord adapter safety circuit breaker activates again (red
button pops up or out) after reset, unplug all 115 VAC appliance power cords from the adapter. Remove the adapter main
4 prong plug head from the NEMA 14-30R wall outlet.
Contact GE Appliances Service (www.repair.GEAppliances.com or 844.278.6631) or consult a qualified electrician.
In Canada, call 800.561.3344, visit GEAppliances.ca/after-sales-support or consult a qualified electrician.
In Canada, call 877.994.5366 or visit www.GEAppliances.ca
application, consult a qualified electrician.
Power Cord Adapter Plug Kit
GFAPC120V
1
Locate the AC circuit panel that provides 240VAC/30
Amp/Single Phase/60Hz to the existing wall mounted
NEMA 14-30R receptacle used (typical US household
electrical dryer outlet) and set that dedicated 30 Amp
circuit breaker to the OFF position. Consult a qualified
electrician if necessary.
2
Plug the 3 prong 115 VAC power cord(s) attached to
the Combo into the small 115 VAC NEMA 5-20R
receptacles as needed. Two Combo units may be plugged
into this power cord adapter plug and both will operate
simultaneously as desired. Make sure the 115 VAC
appliance power cord plugs are fully inserted into their
115 VAC receptacles on the adapter plug(s).
3
Insert the large main 4 prong NEMA 14-30P (plug) into
the wall mounted NEMA 14-30R (receptacle). Make sure
the large plug head is fully seated and flush against
the wall mounted outlet.
4
Carefully place the main appliance back into the desired
operating position. Make sure that the adapter plug is not
squeezed/crushed between the rear of the appliance and
any other surface. Leave at least 1" (25 mm) of space
around all edges/surfaces of the power cord adapter plug
and receptacles and any wall/floor or other surface after
the appliance is moved into the desired operating position.
5
Return/restore the dedicated 30 Amp circuit breaker
(referenced in step 1) to the ON position. Turn on the
Combo in accordance with the operating instructions
and/or the owner's manual.
Printed in China
31-3000402 Rev 0
03-24
