Summary of Contents for Dark Matter 43906
- Page 1 Sentry Streaming Microphone P/N 43906 User's Manual...
-
Page 2: Safety Warnings And Guidelines
SAFETY WARNINGS AND GUIDELINES Please read this entire manual before using this device, paying extra attention to these safety warnings and guidelines. Please keep this manual in a safe place for future reference. This device is intended for indoor use only. •... -
Page 3: Package Contents
PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice™ Customer Service for a replacement. 1x Sentry Streaming Microphone 1x Stand 1x Stand Screw 1x USB Cable 1x User's Manual PRODUCT OVERVIEW... - Page 4 Bottom View Momentarily press the Multi-color Ambient LED Switch button to cycle • through the seven available colors. Press and hold the Multi-color Ambient LED Switch button for three • seconds to turn the Ambient LED lighting on or off. Top View Momentarily press the MODE button to cycle through the four Polar •...
-
Page 5: Polar Patterns
POLAR PATTERNS Note that the top of the polar pattern diagram is the front of the microphone. The Cardioid pattern captures sound from the front of the microphone and rejects sounds from the rear. It is the most common and the most useful pattern under ordinary circumstances. - Page 6 The Stereo pattern captures sound from the front and sides and rejects sounds from the rear. It creates a realistic general sound image and is great for recording instruments or acoustics. The Omnidirectional pattern captures sound equally from all directions. It is great for broadcasts involving multiple people positioned around a centrally mounted mic.
-
Page 7: Installing The Stand
INSTALLING THE STAND Position the Stand on the bottom of the Microphone. Insert the Stand Screw into the hole in the bottom of the mic, then turn it clockwise to tighten and secure the stand to the mic. -
Page 8: Adjusting The Stand
ADJUSTING THE STAND Twist the knob counterclockwise to loosen the legs. Position the stand legs as desired, then turn the knob clockwise to lock the legs in place. INSTALLATION AND CONFIGURATION Plug one end of the included USB Cable into the USB Type-C® port on the bottom of the microphone, then plug the other end into an available USB port on your PC. -
Page 9: Specifications
SPECIFICATIONS 43906 Microphone Type Back electret condenser Cardioid, Bidirectional, Stereo, Pickup/Polar Patterns Omnidirectional Audio Connection USB 1.0 or 2.0 Frequency Response 20Hz ~ 20kHz Sensitivity -36dB ±2dB (0dB=1V/Pa at 1kHz) Maximum SPL 130dB Microphone Gain -12dB, 12dB maximum Output Impedance... -
Page 10: Regulatory Compliance
To download the latest drivers, firmware, manuals, etc., go to www.monoprice.com and type the P/N into the search bar. If available, support files are linked at the bottom of the product page. REGULATORY COMPLIANCE Notice for FCC This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 11 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Monoprice™, Dark Matter™, the Dark Matter logo, and all Monoprice logos are trademarks of Monoprice Inc. USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
