Voltech SBC-5925 Operation Manual

Introduction
This is a DC-DC charger with 9 to 32 Volt input range and 5 selections of charging profiles for WET/ AGM/
GEL/ CAL/ LiFePO4 batteries. The specific charging profile will give your selected battery type a safe, fast
and complete charge. The wide input voltage range allows 12V or 24V systems to charge your 12V auxiliary
battery which can be installed a long distance from the starting battery as in a trailer / caravan.
Features
●
3 Stage charge with selection of 4 types of lead batteries.
●
2 Stage charge for LiFePO4 battery.
●
Wide (9-32 V) input voltage range designed for use in any 12 or 24V Car, 4WD, Truck, Coach and
Caravan electrical system.
●
Auxiliary battery can be fully and efficiently charged from a long-distance charging source.
●
Ignition Control enables unit to stop charging when ignition is off.
●
Low Voltage Cut Off Protection for starting battery.
●
Self Recoverable Input Under Voltage Protection.
●
Self Recoverable Output Over Voltage Protection.
●
Self Recoverable Over Temperature Protection.
●
Self Recoverable Overload Protection (C.C.) with constant current at decreased output voltage.
●
Supplied accessory Remote LED Indicator Module showing:
- Battery voltage level (when no load connected to battery) or Output Voltage Level
- Bulk/ Absorption/ Float Charging Stage for Lead Acid battery types
Protections
●
Input under voltage protection
●
Output over voltage protection
●
Overload protection
●
Over temperature protection
SBC-5925
12V In-Car Charger
Operation manual
