User Manual
GM OnStar Gen12
Telematics Connectivity Platform Module (TCP)
G12R400G1
05. July 2023
Public

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM OnStar Gen12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Continental Refrigerator GM OnStar Gen12

  • Page 1 User Manual Document: GM OnStar Gen12 Product: Telematics Connectivity Platform Module (TCP) Model: G12R400G1 Date: 05. July 2023 Public...
  • Page 2: Table Of Contents

    Content SCOPE OF DOCUMENT ............................ 3 GENERAL PRODUCT INFORMATION ......................3 : ............................... 3 RODUCT TYPE : ........................3 ANUFACTURER PPLICANT : ............................3 ESIGN LOCATION : ............................. 3 RAND RADEMARK : ......................3 ACTORY ANUFACTURING OCATION : ............................3 OUNTRY OF ORIGIN SYSTEM OVERVIEW ............................
  • Page 3: Scope Of Document

    1 Scope of Document The aim of this document is to provide a short overview on the Telematics Connectivity Platform Module (TCP) of model G12R400G1 and to describe the TCP. 2 General Product Information Product type: Telematics Connectivity Platform Module (TCP) Manufacturer, Applicant: Continental Automotive Technologies GmbH Siemensstrasse 12...
  • Page 4: System Overview

    3 SYSTEM OVERVIEW Short Description of the TCP The product described herein is a Telematics Connectivity Platform Module (TCP) for the GM’s GEN12 ONSTAR (Telematics and Connectivity Platform) program. It consists of integrated telematics transceivers for different wireless services, as well as several interfaces to the vehicle.
  • Page 5: Tcp Mechanical Design

    5 TCP Mechanical design Pictures of the housing Public USER MANUAL Chap. 0 Version: Model G12R400G1 Fehler! Verweisquelle konnte Page 5 / 16 nicht gefunden werden.
  • Page 6: Dimensions

    Dimensions H = 22 mm W = 128 mm L = 210 mm Length: 210 mm Width: 128 mm Height: 22 mm Weight Weight: 0.47 kg Public USER MANUAL Chap. 0 Version: Model G12R400G1 Fehler! Verweisquelle konnte Page 6 / 16 nicht gefunden werden.
  • Page 7: Description Of The Tcp Module

    6 Description of the TCP module Product features The model main parts are: • NAD with 2G/3G/4G/LTE and GNSS • External and internal antennas • Voice and Data • 2x2 DL-MIMO for 4G • Internal embedded Sim-IC • Audio subsystem includes analog microphone input and speaker output •...
  • Page 8: Wireless Services

    Ethernet: Model number Speed G12R400G1 1 Gbit/s Wireless services: ➢ 2G ➢ 3G/WCDMA ➢ 4G/LTE ➢ VoLTE ➢ Voice/Assistance Calls o Emergency Calls o Assistance Calls o Calls are only possible to some fixed phone numbers ➢ Global Positioning and Navigation: GPS, GNSS, Beidou, Glonass, AGNSS not supported ➢...
  • Page 9: Connectors

    Connectors: The TCP has 6 types (fully featured variants) of connectors (from left to right): ▪ X1: 20-Pin Main Signal Connector ▪ X2: 12-Pin Audio ▪ X6: Single RF: C-V2X-2 ▪ X3: Quad RF (Cellular PRIMARY, DRX0/GNSS, C-V2X-1) ▪ X7: 1000BASET1 This variant does not support V2X.
  • Page 10: X1 20-Pin Main Connector Pin Out

    6.5.1 X1 20-Pin Main Connector Pin Out Signal Signal Signal VBATT CAN_L (IN) VBATT 10V_REF Keypad_IN Green_LED CAN_H (OUT) Red_LED CAN_L (OUT) CAN_H (IN) *Continental Debug Signals 6.5.2 X2 12-Pin Audio Connector Pin Out Signal Signal SPKR_P MIC_OUT_N SPKR_N MIC_IN_P Not Connected MIC_IN_N Not Connected...
  • Page 11: X7 1000Baset1 Connector

    6.5.5 X7 1000BASET1 Connector Signal 1000BASET1+ 1000BASET1- Audio Subsystem The TCP audio system will provide a hands-free user interface for emergency calls and call center concierge/personal calling within the vehicular environment. The audio system provides the following • Microphone front end input •...
  • Page 12: Technical Data

    7 Technical data Operating temperature Range -40°C to 90°C Supply Voltage Nominal.: 12 V dc Supply Voltage Range: 6 V to 18 V dc Supply current consumption Typical standby current: 250mA (at 12 V) Typical active current consumption: 350mA (at 12 V) Maximum active current consumption: 600mA dc (at 12 V) Power Consumption Typical power consumption: 5.5W...
  • Page 13: Wireless Services Supported

    8 Wireless services supported 2G/GSM: Wireless service: 2G/GSM Band 2 (GSM1900): 1850-1910 / 1930-1990 MHz, Frequency bands / range: Band 5 (GSM850): 824-849 / 869-894 MHz GSM: At room Temperature: Low Band (850): + 32.0 dBm (+/- 1.0 dB), High Band (1900): + 28.5 dBm (+/- 1.0 dB), At extreme temperatures: Low Band (850): + 32.0 dBm (+ 1.0/-3.0 dB), High Band (1900): + 28.5 dBm (+1.0/-3.0 dB),...
  • Page 14: Umts

    3G/UMTS: Wireless service: 3G/WCDMA Band 2 (1900 UMTS): 1850-1910 / 1930-1990 MHz, Frequency bands / range: Band 4 (1700 UMTS): 1710-1755 / 2110-2155 MHz, Band 5 (850 UMTS): 824-849 / 869-894 MHz Electrical output power +22.5 dBm +/-1.0 dB (conducted into 50 Ohm): 4G/LTE: Wireless service: 4G/LTE...
  • Page 15: Gnss Receiver

    GNSS receiver: Model number GNSS G12R400G1 Wireless service: GNSS Receiver GNSS L1 Frequency Band: Beidou-B1I, GalileoE1, GLONASS-G1, GPS-L1 and SBAS-L1 Frequency bands / range: SBAS supported: EGNOS/MSAS/QZSS/WAAS/GAGAN AGNSS not supported. Public USER MANUAL Chap. 0 Version: Model G12R400G1 Fehler! Verweisquelle konnte Page 15 / 16 nicht gefunden werden.
  • Page 16: Owner Manual Statements

    9 Owner Manual statements Owner manual USA Continental Model: G12R400G1 Contains FCC ID: LHJ-FE4RW0110 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
