- Page 1 USB-C 4-Port Hub w/Power Delivery & 15KV ESD Surge Protection USB 3.2 Gen1 Model Number: CG-UC31PD4H Installation Guide Coolgear, Inc. Version: 1.0 Date: 05/06/2024...
-
Page 2: Table Of Contents
First Release 1. Introduction Thank you for purchasing Coolgear’s USB-C 4-Port Hub .Thank you for purchasing this Super-speed 4-port USB3.1 Gen 1 Type-C PD metal hub. It provides an ideal solution for a USB-C upstream port (with PD) to expand 4 USB3,1 ports (1 USB-C with PD and 3 normal USB-A connectors). -
Page 3: Connector Layout
Self Power Input Connector: This 2-pin (one pin plus voltage and the other pin is ● GND) terminal blocks is used to connect a wide range power source to self-power the hub, the voltage can be in the range from +19V to 20V DC. Need help? Visit: coolgear.com/support... -
Page 4: Hardware Installation
To check the USB3.1 Gen 1 hub installation in Windows device manager, please follow the following steps: Click Start Control Panel System Device Manager button Double click Universal Serial Bus Controller Double click Generic USB Hub, the message will show that this device is working properly. Need help? Visit: coolgear.com/support... -
Page 5: Environmental Specifications
Do not disassemble the product. Handling the product’s ● internal components can expose it to ESD (Electro-Static Discharge) hazards that can affect the function of the device. If this product is not functioning properly, email our support ● team at support@coolgear.com. Need help? Visit: coolgear.com/support... - Page 6 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
- Page 7 USB-C 4-Port Hub – Installation Guide © 2024 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
