  • Page 1 AFP-16 Professional instant messaging audio player Owner’s manual...
  • Page 2 Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following: WARNING Power supply/Power cord Water warning •...
  • Page 3 • Do not expose the device to excessive dust or vibrations, or extreme cold or heat (such • Do not insert your fingers or hands in any gaps or openings on the device. as in direct sunlight, near a heater, or in a car during the day) to prevent the possibility of •...
  • Page 4 Dear customer, Thank you for purchasing AudioResolution AFP-16. Professional SD card audio announcement player with 16 instant play buttons with LED indication of playback. It features GPI (General Purpose Interface) digital signal pin, configured as input or as a output. GPI - Input is for blocking announcement playback with visible signalization of playback blocking, built in speaker for playback monitoring with separate volume control, announcement master volume control.
  • Page 5 AFP-16 - Front panel (Input section) AFP-16 - Rear panel (Output section) 13 12 1) Power switch 6) Power jack 11) Line Out For turning ON or OFF the unit. For connecting Power supply of 12V/1A. Playback output on 3-pin XLR connector. It is transformer balanced and isolated.

  • Page 6: Operation

    Operation • For the right operation it is necessary to have connected the supplied power adaptor Supported audio formats (12V /1A), inserted SD card with recorded messages with the right format and unit • Audio player AFP-16 supports audio files in MP3 or WAV file format. powered ON.

  • Page 7: Specifications

    Specifications AudioResolution AFP-16 Playback Number of direct play buttons Built in monitor speaker Max. output power Monitor volume control Yes - potentiometer Playback blocking signalization JUMBO RED LED Playback storage SD/SDHC card Supported audio formats MP3 mono/ stereo, 44,1kHz, 32kbit/s - 320kbit/s WAV mono/ stereo, 16-bit, 44,1kHz Supported SD card format FAT16, FAT32...

  • Page 8: Block Diagram

    Block diagram...
  • Page 9 | web: www.audioresolution.com MediaTech Central Europe, a.s., Drienova 34, 821 02 Bratislava, Slovak Republic (EU) Tel: +421 2 20 999 700...
