YG80B
Bluetooth® Weatherproof Lock
Installation and Operating Instructions
1
DN 01016/001 - 03/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YG80B and is the answer not in the manual?

Questions and answers

Summary of Contents for Bpt YG80B

  • Page 1 YG80B Bluetooth® Weatherproof Lock Installation and Operating Instructions DN 01016/001 - 03/2024...
  • Page 2: Table Of Contents

    Table of Contents Document Information Contents and Purpose Target Group Safety and Compliance Safety Information Regulatory Compliance Information Product Information Product Description Package Contents Technical Data Product Dimensions Lock Dimensions Strike Dimensions Pre-Installation Mounting Assessment Wiring Assessment Operating Mode Assessment 5.4 Strike Configuration Mounting...
  • Page 3: Document Information

    Document Information Contents and Purpose This document describes installation, connection, operation, and maintenance of the lock YG80B. Read the document carefully and observe the instructions it contains. They contain important information for reliable installation and trouble-free operation. Target Group Target group of these instructions are: •...
  • Page 4: Safety And Compliance

    Safety and Compliance Safety Information WARNINGS • The handling and installation of this device is recommended for a professional. • Use of an unsuitable power supply unit may cause product failure or injury. • Operation of lock while submerged may cause product failure. •...
  • Page 5: Regulatory Compliance Information

    Regulatory Compliance Information This product is in compliance with the CE Directives including Electromagnetic Compatibility (EMC) Directive, Radio Equipment (RED) Directive, Restriction of the use of certain hazardous substances (RoHS) Directive, and Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) Regulation. CE Declaration of Conformity is available at www.bqtsolutions.com.
  • Page 6 This product is regulated by the UL/CSA and bears UL/C-UL certification. Certifications: UL294, UL1034, CAN/ULC-S533-15 UL File Number: BP21205 UL Categories: ALVY, CVXY, FWAX7 Line Security Level I Standby Power Level I UL294 Attack Level I Endurance Level IV Static Strength: 1,500 lbf (6,673N) UL1034 Dynamic Strength: 70 ft·lbf (95J) Endurance: 250,000 cycles This device complies with Part 15 of the FCC Rules.
  • Page 7: Product Information

    The lock is fully sealed around the bolt pin and lid to prevent water ingress. For the wiring, waterproofing is ensured with a removable IPX7 rated cable. Use the BQT Connect app on your smart device to manage the YG80B. The app allows the user to pair with and directly control the lock via Bluetooth, as well as manage access permissions by sharing...
  • Page 8: Package Contents

    Package Contents 1x Lock 1x Strike 1x Neoprene Gasket (Optional Use) 1x 3 metre 8-way wire loom...
  • Page 9: Technical Data

    Technical Data Materials Bolt Pin Stainless Steel SS304 Lock / Strike Body Aluminium A383 Polypropylene, Glass Fiber Reinforced, UV Stabilised Mechanical Bolt Pin Dimensions ø18mm, 30mm extension, ø28mm receiver Strike Gap max. 15mm (5/8 inch) Holding Force 39,000N (8,800 lbf) (factory tested only) Cycle Life 300,000 cycles Locking/Unlocking Time 4.5 seconds (typical) Environmental...
  • Page 10: Product Dimensions

    Product Dimensions Lock Dimensions The dimensions shown are approximate and subject to change without prior notice. 150.0mm 5 29/32" 80.0mm 3 5/32" 14.5mm 56.0mm 37/64" 2 13/64" 80.0mm 48.0mm 3 5/32" 1 57/64" 22.6mm 112.5mm 22.5mm 57/64" 4 27/64" 57/64"...
  • Page 11: Strike Dimensions

    Strike Dimensions The dimensions shown are approximate and subject to change without prior notice. 80.0mm 3 5/32" 60.0mm 80.0mm 2 23/64" 3 5/32" 22.0mm 28.0mm 55/64" 1 7/64"...
  • Page 12: Pre-Installation

    To ensure the YG80B operates properly, the lock and strike must be separated by 15mm or less (5/8 inch or less).
  • Page 13: Wiring Assessment

    Wiring Assessment Before installation begins, consideration must be made for where to run the wires. If bluetooth is going to be the sole means of controlling the lock, only the two power supply wires will need to be connected. The remaining two control connections and four monitor connections provide optional wired control as well as door position, bolt position, and tamper detection feedback.
  • Page 14: Operating Mode Assessment

    The lock can also be set to either fail safe, or fail secure. Deciding this will depend on how the lock should behave when there is power loss. • For fail safe, the control input is set high to lock the door, and the YG80B will unlock in the event of power loss. •...
  • Page 15: Strike Configuration

    Strike Configuration The YG80B strike can be mounted a number of ways in relation to the lock, but to do so the embedded magnet must be moved to align with the YG80Bs internal reed sensor. Consider the magnet location for the following mounting orientations.
  • Page 16: Mounting

    Mounting Lock Installation 1. Drill the lock mounting holes Referring to the product dimension drawings, drill holes at the mounting locations to accept the appropriate M8 screws for the surface material (screws not included). In the example shown, M8 stud anchors are used in a precast concrete wall. 2.
  • Page 17: Strike Installation

    You can verify the placement and configuration of the strike by closing the door and removing the lid of the lock. If the YG80B detects the magnet, the LED will light up. Otherwise if it does not light up, the gap between the lock and strike may be too large or the magnet may not be in the correct location under the strike ring.
  • Page 18: Wiring

    Wiring The YG80B is supplied with an 8-way wire loom that plugs directly into the lock. The wires are colour coded as per table below. If bluetooth is going to be the sole means of controlling the lock, only the two power supply wires will need to be connected.
  • Page 19: Toggle Mode

    • Tamper Detection: When the lid is on the YG80B, the green tamper detection monitor wire will be in a closed contact state. If the lid is removed in any way, the wire will switch to an open contact state.
  • Page 20: Operations

    Operations To change operational modes, remove the lid and locate the DIP switches as shown below. Change the switches to the desired positions, as per the table shown. The Bluetooth pairing button can also be located as shown below. The BQT Connect app will help to guide the pairing proces.
  • Page 21: Operation Modes

    Assume the lock is installed, wired, and set to toggle or twin wire mode. The user has the BQT Connect app installed with an active eKey for the YG80B. The door is closed and locked and the user presses the unlock button on the app while within Bluetooth range, the YG80B will unlock and the door can then be opened.
  • Page 22: Failure Modes

    Fail Secure In the event of a power failure, the YG80B will lock, or remain locked, if the door is closed. This ensures that a lock will not disengage during power failure, keeping the access secured.
  • Page 23: Maintenance

    As a result of this wear, the lock may fail at the end of its normal service life. Interval Activity As needed: To keep the YG80B working effectively, ensure the strike hole and bolt pin are clear of debris at all times. Periodically, depending on frequency of Check for: use (to be determined by the operator): •...
