Page 2
CALIFORNIA Proposition 65 Warning WARNING: Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects, and other reproductive harm.
Page 3
Make an order for missing parts. General If more assistance is necessary you should speak to your AGCO dealer. This manual is only applicable to the models specified on the front cover. Fastener torques Always replace fasteners with fasteners of the same specification.
Page 4
1 Safety Description Color Functions Special tool Pressure gauges, specified tools Where the special tools or equipment are in an illustration, they are this color. Parts that you move Electrical wires, hydraulic hoses A component that you must move, and that is not necessary to remove from the machine.
Page 5
1 Safety Safety icons The safety warnings show in the manual with these icons: DANGER: This is an immediately dangerous situation which, if you ignore it, will cause death or injury. WARNING: This is an immediately dangerous situation which, if you ignore it, can cause death or injury.
Page 6
Do not change the equipment. An adjustment not specified by the manufacturer can change the function of the machine and cause damage or personal injury. Only use AGCO approved replacement parts. WARNING: To prevent injury and machine damage, you must: •...
Page 7
1 Safety Waste disposal Incorrect disposal of waste can cause pollution to the environment. Some examples of dangerous waste materials include oil, fuel, coolant, battery chemicals and air-conditioning refrigerant. • Only use an approved container to collect the waste material. Always seal the container after you drain the fluids.
Page 9
2 Introduction Bill of materials Use this kit to change the specification of the machine. Fig. 1 Kit number: ACX3744410 Description Quantity Number Part number ACX3744870 Chute ramp 6856520 Chute ramp angle stop ACX3202670 Chute ramp bale turn 700013 Carriage bolt - 5/16 x 3/4 71432179 Nut - 5/16 SimplEbale - Scale with quarter turn kit...
Page 11
2 Introduction Description Quantity Number Part number (16) ACX4697380 Shock absorber (17) ACX4652580 Plate Fig. 3 Kit number: ACX3744030 Quantity Description Number Part number 7770324 Carriage bolt - 5/16 x 2 7701717 Hex bolt - 5/16 x 1-1/2 ACX3744040 Frame 705525 Washer - 5/16 ACX4196720...
Page 12
2 Introduction Description Quantity Number Part number (13) 700714586 Nut - 1/2 (14) 700702916 Washer, wide - 3/8 (15) 700710984 Hex bolt - 1/2 x 1-1/4 (16) ACX3744200 Support bracket (17) ACX4196410 Support bracket (18) 700711238 Nut - 3/8 (19) 7700156 Carriage bolt - 1/2 x 1-1/2 (20)
Page 13
3 Installation Preparation 3.1.1 Remove the existing chute Procedure Use the applicable equipment to hold the existing chute. Remove the nuts (3), the washers (2), the bolts (1) and the shock absorber (4). Fig. 1 Remove the nut (3), the washer (2) and the bolt (1).
Page 14
3 Installation 3.1.2 Assemble the SimplEbaler chute (quarter turn) Procedure Install the arm (3) to the frame (1). NOTE: The outer edge of the arm must be 6.25 inches from the outer edge of the frame. Install the bolts (2), washers (4) and the nuts (5). Fig.
Page 15
3 Installation Install the support bracket (1). NOTE: Position the support bracket to the left side of the of the right frame mounting tab when seen from the rear. Install the bolts (2) and (3), the washers (4) and the nuts (5). Fig.
Page 16
3 Installation Install the bale stop (4). NOTE: Position the bale stop and bracket to the right side bolt holes when seen from the rear. Install the support bracket (3). Install the bolts (1) and the nuts (2). Fig. 7 Number Part number Description...
Page 17
3 Installation 12. Install the stop brackets (3). 13. Install the bolts (2), the washers (4) and the nuts (1). 14. Make sure that the parts are loosely assembled. Fig. 9 Number Part number Description Quantity 700714586 Nut - 1/2 700710984 Hex bolt - 1/2 x 1-1/4 ACX3744280...
Page 18
3 Installation 15. Install the load sensors (2). 16. Install the bolts (1). Fig. 10 Number Part number Description Quantity 7701717 Hex bolt - 5/16 x 1-1/2 ACX3744110 Load sensor 17. Install the washers (1) and the nuts (2) and (3). Fig.
Page 19
3 Installation 18. Install the load sensor module (3) and the fastener (2). 19. Install the nuts (1). Fig. 12 Number Part number Description Quantity 67741 Locknut 10-24 102624 Phillips pan head bolt 10-24 ACX3743400 Load sensor module SimplEbale - Scale with quarter turn kit 79037898A_en...
Page 20
3 Installation 20. Move the wiring harness through the holes in the chute frame. 21. Connect the electrical connector to the load sensor module. 22. Install the cable tie (1). Fig. 13 Number Part number Description Quantity 7724347 Cable tie 23.
Page 21
3 Installation Number Part number Description Quantity 700013 Carriage bolt - 5/16 x 3/ ACX3744370 Chute ramp turn 71432179 Nut - 5/16 ACX3744870 Chute ramp SimplEbale - Scale with quarter turn kit 79037898A_en...
Page 22
3 Installation 28. Install the chute ramp angle stops (4) to the chute ramp (1). 29. Install the bolts (2) and the nuts (3). Fig. 16 Number Part number Description Quantity ACX3744870 Chute ramp 700013 Carriage bolt - 5/16 x 3/ 71432179 Nut - 5/16 6856520...
Page 23
3 Installation Installation 3.2.1 Install the mounting brackets Procedure Install the support bracket (1) to the chute. Install the bolts (2), the washers (3) and the nuts (4). Fig. 17 Number Part number Description Quantity ACX3202840 Support bracket 700047 Carriage bolt - 3/8 x 1 700702916 Washer, wide - 3/8 700711238...
Page 24
3 Installation 3.2.2 Install the SimplEbale chute (quarter-turn) Procedure Use the applicable equipment to lift the chute ramp. Install the chute ramp onto the machine. Fig. 19 Install the bolts (3). Install the washer (1), the nut (2), the bushing strap (4).
Page 25
3 Installation Install the bolts (5). Install the washer (2), the nut (1), the bushing strap (4). Install the washer (2) and the nuts (3). Fig. 21 Number Part number Description Quantity 700711238 Nut - 3/8 700702916 Washer, wide - 3/8 704734 Locknut - 3/8 ACX3744900...
Page 26
3 Installation 11. Install the shock absorber, the spacer (5) and the bushing (2). 12. Install the bolt (1), the spacer (5), the washer (3) and the nut (4). Fig. 23 Number Part number Description Quantity 7770837 Carriage bolt - 1/2 x 6 ACX4481300 Bushing 700711557...
Page 27
3 Installation 15. Install the cotter pin (1). Fig. 25 Number Part number Description Quantity 062349 Cotter pin 16. Move the wiring harness through the holes in the chute frame. 17. Install the electrical connector to the load sensor module. 18.
Page 29
3 Installation 19. Install the grommets (1). 20. Power on the Ag CoPilot monitor and navigate to the bale scale run screen. 21. View the load sensors and set the load sensors to zero. Fig. 27 Number Part number Description Quantity 700741601 Grommet...
Page 30
3 Installation 24. Install the washers (1) and the nuts (2) and (3). Fig. 29 Number Part number Description Quantity 705525 Washer - 5/16 71432179 Nut - 5/16 704478 Half nut - 5/16 25. Use the special tool (1) to set up the load sensors (2).
Page 31
3 Installation Calibration 3.3.1 Calibrate the scale Procedure Position a bale with known weight on to the scale. View the scale reading on the Ag CoPilot monitor. Manually enter in a scale offset adjustment on the Ag CoPilot monitor if necessary. Position a second bale with a known weight on to the scale.
