Sleeve, frame and module installation
Make a hole for the sleeve.
Remove all sharp edges that could
damage the compression rubber.
6
Remove any dirt in the sleeve.
Min diameter ø (mm)
Type:
(Max +2 mm, 0,079")
R X 75
115
R X 100
145
R X 125
170
R X 150
199
R X 200
250
4
Insert the sleeve.
7
Lubricate the frame sparsely on
the outside.
Installation instructions
Roxtec R X
ø (in)
4.528
5.709
6.693
7.835
9,843
Size:
Rec. torque
Sleeve
(Nm)
75-200
9
8
Insert the frame into the sleeve.
Max Ø
2
Not OK
1mm
Not OK
Aperture irregularities are
acceptable within min and max
diameters.
5
Tighten the bolts on the sleeve
crosswise, in several turns. Use
the same torque on each bolt.
9
Lubricate the frame thoroughly
on the inside, especially in the
corners.
