  • Page 1 LUMARY HDMI ULTRA-THIN DOWNLIGHT USER MANUAL...
  • Page 3 LUMARY SMART DEVICE User Manual Thank you for choosing Lumary products! Are you ready to get started? Simply download the Lumary App and easily manage your smart devices from your phone or tablet. Our devices easily connect to your home Wi-Fi, allowing you to control multiple devices with just a tap of your fingertips.

  • Page 4: Table Of Contents

    Contents Product & Notes Installation Instructions HDMI Sycn Control Box 7-15 16-29 Application Connection Group Control 30-32 UI Function Introduction 33-36 37-40 Parameter Information 41-42 43-49 App-To-App Voice Control...

  • Page 5: Product & Notes

    HOLE CUT-OUT Get Ready Know your Wi-Fi network and password. Make sure your mobile device is running iOS 13.3 or higher and Android 9.0 or higher. Make sure you're connecting to a 2.4GHz Wi-Fi network (Lumary can't connect to 5GHz networks). ...

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS IMPORTANT： Read all instructions before installing fixtures. Retain for future reference. SAFETY： For your safety, this fixture must be wired in accordance to local electrical codes and ordinances. All work should be done by a qualified electrician. WARNING : Make certain power is OFF from the electrical.Panel before starting installation or attempting any maintenance.Indoor installation only.
  • Page 7 INSTRUCTIONS 1. Turn off the power before installation. Remove the existing fixture if applicable. Determine the location and necessary hole cutout diameter using the supplied table and cut the ceiling hole with the listed approximate diameter(Fig1) HOLE SIZE 4inch:4 5/16'' (110mm) 6inch:6 5/16'' (160mm）...
  • Page 8 3. Insert J-Box through the mounting hole and secure it, connect the fixture power cable to the J-Box. (Fig3) 4. Push the spring-loaded clips into the mounting hole upwards and insert the fixture into it. Release the clips and the fixture will be pulled flush to the ceiling.(Fig4) 5.

  • Page 9: Hdmi Sycn Control Box

    Lumary Smart HDMI Sync Box...
  • Page 10 CONTENTS • IMPORTANT SAFETY INSTRUCTIONSGET- TING • TO KNOW SMART STRIP LIGHTS • USINGYOUR SMART STRIP LIGHTS • TROUBLESHOOTING...
  • Page 11 Reach it. THESE INSTRUCTIONS • For any product problems or report an unexpected situatio during use, please contact the Customer Support at:Support@lumary.tech...
  • Page 12 Packing Catalog Power Adapter x1 HDMI Sync Control Box x1 (for Sync Box) HDMI Cable x1 LED Strip Light x1 (For HDMI Port) Fixing Clips x14...
  • Page 13 Specifications Model L-HSB0A1 Power Supply 100-240VAC,50/60Hz,DC12V/3.5A Strip Light : 21W Max. Power Sync Box: 7W Max. 30pcs /meter Strip Light Length Strip Light : 12.5ft(3800mm) Suitable TV Size 55-65 inch HDCP 2.2Video resolution, HDMI Support to 4K@ 60Hz, HDR 10+ Wi-Fi 2.4GHz Support OS...
  • Page 14 Function Button Description Power switch HDMI input source switch button ZigBee network key Wi-Fi network key Light bar& strip light switch Power indicator Status indicator Channel 1 indicator Channel 2 indicator Channel 3 indicator Power interface Strip light output Light bar output HDMI input channel 1 HDMI input channel 2 HDMI input channel 3...
  • Page 15 Key Operation Instructions Swipe left to turn on the power, the power Power switch indicator light turns white Short press the HDMI channel selection key to HDMI input switch the HDMI input source, the channel indicator flashes in white (Note: the access is source switch always on, if there is no access, it goes out, and button...
  • Page 16 The status indicator is off: initialization is complete. Power Indicator The status indicator lights up white: the device is initialized. The network has been successfully configured, the red light is always on, the network fails or the router has no peripheral or is waiting to Status connect to the network.
  • Page 17 Sync With Input Source Mode of panel is divided into three parts. Configure the device: selects ZigBee devices that is automatical- ly found.Add those devices in the group, drag them to the effective range of the video model, and set the location of the devices to achieve the same frequency color rendering effect.

  • Page 18: Application Connection

    Application Connection 1. Find and isntall the "Lumary" App on App Store,Google Play.
  • Page 19 2. Register a Lumary account. Test@lumary.tech Test@lumary.tech ****** Enter your email address. Log into the App. Note:Please select your region and country.
  • Page 20 3. Connect NOTE: Lumary's products can't connect to 5GHz networks. Steps 1. Open the Lumary App,In the top corner of the Devices screen, click ''+'' and select ''Add Device'' '' Gateway Control '' , click''HDMI'' ,choose Wi-Fi and enter password,click "Next".
  • Page 21 2. Choose Wi-Fi and enter password,click "Next". 3. Confirm the DC12V port on the power adapter is connected and powered on,and click "Next".
  • Page 22 4. Insert the USB LED strip plug into the control box LIGHT1, and click "Next". 5. Make sure the control box switch is turned on, and click "Next".
  • Page 23 6. Confirm the LED strip is breathing slowly ,and click "Next". 7. Connect your mobile phone to device’s hotspot,Lumary-xxxx 13:09...
  • Page 24 8. Click "Lumary-xxxx"and return to Lumary App, The device is adding. 13:11 Lumary-3D2B...
  • Page 25 9. HDMI Sync control box is added. Add Sync light Method 1—Auto Add: Long press the 5S ZigBee button through the Sync control box . When the indicator flashes, the Sync light in breathing mode will be automatically added. If the lights do not enter the distribution mode, the device needs to be reset through the wall switch:...
  • Page 26 Method 2—App add: 1. Click "Gateway Configuration". 2.Ensure that the sub-devices is in the network distribution state...
  • Page 27 3. Search sub-device. Lumary Lumary ZigBee ..ZigBee ..Lumary ZigBiee ..Lumary ZigBee HDM..
  • Page 28 4. The device is added. You can create a group to control the device. Lumary ZigBee Ultra... Lumary ZigBee Ultra... Lumary ZigBee Ultra... Lumary ZigBee Ultra... Lumary ZigBee Ultra... Lumary ZigBee Ultra... Lumary ZigBee Ultra... Lumary ZigBee Ultra...
  • Page 29 Add those devices in the group, drag them to the effective range of the video model, and set the location of the devices to achieve the same frequency color rendering effect. Lumary Lumary Lumary ZigBee H... Lumary ZigBee H... Lumary ZigBee H... Lumary ZigBee H...
  • Page 30 Video Mode can be adjusted as multiple and single color modes, and easy to swap the rendering mode. In Setting, Intensity Selection is used to adjust the brightness of the loading light. Video scene can set as movie or game mode to achieve different requirements.
  • Page 31 We will gradually update the supported devices, please wait patiently. Note: • The Lumary HDMI Sync device uses the Tuya ZigBee protocol. • HDMI Sync video & Musci control for 12 devices. • HDMI Sync control box supports a maximum of 128 Zigbee devices.

  • Page 32: Group Control

    Group Control 1. Log in to Lumary App, tap the smart device and enter into, click " " in the top right corner.
  • Page 33 2. Click "Create Group", then select a device and save. ZigBee...
  • Page 34 3. You can reset the group name and save it, and the group can control devices. ZigBee...

  • Page 35: Ui Function Introduction

    UI Function Introduction Lumary ZigBee UItra-thin Downli... Lumary ZigBee UItra-thin Downli... ZigBee ZigBee Warm White & Cool White Adjust 2700 to 6500K 16 million color adjustment and Dimming 1-100% dimming...
  • Page 36 Lumary ZigBee UItra-thin Downli... Lumary ZigBee UItra-thin Downli... ZigBee ZigBee Music Combined with the built-in rhythm algorithm of the App, the Mic of the Scene mobile phone can recognize the changes DIY scene 8 in the size or tempo of external music or Default Scene 30 sound to realize the rhythm of the light.
  • Page 37 Lumary ZigBee UItra-thin Downli... ZigBee...
  • Page 38 Sleep plan The light to sleep feature makes your lights slowly fade out to lull you into a peaceful slumber. Wake up plan The light to wake-up feature allows you to set the lights to gradually increase in brightness to wake you up gently and naturally with less startle.

  • Page 39: Faq

    2. If my Wi-Fi internet goes down, will Lumary App still work? Lumary products need to be connected to Wi-Fi in order to use them remotely, and the device can be controlled simply using the app via the LAN as well as Bluetooth.For example: on, off, dimming, colour temperature, colors.
  • Page 40 4. Can I share with family and friends?  Yes, you can share access to your Lumary devices. In the Lumary App, from your main device list, click on one of the devices press the "..." button on the top right and click on "Share Device" to give or revoke sharing permissions. In order to share, the other user should already have...
  • Page 41 Make sure your Wi-Fi router is online and in range, and check that you have the latest Lumary functionality by clicking "Check for firmware update" in your device settings. Try to turn off the device >> clear the application cache >> reboot the router >> turn on the device after one minute and check and confirm the device status after five minutes.
  • Page 42 10.What should I do,when I find a problem with the purchased product? Please email us (support@lumary.tech) with your Amazon order ID. We are dedicated to ensuring your 100% satisfaction. Rest assured if the problem is with this product, we'll be more than happy to exchange it for a new one...

  • Page 43: Parameter Information

    Parameter information Name Lumary ZigBee Ultra-thin Downlight A Model L-SD4A1/L-SD6A1(2/4/8/12) Input Voltage 100-130VAC,60Hz Wattage 9W/13W Color Temperature RGB +Tunable White(2700K-6500K ) Lumens 780lm/1000lm Beam Angle 110° Rated Life 25000h FCC ID:2ANDL-ZT3L FCC ID:2ASF2KT-CR31B...
  • Page 44 CAUTION: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 45: App-To-App Voice Control

    Name and Control Each Device by Voice...
  • Page 46 Work With Amazon Alexa 1. Log in to Lumary App, tap the smart device and enter into, click " " in the top right corner. 2. Tap "Alexa" in Third-party Control. 3. Tap "Sign In With Amazon". ZigBee...
  • Page 47 4. Tap "Allow"; 5. Linked successfully, when add new device, there is no need to link again, just discover new device in Alexa.
  • Page 48 To control your Lumary smart device, just ask Alexa. Make sure your devices are already set up using the Lumary app. Things you can say*: "Alexa, discover my devices." "Alexa, turn on the bedroom light." "Alexa, set the bedroom light to orange."...
  • Page 49 Work With Google Assistant 1. Log in to Lumary App, tap the smart device and enter into, click " " in the top right corner. 2. Tap "Google Assistant" in Third-party Control. 3. Tap "Link with Google Assistant". ZigBee...
  • Page 50 4. Click "Agree and link"; 5. Linked successfully, when add new device, there is no need to link again, just discover new device in Google Home.
  • Page 51 To control your Lumary smart device, just say "Hey Google",and ask. Make sure your devices are already set up using the Lumary app. Things you can say*: "Hey Google, turn on all the lights in my bedroom." "Hey Google, turn off the light."...
  • Page 53 Can't connect? Need help? HAVING AN EASY TALK TO US BEFORE YOU RETURN THE PRODUCT WILL FIX A PROBLEM MORE QUICKLY Lumary support: support@Lumary.tech Visit us at: www.lumary.tech...
