Summary of Contents for Maven S.3
- Page 1 MAVEN S.3 SPOTTING SCOPE...
- Page 2 Thank you for purchasing a Maven™spotting scope. With this purchase you have told the world that quality and personality mean more to you than big-brand marketing. Included here are the instructions for getting your scope ready for your first adventure. If you have any questions, please contact us directly at: customerservice@mavenbuilt.com.
- Page 3 S.3S S.3A PARTS OF THE SCOPE: A. Zoom lens eyepiece E. Focus wheel J. Objective lens B. Twist-up, multiple-position F. Tripod collar adjustment knob K. Reticle Eyepiece eyecup G. Tripod adapter mount L. Diopter C. Magnification wheel H. Aim assist groove/nock D.
-
Page 4: Eyepiece Adjustment
Reticle Eyepiece: use the diopter wheel (L) to bring the reticle into focus. EYE RELIEF ADJUSTMENT The eyecup on your Maven spotting scope zoom eyepiece twists up so that any viewer can see the full field-of-view, with or without eyeglasses. For best viewing with eyeglasses, twist the eyecup (B) all the way in (clockwise) until it stops. -
Page 5: Mounting To A Tripod
MOUNTING TO A TRIPOD Mount your scope to a tripod or a vehicle window mount for stable viewing. This optic comes with an integrated Arca-Swiss tripod adapter mount and a standard ¼” x 20 thread. If your tripod is Arca compatible, simply attach the scope directly to the tripod head;... - Page 6 AIMING To assist in locating your target object, use the aim assist groove/nock located on the objective lens shade. 1. Adjust the magnification wheel to its lowest setting. 2. Align the aim assist groove/nock toward your target. FOCUSING 1. If using a zoom eyepiece, set the magnification to the desired power.
- Page 7 REMOVABLE EYEPIECE This optic is designed with a removable eyepiece. You may need to remove this in order to clean the optic properly. To remove: 1. Turn the eyepiece lock ring counter-clockwise to unlock. 2. Rotate the eyepiece counter-clockwise until it stops. 3.
- Page 8 EYEPIECES This spotting scope is fitted with an eyepiece lock ring (D) and allows the use of different eyepieces. A zoom eyepiece (A) allows the user to increase or decrease magnification and is great for spotting wildlife or observing nature. A reticle eyepiece (K) is helpful when spotting for shooting applications.
- Page 9 S.3 (MOA) S.3 (MIL) @ 24x @ 24x Subtension Dimensions...
-
Page 10: Lens Shade
Note: the objective lens cap can be used while the lens shade is extended. CARING FOR YOUR SCOPE: To maintain maximum performance of your Maven spotting scope, keep the lenses free of dirt, dust, and grit. Protect the lenses with a case or the included lens covers. It is... - Page 11 1. Hold the eyecup and twist counter-clockwise until the eyecup is removed from the scope frame (zoom lens only). Click to view our Maven Minute 2. Rinse with water. playlist. Click “How to Clean Optics” for a video on cleaning optics.
- Page 12 We don’t care where or when you bought it or if it was your fault or not – if it says Maven, we will take care of it. *Warranty does not cover loss, deliberate damage, or cosmetic damage that does not hinder product performance.
- Page 13 800-307-1109 / 1042 Pronghorn Dr. Lander, WY 82520...
