- Page 1 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD FLYSPARK SF-Z5 USER MANUAL FLYSPARK USER MANUAL SF-Z5...
-
Page 2: Table Of Contents
目录 1 PRODUCT INTRODUCTION 1.1 FLY SPARK DYERYIEW 1.2 PRODUCT ACCESSORIES 1.3 SPARK FABRICA GRANULE 2 TECHNICAL PARAMETER 3 ANGLE DEFINITION 4 FIXED INSTALLATION SCHEMA 5 ON-SCREEN OPERATION GUIDE 5.1MENU SETTING 5.2 MENU SETTING 5.3DMX PARAMETER LIST 6 OPERATION WARNING 6.1 ENVIRONMENTAL REQUIREMENTS 6.2SAFETY TIPS 7 OPERATE THE MACHINE... - Page 3 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD DISCLAIMER Please read the manual carefully before installing and using this product. Failure to read or comply with this manual may result in injury to products and personnel, and Spark Fabrica shall not be responsible for this. This product is a professional machine, we do not assume any responsibility for accidents or losses caused by the use or maintenance of this product by personnel without professional training and permission.
-
Page 4: Product Introduction
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 1 PRODUCT INTRODUCTION This product is a special effects device. For professional use only. This product is a special effects device for the dynamic and static simulation of cold pyrotechnics. Using CST technology, the tailor-made metal powder is heated to produce a dynamic and static fountain of silver sparks, which is safer than traditional cold fireworks. -
Page 5: Product Accessories
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 1.2 PRODUCT ACCESSORIES 1.6 Meter Power Plug / 3 Meter Power Cable 3 Meter DMX Cable User Manual NOTICE Carefully unpack! Check and make sure the item is intact. 1.3 SPARK FABRICA GRANULE A Kind Of Special Metal Powder With Full Spark And Less Residue, No Smoke, No Odor And No Toxic Gas During Use. -
Page 6: Technical Parameter
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 2 TECHNICAL PARAMETER Manufacturer SPARK FABRICA Identification Name FLYSPARK Model SF-Z5 100-120V，60HZ Input Voltage & Frequency 200-240V，50HZ Current Limiter Specifications 10A,100-120V / 6.3A,200-240V Constant Current 6.4A,100-120V / 3.2A,200-240V AC Power Nominal Total Power Consumption 700W Power Input Connector SEETRONIC... -
Page 7: Angle Definition
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 3 ANGLE DEFINITION The spray angle of the FLYSPARK is ±90°. From the viewer’s side, it is defined as 13 spray directions, respectively labeled from left to right ,as shown below: 4 FIXED INSTALLATION SCHEMA ( BOTTOM SCREW MOUNTING HOLES ) FLYSPARK USER MANUAL SF-Z5 |... -
Page 8: On-Screen Operation Guide A6
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5 ON-SCREEN OPERATION GUIDE SWIPE AREA INCRESE SAVE MENU DECREASE MENU BUTTON, short press to enter menu setting. DECREASE BUTTON, used to decrease the setting value or switch mode OFF/ON. INCREASE BUTTON, used to increase the setting value or switch the mode OFF/ON. SAVE BUTTON, used to save after setting. -
Page 9: Menu Setting A7
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.1 MENU SETTING SETTING RANGE Temperature 400℃-800℃ DMX Channel DMX Address 1-512 Safety Address OFF/501-512 Setting Density Maximum/Minimum/moderate Angle offset -30-30 MaxAngle Limit 90-0 MinAngle Limit -90-0 OFF/ON RFID OFF/ON Auto Heat Advanced OFF/ON Tilt Sensor OFF/ON TFT BackLight... - Page 10 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.2 MENU SETTING When the icons are all green,it indicates normal operation and when the icons are NOTICE yellow,it indicates an abnormality. chip temperatrue Blower Motor Tilt Sensor Shaft Motor Pcb Temperature Hopper Motor Temp .sensor Time Remaining 5.3 DMX PARAMETER LIST...
- Page 11 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD CHANNEL 1 （ CH1） : Manual Angle setting， spark output can stay at any angle from 90° to -90°. As shown in below: ANGLE NUMBER ANGLE DMX VALUE 90° 75° 60° 45° 30° 15° 0°...
- Page 12 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 0° Spark at regular intervals CH3 effective time 21-22 15° Spark at regular intervals CH3 effective time 23-25 30° Spark at regular intervals CH3 effective time 26-28 CH3 effective time 29-30 45° Spark at regular intervals Spark at regular intervals CH3 effective time 31-33...
- Page 13 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD -30°~0°~-30° 10 quick swing 92-94 75°~0°~75° 10 quick swing 95-96 60°~0°~60° 10 quick swing 97-99 100-101 45°~0°~45° 10 quick swing 10 quick swing 102-104 30°~0°~30° -90°~0°~-90° Slow swing 2 times 105-107 -75°~0°~-75° Slow swing 2 times 108-109 110-112 -60°~0°~-60°...
- Page 14 www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 164-165 -90°~-30°~-90° Slow swing 3 times -90°~0° Slow swing angle decrease 166-168 90°~0° Slow swing angle decrease 169-170 -90°~90° Slow swing angle decrease 171-173 0°~-90° Slow swing 1 time 174-175 -90°~0° Slow swing 1 time 176-178 0°~90°...
-
Page 15: Operation Warning
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 6 OPERATION WARNING Please read the following precautions carefully before operating this machine. 6.1 ENVIRONMENTAL REQUIREMENTS 危 险 Do not mount the product on flammable surfaces (linoleum, carpet, wood, paper.card- board, plastic, etc.) 危 险 Do not use in a confined space. -
Page 16: Safety Tips A14
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 6.2 SAFETY TIPS Make sure to connect the ground wire properly to avoid electric shock. If water enters or covers the bottom of the machine, it will cause machine to malfunc- tion or electrical leakage. Make sure that the bottom of the machine is far enough away from the impounded surface water on rainy days, so as to prevent the water from entering the inside of the machine Do not touch sparks. -
Page 17: Operate The Machine
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 7 OPERATE THE MACHINE 7.1 PREPARATION Place the machine on a flat ground, level surface with a recommend maximum inclination angle of no more than 15 degrees. 7.2 ADD GRANULE A consumable designed special granule for cold spark machine to create cold fireworks on stage *Tear a bag of granule, and pour the granule from the feeder at the top of the machine *Pour the granule off the feeder instead the output... -
Page 18: Connecting The Machine
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 7.3 CONNECTING THE MACHINE Connecting the power cable and DMX signal cables *The first unit is connected to the power plug *Connect the other machine in parable with the power connect cable *Parallelise other machines with DMX signal cables. *Connect PYRO SIM CONTROLLER or DMX512 console. -
Page 19: Default Setting
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 7.4 DEFAULT SETTING REALM DEFAULT VALUE Temperature 400℃-800℃ DMX Channel DMX Address 1-512 Safety Address 0-512 Density Maximum/Minimum/moderate Maximum Auto Heat OFF/ON Tilt Sensor OFF/ON TFT BackLight OFF/ON Restore Defaults OFF/ON *Turn on power *Check machine status icons (refer to 5.2 Status Icons) When the icon shows yellow, it means that the machine is in abnormal condition, and can only be used again after professional inspection and repair. -
Page 20: Dmx Address Setting
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 7.5 DMX ADDRESS SETTING Set the DMX address of the spark machine according to the channel mode: *In 6-channel mode, please set the DMX address to 1, 7, 13, 19 ..Do not set the DMX address repeatedly. SWIPE RFID TIME CARDS To avoid machine malfunction or other safety accidents caused by poor quality consumables, Only the RFID time cards provided by our company are allowed. -
Page 21: Turn On The Heating Function
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 7.7.2 TURN ON THE HEATING FUNCTION The DMX value for the heating function of the second channel is 240~255, and it takes about 5 minutes to preheat after power on. When the heating function is on, the HEAT indicator on the machine will light up in red and the READY indicator will flash green at the same time to indicate that the machine is heating up. -
Page 22: Clear Material
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD Suitable fire extinguishers are as follows: 1.Any items similar to sand or soil can be used to cover and put out the fire. 2.Please use Class D Fire extinguishers for metal materials on fire. 7.8 CLEAR MATERIAL This machine has the clear material function, which can clean up the consumable the raw material in the feeder and avoid blockages. -
Page 23: Failure Handling
www.sparkfabrica.com CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 9 FAILURE HANDLING ERROR CODE DESCRIPTION SOLUTION System Error System Error: Replace main board E0 Storage Fail StorageFail 1.Restart machine to clear alerts,stop operating for 15 minutes until temperature returns to normal. Blower motor protection/ Motor Protect 2.Check wire connection of motor disconnected... - Page 24 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
