- Page 1 Operating Instructions Translation of original instructions Makro•Grip Ultra (410 S) ® Mechanical Screw Jack I t e m n o . 8 2 5 8 6 LANG Technik GmbH • Albstraße 1-6 • D-73271 Holzmaden • www.lang-technik.de • Version 2022/11...
- Page 2 Errors and omissions in the documentation are excepted. All rights to this documentation remain with LANG Technik GmbH. Modifications to the product: In the event of modifications to the product by the customer, the warranty is void.
-
Page 3: Table Of Contents
Contents Chapter 1 Product Description On page Unit Areas of application Accessories Chapter 2 Technical Data Dimensions Material Scope of delivery Maintenance and repair Chapter 3 Design and Function Assembly Chapter 4 Maintenance Malfunctions/Error Chapter 5 Warnings Intended Use Personnel Requirements Protective Equipment and Safety Chapter 6 Decommissioning Disposal... -
Page 4: Unit
Product Description Unit The mechanical screw jack is an accessory item for extending the Makro•Grip Ultra clamping ® system. Workpieces that are susceptible to deformation, thin-walled and/or have high surface roughness and dimensional accuracy requirements are a major challenge. The purpose of the mechanical screw jack is to have a positive impact on the quality of the part being machined and to ensure maximum process reliability. -
Page 5: Chapter 2 Technical Data
Technical Data Dimensions Screw jack Clamping screw Actuating rod Designation Item number Stroke Clamping range Weight (kg) (mm) Mechanical 82586 80* - 410/610/810 screw jack (set) *Because of the center mounting of the screw jack, the minimum clamping range increases to 80 mm (clamped in the toothing). Without mechanical screw jack, the minimum clamping range is 40 mm. -
Page 6: Scope Of Delivery
If the clamping capacity of the actuating rod decreases, both O-rings (8x3 NBR70) must be replaced. In case of damage or faults, please contact LANG Technik GmbH directly. LANG Technik GmbH • Albstraße 1–6 • D-73271 Holzmaden • Phone: +49 7023 9585-0... -
Page 7: Chapter 3 Design And Function
Design and Function Assembly ➊ Prepare the base bodies of your Makro•Grip Ultra clamping system for mounting of the ® support by removing the plastic covers that are no longer required. To do this, carefully push in the plastic covers on the side with a screwdriver and lever them out. - Page 8 Design and Function ➌ Take the actuating rod required for your setup and place the clamping elements on the actuating rod between the two O-rings in the following order. Shim – O-ring – O-ring – Shim ➍ Now push the actuating rod together with the clamping elements into the channel of the base body and screw them loosely into the support.
-
Page 9: Use
Design and Function ➊ Make sure that the pendulum support is below the support surface of the workpiece to be clamped by lowering the pendulum support with the clamping screw loosened, which is done by unscrewing the actuating rod. ➋ Clamp the workpiece in the Makro•Grip Ultra clamping system and move the pendulum ®... -
Page 10: Malfunctions/Error
Maintenance / 5 Warnings Malfunctions/Error If the actuating rod is overtightened, the part to be machined can be forced out of the clamping jaws. Care should be taken to ensure that the support is only fitted lightly to the component to be machined. To ensure friction-free use, make sure that all dirt has been removed during assembly and the components are lightly oiled. -
Page 11: Chapter 6 Decommissioning
Decommissioning Disposal According to Directive (EU) 2018/851 For disposal, observe the country-specific disposal regulations. LANG Technik products do not belong in household waste. Failure to comply is an offense. Accessories and packaging are recycled in an environmentally friendly manner Product... -
Page 12: Chapter 7 Explanation Of Symbols
Explanation of Symbols Symbols Please pay attention to the following warning symbols Read all the operating instructions carefully before commissioning for the first time and keep it in a safe place for future use Please read and follow the technical and safety instructions The use of protective gloves made of tough, resistant material is recommended A helmet and safety goggles are recommended for personal safety... - Page 13 LANG Technik GmbH Albstraße 1–6 D-73271 Holzmaden Germany www.lang-technik.de | info@lang-technik.de Sales: sales@lang-technik.de | Phone: +49 7023 9585-0...
