Zhuneng Technology Energize Lab Eilik User Manual

Hide thumbs

Advertisement

Table of Contents

Hello~
User Manual V1.5
E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Energize Lab Eilik and is the answer not in the manual?

Questions and answers

Summary of Contents for Zhuneng Technology Energize Lab Eilik

  • Page 1 Hello~ User Manual V1.5...

  • Page 2: Table Of Contents

    CONTENT IN THE BOX 1. Get to Know Eilik 2. Interact with Eilik 3. Games & Skills 4. One More Eilik, Way More Fun 5. Safety & Security Scan to Read 한국어 설명서를 읽 スキャンして日本 扫码阅读中文 English Manual 으려면 스캔하세요 語の説明書を読む...

  • Page 3: In The Box

    IN THE BOX 1. Eilik x1 2. User Manual x1 5. Food Toy x5 (Random) 3. USB-C Cable x1 6. Magnet x5 4. Conductive Tab x1 7. Double-side Tape x9...

  • Page 4: Get To Know Eilik

    1. Get to Know Eilik 1.1 Body & Button Touch Sensor Speaker (Head) Vibration Sensor Touch Sensor (Back) Display USB-C Port Collar Button Magnetic Pogo Pin Touch Sensor (Belly) Infrared Sensor Heart Mode (Default) Left or Right Dance to Beat Talking Toy Eilik ≥1 Settings...
  • Page 5 1.2 Functions Tap the head to enter the The Collar Button selected function. Long press 3s+ to turn ON and OFF. Upon activation, Eilik will initiate an animated display accompanied by audio, while subsequently exhibiting left and right rotational movements of its head, arms and body.
  • Page 6 1.3 Charge A charging time of 1-1.5 hours is good for Eilik. Two Charging Statuses While Eilik is on While Eilik is off When the screen is off (Shutdown or Sleep), touch the head to check the two charging statuses. If Eilik does not display any charging status, please replace the USB cable and try again.

  • Page 7: Interact With Eilik

    2. Interact with Eilik 2.1 Different Interations 1. Pet head 2. Tickle belly 3. Rub back 4. Hit head 5. Slap table 6. Take off the ground Try harder Try harder To soothe Eilik, hold its back and pet its head.(P26) Check out P18-19 for Settings of the above interactions 4, 5, 6.
  • Page 8 2.2 Heart Mode & Idle Mode Later on Heart Mode (Default) Idle Mode Sleep Eilik enters Heart Mode (Interactive Later on Mode) by default after startup. In the absence of interaction, Eilik will transition to Idle Mode, engage in self-amusement, and eventually enter a sleep state.
  • Page 9 2.3 Emotion Engine Tips: If your Eilik appears angry upon arrival, gently pet Eilik on the head to calm it down. Or, enter the Settings menu to turn off the anger state. (Refer to P18-19) Normal back/belly Pat head Touch back/belly Happy Hit head...

  • Page 10: Games & Skills

    3. Games & Skills 3.1 Introduction Tap to confirm Press to switch functions Heart Mode (Default) Left or Right Dance to Beat Talking Toy Monster Shooter Fishing Game Puppet Toy Festivals Future updates will be available via Eilik software. Countdown Timer Pomodoro Timer Settings...
  • Page 11 3.2.1 Left or Right 1. Guess which hand 2. Repeat guessing Wrong! Left or right Try again!
  • Page 12 3.2.2 Dance to Beat 1. Create rhythms by clapping 2. Eilik will listen to the beat and hands, a metronome or a speaker dance on different rhythms Fast Medium Slow The dance will last for 3 minutes; touch the head to stop dancing.
  • Page 13 3.2.3 Talking Toy 1. Recording 2. Repeating How do you do! How do you do!
  • Page 14 3.2.4 Monster Shooter 2. Aim and shoot 1. Select weapon 3. Level up Aim and shoot Level Up Press the Collar Button to exit the game. This is an intense and fast-paced shooter game to train your reaction. Choose from a wide range of awesome weapons, shoot at evil monsters and protect our base.
  • Page 15 3.2.5 Fishing Game 2. Quickly turn Eilik's body in the 1. Cast a fishing rod arrow direction on the screen Wait for a moving buoy Keep the buoy in the middle until (fish is hooked) the fish is exhausted Level Up Rotate body If the buoy swings violently, the fish will be off the hook.
  • Page 16 3.3.1 Puppet Toy 1. Rotate the head or hands 2. Tap the head to switch to pose expression groups Next Previous...
  • Page 17 3.3.2 Countdown Timer 1. Rotate hands to set time 3. A bell ringing, time's up 18 min 2. Tap to confirm 4. Tap to stop...
  • Page 18 3.3.3 Pomodoro Timer 1. Rotate hands to set 3. Rotate hands to set worktime breaktime 25 min 5 min 2. Tap to confirm 4. Tap to confirm There will be a prompt sound to remind you of the time. You can also touch the head to check the time.
  • Page 19 3.3.4 Festivals 1. Tap to enter menu 2. Select a mode Previous Next Touch head Touch back Touch belly to play default animations to customize messages Eilik'll pass the word Default I will always be Animation here with you. I will always be here with you.
  • Page 20 3.3.5 Settings 1. Rotate hands to 3. Tap head to adjust the relative confirm settings. settings. ON/OFF ON/OFF 2. Tap BELLY to switch Check next page to see more Settings the settings interface. interface details.
  • Page 21 In Settings, tap Eilik's back to display the ID number. ID number KSDMGR-0000000001 Settings Interface Brightness Volume Sensitivity to height Sensitivity to quake When turned off, Eilik will When turned off, Eilik not react to the base leaving will not respond to any the flat surface.

  • Page 22: One More Eilik, Way More Fun

    4. One More Eilik, Way More Fun Snap! 1. Set all Eilik in default Heart Mode, snap to connect.
  • Page 23 Snap! 2. Press any collar 3.Tap any Eilik's button to switch head to start or functions. confirm.
  • Page 24 4.1 Eilik Duo Eilik Theater Crime Patrol Dance to Beat Puppet Toys...
  • Page 25 Eilik Theater Tap any touch sensor to start Crime Patrol Note: Avoid the Tap to disarm criminals distraction props like, within a limited time bomb, candy cane, etc. Dance to Beat Puppet Toy Refer to page 10 Refer to page 14...
  • Page 26 4.2 Eilik Party Dominoes Song and Dance Crime Patrol Dance to Beat Puppet Toys...
  • Page 27 Dominoes Tap any touch sensor Try another move to change moves Song and Dance Tap any touch sensor Try another song to change dance Crime Patrol Dance to Beat Refer to page 10 Refer to page 23 Puppet Toy More games are coming... Refer to page 14...

  • Page 28: Safety & Security

    5. Safety & Security 5.1 Precautions 5.1.3 Hover Detection Eilik has an infrared sensor at the 5.1.1 Force Reboot base that triggers fear and even crying If Eilik is STUCK or frozen after when lifted off the ground. To comfort booting, hold down the button for 15s Eilik, simply hold it by the back and to Force Reboot.
  • Page 29 5.1.4 Firmware Update Firmware Update is the operation of upgrading the Eilik firmware to the latest version, generally used to add new features, improve performance, fix bugs, or enhance device security. (Recommend timely updates!) Start to Update Download Software Connect to PC energizelab.com/download Don't unplug the USB-C cable or move...
  • Page 30 5.1.5 Reset Procedure Note: This operation is generally utilized to address the Failure to Boot issues such as unresponsiveness, automatic shutdown after booting, or a blank startup screen. Its purpose is to restore the normal Conductive tab functioning of Eilik. R side Use the Conductive tab R side...
  • Page 31 5.1.6 Format SD Card This method is to COMPLETELY FORMAT the SD card. FORMAT All the contents of the SD card will be ELIMINATED. Please operate with caution. SD CARD Use the Conductive tab L side to cling to the Magnetic Pogo Pin on the left side of Eilik.
  • Page 32 5.2 Security Instructions Improper use of the product can easily do not put this product in the outside cause damage to the product or may unmanned car or other sun exposure endanger personal and property safety. places. Please keep and use this product in 8.
  • Page 33 5.3 Warranty Policy Energize Lab provides a 90-day Product in full and final settlement of Warranty Policy. The specific warranty Energize Lab's obligations under this services are as follows: warranty. 1. During the Limited Warranty period, Energize Lab will repair or replace any Energize Lab will not provide warranty parts of the Product that are defective services in the following circumstances:...
  • Page 34 5.4 Regulatory Compliance on a circuit different from that to which FCC Compliance Statement the receiver is connected. This device has been tested and found ● Consult the dealer or an experienced to comply with the limits for a Class B radio/TV technician for help.
  • Page 35 EU Declaration of Conformity EU WEEE Statement Shenzhen Zhuneng Technology Co., The symbol means that this product Ltd. hereby declares that this device shall be disposed of separately from is in compliance with the essential household waste according to local laws requirements and other relevant and regulations in the EU.
  • Page 36 TO LEARN MORE VISIT: energizelab.com NEED SOME SUPPORT VISIT: energizelab.com/support JOIN OUR COMMUNITY: Designed by Energize Lab, assembled in China. Copyright © 2023 Shenzhen Zhuneng Technology Co., Ltd. All rights reserved. Energize Lab and Eilik are trademarks of Shenzhen Zhuneng Technology Co., Ltd.
