- Page 1 USER MANUAL High Precision Rain Sensor Model No. HCS012ARF Welcome to the RAINPOINT family! Please read the manual before using to learn about the features and functions.
-
Page 2: Table Of Contents
Contents Contents in the box Introduction 2.1 Product Overview 2.2 Specification 2.3 Product Features Connection and Installation 3.1 Rain Sensor Connection 3.2 Rain Sensor Installation App Features and Functions 4.1 Device Home Page 4.2 Basic Setting 4.3 Charts Troubleshooting Precautions Warranty Policy FCC Statement Customer Support... -
Page 3: Contents In The Box
1. Contents in the box 1 X HCS012ARF High Precision Rain Sensor 1 X User Manual 3 X Stainless Steel Screw 1 X Warranty Card -01-... -
Page 4: Introduction
2. Introduction 2.1 Product Overview Battery Cover 2.2 Specification Weight: 189g Rainfall Range: 0-9999mm Accuracy: ±0.1mm Data Reporting: Every 3 mins Wireless Range: 120m Powered by: 3*AA batteries (Not included) 2.3 Product Features New rain bucket design, automatically drain rainwater. Real time rainfall accurate measurement, in/mm switchable. -
Page 5: Connection And Installation
3. Connection And Installation 3.1 Rain Sensor Connection Insert the batteries. -03-... - Page 6 On the APP, select the button on the top right corner of the APP home page to add device, or you can go to the hub's home page and use "Sub-devices" to add devices. -04-...
- Page 7 Enter the "Add Device" page, click on , or click on in the upper right corner, scan the QR code in bottom of the manual or on the device to connect to network. Scan to connect 0230012200 -05-...
- Page 8 Select "Next" and start searching devices. At the same time, insert the batteries. Keep the Rain Sensor and the hub close to each other so they can connect automatically. After successfully connecting, precipitation for an hour is displayed in th emiddle of the screen, and precipitation for the last 24 hours, 7 days and the entire period is displayed at the bottom.
-
Page 9: Rain Sensor Installation
3.2 Rain Sensor Installation Horizontal placement. Note: Please try to place the rain barrel horizontally on a flat surface, not at an angle. The equipment should be placed smoothly and should not be shaken otherwise it will affect the accuracy. -07-... -
Page 10: App Features And Functions
4. APP Features And Functions 4.1 Device Home Page Setting: Basic settings for the Rain Sensor. Cumulative precipitation in one hour. Cumulative precipitation for the past 24 hours, 30Days and 12Months. Charts: Check the accumulate data in bar Charts. -08-... -
Page 11: Basic Setting
4.2 Basic Setting In the basic settings, you can check and manage the device information, such as name, interface and description. 4.3 Charts Select Charts to view the hourly, daily or monthly rainfall that has passed through this sensor. -09-... -
Page 12: Troubleshooting
Do not mix old and new batteries or different types of batteries. Please place the rain barrel horizontally to avoid inaccurate readings. 7. Warranty Policy RainPoint provides a 1-year limited warranty on this product against manufacturing defects in materials and workmanship. -10-... -
Page 13: Fcc Statement
8. FCC Statement (FCC ID: 2AWDBHCS012ARF) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. FCC Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. -
Page 14: Customer Support
If you find it difficult to set up and want to watch the setting tutorial video, please subscribe to our channel RainPoint on YouTube. Or scan the QR code to visit the RainPoint channel on YouTube quickly. If the app and the user manual don’t have what you’re looking for, and need some help about Rainpoint, please contact us by LOT NO.: XXXXXX (on the back of the device) - Page 16 Need Help ? Scan the QR code for more help. or Email： support@rainpointonline.com...
