WS036A Professional WiFi Weather Station
1.Introduction
Thank you for your purchase of the WS036A Professional WIFI
Wireless Weather Station. The following user guide provides step by
step instructions for installation, operation and troubleshooting.
2.Warnings and Cautions
Warning: Any metal object may attract a lightning strike, including
your weather station mounting pole. Never install the weather station
in a storm.
Warning: Installing your weather station in a high location may
result in injury or death. Perform as much of the initial check out and
operation on the ground and inside a building or home. Only install the
weather station on a clear, dry day.
3.Getting Started
The WS036A weather station consists of a display console, a sensor
array with Integrated Outdoor Sensor, and mounting hardware.
User Manual
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS036A and is the answer not in the manual?

Questions and answers

Related Manuals for UCTECH WS036A

Summary of Contents for UCTECH WS036A

  • Page 1 Only install the weather station on a clear, dry day. 3.Getting Started The WS036A weather station consists of a display console, a sensor array with Integrated Outdoor Sensor, and mounting hardware. - 1 -...

  • Page 2: Parts List

    3.1 Parts List The weather station consists of the following parts (as referenced in Figure 1 ). Item Image Display Console Frame Dimensions : 6.5X 5.32X 0.71inch (165×135×18mm） LCD Dimensions: 5.12 x 316inch(130×80mm) Manual Power Adapter Figure 1 3.4 Display Console - 2 -...
  • Page 3   3.4.1 Layout of Display Console The following illustration shows display console features in normal mode as below : 1. Wind direction icon 10. Indoor Humidity display 2. Wind gust display 11. Moon Phase and Weather 3. Wind average display forecast icon 4.
  • Page 4 1. Plug in the display console with power adapter. BL ON will display in the time area for three seconds when powered up. Note: It is recommended to plug in the power adapter to reduce the battery consumption and extend the service life. 2.
  • Page 5 Figure 4 Recover the battery door, and unfold out the desk stand to place the console in the upright position Note: The battery is a back-up of weather station console, saving console settings when powered off from adaptor. Note: The transmitter of Wifi 2.4G & other wireless functions can not work when using the battery.

  • Page 6: Sensor Operation Verification

    Note: Do not press any button until all the remote sensors report in the display screen, otherwise the display console will terminate to connect with remote sensors. Note: While in the search mode, the remote search icon will be constantly displayed until all the measured values received. The console will automatically switch to the normal mode from which all further settings can be performed.

  • Page 7: Display Console Operation

    3. Verify proper operation of in/outdoor temperature. Verify the indoor and outdoor temperature match closely with the console and sensor array in the same location (about 5 to 10’ (1.5 to 3 meters) apart). The sensors should be within 4°F /2°C (the accuracy is ± 2°F/1°C).
  • Page 8 While in Normal Mode, press (do not hold) the SET key to enter the Quick Display Mode as follows: once for time, time/week and second Twice for rainfall three for pressure four for outdoor temperature 1. Time, Time/Week and Second. Press the CHANNEL/+ or MAX/MIN/- key to toggle between time, time/week and second.
  • Page 9 1. 12/24 Hour Format (default: 12h). Press the SET key again to adjust the 12/24 hour format setting. Press the CHANNEL/+ key or MAX/MIN/- key to change between 12 hour and 24 hour format. 2. Change Hour. press the SET key again to set the hour. Press the CHANNEL/+ key or MAX/MIN/- key to adjust the hour up or down.
  • Page 10 CHANNEL/+ key or MAX/MIN/- key to switch between °F and °C units of measure. 10. Wind Speed Units of Measure (default: mph). Press the SET key again to change the wind speed units of measure . Press the CHANNEL/+ key or MAX/MIN/- key to toggle the wind speed units between m/s, km/h, mph, knots or bft.
  • Page 11 Hemisphere (NOR) or Southern Hemisphere (NOR). (Refer to 5.0 Final Installation of Sensors) 7.3 Sensor Search Mode If Integrated Outdoor Transmitter data is lost, touch and hold the CHANNEL/+ button for 3 seconds, the search icon will be displayed constantly for 3 minutes. Once the signal is reacquired, the remote search icon will turn off, and the current values will be displayed.

  • Page 12: Snooze Mode

    Note: The Maximum values will display the current values after reset. 7.5.2 Min Record Viewing and Reset Press the MAX/MIN/- key again (do not hold), the MIN icon will be displayed. Press the SET key to view min values of pressure (ABS or REL), outdoor temperature and humidity (feels like or dew point), and indoor temperature and humidity Press the MAX/MIN/- key for three seconds to clear all Min...
  • Page 13 7.6.1 Adjustable Brightness of Backlight There are 3 levels of brightness of display backlight. When the backlight is on with adapter, press SNOOZE key to switch between the 3 levels. In the brightest backlight of 3 levels, press the SNOOZE key to turn off the backlight.

  • Page 14: Setting The Alarms

    8.1 Alarm Triggered When an alarm condition is exceed, the alarm icon will flash (visual) and the alarm beeper will sound (audible). To silence the beeper, press any key. 8.2 View High/Low Alarms Value To view the current alarm settings, press the ALARM key to enter the alarm mode.
  • Page 15 To save the alarm setting and proceed to the next alarm parameter, Press (do not hold) the SET key. To adjust the alarm parameter, press the CHANNEL/+ key or MAX/MIN/- key to increase or decrease the alarm settings, or press and hold the CHANNEL/+ key or MAX/MIN/- key for three seconds to increase or decrease the alarm settings rapidly.
  • Page 16 1.Alarm hour(alarm 1) 14.Outdoor dew point HI alarm 2.Alarm minute(alarm 1) 15.Outdoor dew point low alarm 3.Alarm hour(alarm 2) 16.Rainfall (1h) HI alarm 4.Alarm minute(alarm 2) 17.Rainfall (24h) HI alarm 5.Wind Gust HI alarm 18.Absolute pressure HI alarm 6.Wind average HI alarm 19.Absolute pressure low alarm 7.
  • Page 17 In normal mode, press and hold the ALARM key for three seconds to toggle the BZ ON (beeper on) or BZ OFF (beeper off) depending on the current setting. Display console return to normal mode without any operation in three seconds.
  • Page 18 Pressure is rising and the previous Sunny condition is partly cloudy. Pressure is falling and the previous condition is sunny Partly or Pressure is Cloudy rising and the previous condition is cloudy Pressure is falling and the previous condition is partly Cloudy cloudy or Pressure is rising and the...

  • Page 19: Moon Phase

    10.3 Rate of Change Icon  The rate of change icon indicates if the temperature and humidity are increasing, decreasing or steady, as shown in . If the arrow points upward, the temperature is increasing at a rate of +2°F per 30 minutes (or greater), or humidity is increasing at a rate of +5% per 30 minutes (or greater).

  • Page 20: Specification

    adaptor at the same time (Take out batteries before starting the reset operation). 13. Specification 13.1 Measurement Specifications The following table provides specifications for the measured parameters. Measurement Range Accuracy Resolution Indoor 0 to 60 °C ± 1 °C 0.1 °C(°F) Temperature (32 to 140°F) (±...

  • Page 21: Fcc Statement

    Adapter: 5.9V~500mA(included) Battery life: Minimum 12 months for sensors (use lithium batteries in cold weather climates less than -20°C(-4°F). FCC Statement Statement according to FCC part 15.19: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: 1.
  • Page 22 • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Warning: The user should be 20CM away from the product when it is used.
