Ness iGate Prime 4G Manual

iGate Prime 7 4G
* ALWAYS TEST THE UNIT ON SITE BEFORE
SIM Preparation
1
A Nano sized active SIM card is required
(not included).
This product requires a regular voice and
SMS SIM card, a data-only SIM will not
work.
Relay Connections
4
Gate
Controller
Relay1
N/C
COM
N/O
N/C
COM
N/O
Optional
Separate
Exit Button lock PSU
Relay 2
PRESS
TO EXIT
N/C
LIGHTNING PRONE AREAS MUST USE SURGE PROTECTION
FOR POWER SUPPLY!
1
- Advanced GSM Switch
INSTALLATION TO AVOID RE-STOCKING FEE
Site Wiring
2
iGate Enclosure
(Install at height to allow the
internal antenna to find signal.)
DC Power Cable
(1.0mm2 – 8m MAX)
Keep PSU as close to the unit as possible
& Do not share PSU with other devices.
Note:
Can be purchased separately.
Driveway
Gates
Magnetic Lock
See overleaf for
more PCB details
Turn Over
SITE SURVEY
PSU not supplied.
24v DC 1.2A peak.
Power
3
POWER CABLE
TIP:
to power the unit.
Please use the following cable:
Up to 2 metres ( 6 feet )
Up to 4 metres ( 12 feet ) – Use minimum 0.75mm
Up to 8 metres ( 24 feet ) – Use minimum 1.0mm
INGRESS PROTECTION
12-24V DC input
(Polarity Protected)
106-885
iGate Prime 4G
Please read this entire manual before installing this
product. A full comprehensive manual is available on
our website for additional information.
Ensure there is good
4G signal on site. 4G
units will fall back to
3G service in some
countries.
This product requires a regular voice & SMS SIM card.
Do not use a data only SIM, as this will not work in the unit.
KEEP POWER SUPPLY AS CLOSE AS POSSIBLE.
Most technical calls received are due to installers using CAT5 or alarm cable
NEITHER are rated to carry enough power! ( 1.2amp peak )
– Use minimum 0.5mm
2
2
We recommend sealing all entry holes for prevention of insects that can
cause issues with a risk of shorting out components.
To maintain the IP55 rating please follow the sealing instructions included.
(also available online)
Set up on a bench in workshop
BEFORE going to site.
Program the unit in the comfort
of your work bench and call
technical support should you
have any questions.
Power
( 18 gauge )
Consumption:
2 ( 16 gauge )
Standby = 80mA
( 14 gauge )
Peak = 1.2A
