COASTIPC AIR-030 User Manual

Edge ai system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Rev042324
AIR-030
Edge AI System
coastipc.com | 866-412-6278 | info@coastipc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIR-030 and is the answer not in the manual?

Questions and answers

Related Manuals for COASTIPC AIR-030

Summary of Contents for COASTIPC AIR-030

  • Page 1 User Manual Rev042324 AIR-030 Edge AI System coastipc.com | 866-412-6278 | info@coastipc.com...
  • Page 2 This product contains a hard copy of the Chinese user manual for China CCC certifi- cation purposes. A PDF of the English user manual is included on the accompanying CD. Please disregard the hard copy Chinese user manual if the product is not sold and/or installed in China. AIR-030 User Manual...
  • Page 3 For more information about this or other Advantech products, visit our website at http://www.advantech.com/ https://www.advantech.com/products/fanless-embedded-computers/sub_1-2jkeuf For technical support and customer service, visit our support website at: http://support.advantech.com.tw/support/ Part No. 2006R03000 Edition 1 Printed in Taiwan June 2023 AIR-030 User Manual...
  • Page 4 Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the  receiver is connected. Consult the dealer or an experienced radio/TV technician for assistance.  AIR-030 User Manual...
  • Page 5 Before system installation, check that the items listed below are included and in good condition. If any item does not accord with the list, contact your dealer immediately. 1 x AIR-030 unit  1 x Registration and 2-year warranty card ...
  • Page 6 Power cord BSI 3P 2.5A 250V 183 cm (UK) 1700000237 Power cable, 3-Pin 183cm, PSE type Optional Items for Expansion Kit Part number Description AMO-0301 AIR-030 1 x PCIe*16 Riser card AMK-A0045 Thermal Kit for using PoE/5G on AIR-030 AIR-030 User Manual...
  • Page 7 DISCLAIMER: These instructions are provided according to IEC 704-1 stan- dards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. This product is intended to be supplied by an UL Listed power Adapter, or DC power source,rated:9~36Vdc, 16.66-4.16A,Tma=60 degrees C, if need further AIR-030 User Manual...
  • Page 8 Il y a un risque d'explosion si la batterie est remplacée de manière incorrecte. Remplacez uniquement avec le même type ou un type équivalent recommandé par le fabricant. Jetez les piles usagées conformément aux instructions du fabricant. AIR-030 User Manual viii...
  • Page 9 CC, évalué: 9~36Vdc, 16.66-4.16A, Tma = 50 degrés C, si besoin d'assistance supplémentaire, veuillez contacter Advantech pour plus d'informations. (Tma 50 degrés C = Fonctionnement Température) ZONE D'ACCES RESTREINTE: L'équipement ne doit être installé que dans une zone d'accès restreint. AIR-030 User Manual...
  • Page 10 AIR-030 User Manual...

  • Page 11: Table Of Contents

    Table 2.9: Ethernet Connector (LAN) Pin Definition....14 2.4.5 USB 3.0 Connector ..............14 Figure 2.3 USB Connector............14 Table 2.10:USB 3.0 Connector Pin Definition ......14 2.4.6 COM Connector ................15 Figure 2.4 COM Connector............15 AIR-030 User Manual...
  • Page 12 2.4.12 CANBUS Port and Pin Definition ..........19 2.4.13 Audio Connector ................. 19 Installation....................20 2.5.1 M.2 B Key Installation ..............20 2.5.2 M.2 E Key Installation ..............22 2.5.3 POE Module Installation ............. 24 2.5.4 Expansion Kit Installation............29 AIR-030 User Manual...

  • Page 13: Chapter 1 General Introduction

    Chapter General Introduction This chapter gives background information on AIR-030 series.

  • Page 14: Introduction

    NVIDIA Jetson AGX Orin 32G and 64 SoM. Next-Level and powerful AI Performance with NVIDIA Jetson AGX Orin AIR-030 is powered by the NVIDIA Jetson AGX Orin 32G and 64G SoM, which pro- viding high computing power for CPU performance up to 12 cores and delivering up to 275 TOPS AI performance.

  • Page 15: Display

    1.2.5 AIR-030-B90A1: 8-core Arm Cortex-A78AE  AIR-030-S30A1: 12-core Arm Cortex-A78AE  1.2.6 AIR-030-B90A1: 1792-core NVIDIA Ampere GPU with 56 Tensor Cores  AIR-030-S30A1: 2048-CORE NVIDIA Ampere GPU with 64 Tensor Cores  1.2.7 Audio Audio Interface: Realtek ALC5640, High Definition Audio, Line-Out ...

  • Page 16: Mechanical Specifications

    Mechanical Specifications 1.3.1 System Dimensions AIR-030 single layer (standard) AIR-030-B90A1/AIR-030-S30A1 200 x 220 x 74mm (7.87 x 8.66 x 2.91 in) Wall mounting Kit AIR-030 User Manual...

  • Page 17: Weight

    AIR-030 dual layer (optional) 200 x 220 x 123mm (7.87 x 8.66 x 4.84 in) Wall mounting kit 1.3.2 Weight AIR-030-B90A1/AIR-030-S30A1: 3.63 kg (8lb) AIR-030 User Manual...

  • Page 18: Power Requirements

    When the system is equipped with an M.2 SSD: 30 G, IEC 60068-2-27, half  sine, 11 ms duration 1.5.6 Safety Certification UL, CB, and CCC  1.5.7 EMC Certification CE, FCC Class B, CCC, and BSMI  AIR-030 User Manual...

  • Page 19: Chapter 2 Hardware Installation

    Chapter Hardware Installation This chapter details instructions for installing AIR-030 hardware and external I/O.

  • Page 20: Introduction

    2.2.1 Jumper Description AIR-030 can be configured to satisfy specific application requirements by setting jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 21: Jumper Location

    2.2.3 Jumper Location Table 2.2: JPSON1 AT/ATX Mode Default Setting ATX (2-3) Jumper Setting AT(1-2) AIR-030 User Manual...
  • Page 22 M.2 E-Key/LAN3 OFF: LAN3 Enable (Default) Table 2.5: M.2 E-Key and COM4 UART interface selection Mode/Description Pin1 Pin2 ON: COM4 Enable (Default) COM4/M.2 E-Key UART5_SW1 Setting OFF: M.2 E-Key Enable ON: USB3 M.2 B-Key Signal OFF: PCIe (Default) AIR-030 User Manual...
  • Page 23 RS-485 ON: Receiver (Hardware flow control) OFF: Transmitter Termination Enable Table 2.7: COM Port Failsafe Function Selection COM1_SAFE1(COM1) Mode/Description Pin1 Pin2 Pin3 Pin4 COM2_SAFE2(COM2) Default COM4_SAFE3(COM3) RS422_TX/RX external pull up/down COM5_SAFE4(COM4) Setting RS-485 TX external pull up/down AIR-030 User Manual...

  • Page 24: I/O Introduction

    I/O Introduction Front View Rear View Side View AIR-030 User Manual...

  • Page 25: External I/O

    External I/O 2.4.1 Power On/Off Button AIR-030 features a Power On/Off button with an LED indicators on the top side that show On status (Green LED). Figure 2.1 Power On/Off Button 2.4.2 Power Input Connector The power input connector supports DC in 9~36V.

  • Page 26: Ethernet Connector (Lan)

    +V3.3_LAN 2.4.5 USB 3.0 Connector AIR-030 supports 4 x USB 3.2 Type A interfaces. These support Plug-and-Play func- tionality and hot swapping for up to 127 x external devices. Figure 2.3 USB Connector Table 2.10: USB 3.0 Connector Pin Definition...

  • Page 27: Com Connector

    2.4.6 COM Connector AIR-030 provides four 9-pin D-sub connector, which supports RS232/422/485 serial communication interface ports. The default setting is RS-232, if you want to use RS- 422/485, you can use the switch to select the mode. Figure 2.4 COM Connector Table 2.11: COM Connector Pin Definition...

  • Page 28: Hdmi Connector

    2.4.7 HDMI Connector AIR-030 offers integrated 19-pin receptacle connector HDMI 2.0 interfaces. The HDMI link supports resolutions up to 3840 X 2160 @ 60 Hz. Figure 2.5 HDMI Connector Table 2.12: HDMI Connector Pin Definition Signal Name HDMI_TX2+ HDMI_TX2- HDMI_TX1+...

  • Page 29: Usb Type C

    2.4.9 USB Type C AIR-030 supports USB Type-C 24 pin USB connector with a rotationally symmetrical connector. Type-C receptacle A pin layout Name Description Ground return SSTXp1 SuperSpeed differential pair #1, TX, positive SSTXn1 SuperSpeed differential pair #1, TX, negative...

  • Page 30: Micro Usb For Otg

    Micro USB for OTG Micro USB port is supported by OTG for system recovery only. Signal Name DATA- DATA+ GND_1 GND_2 2.4.11 Digital I/O AIR-030 offers 16-bit DI/O and pin definition as below. Signal Name Signal Name I2C_GPIO_0_CONN I2C_GPIO_1_CONN I2C_GPIO_2_CONN I2C_GPIO_3_CONN I2C_GPIO_4_CONN I2C_GPIO_5_CONN...

  • Page 31: Canbus Port And Pin Definition

    AIR-030 offers CANBUS port and pin definition as below. Signal Name CAN0_D- CAN1_D+ CAN0_D+ CAN1_D- 2.4.13 Audio Connector AIR-030 features one phone jack connector that supports a stereo Line-Out audio port. The audio chip is controlled by ALC5640. AIR-030 User Manual...

  • Page 32: Installation

    Installation 2.5.1 M.2 B Key Installation Loosen the 6 screws on left and right side of AIR-030. Loosen the 6 screws and remove the bottom cover. AIR-030 User Manual...
  • Page 33 Install M.2 2280 B/B+M Key module. Secure the bottom cover with screws (6 screws on bottom cover and 6 screws on left and right side plate). AIR-030 User Manual...

  • Page 34: M.2 E Key Installation

    2.5.2 M.2 E Key Installation Loosen the 6 screws on left and right side of AIR-030. Loosen the 6 screws and remove the bottom cover. AIR-030 User Manual...
  • Page 35 Install M.2 2230 E Key module. AIR-030 User Manual...

  • Page 36: Poe Module Installation

    Secure the bottom cover with screws (6 screws on bottom cover and 6 screws on left and right side plate). 2.5.3 POE Module Installation Loosen the 6 screws on left and right side of AIR-030. AIR-030 User Manual...
  • Page 37 Loosen the 6 screws and remove the bottom cover. AIR-030 User Manual...
  • Page 38 Install the POE module and secure it with 4 screws. AIR-030 User Manual...
  • Page 39 Connect the power cable between POE module (POE_PWR1) and M/B (POE_PWR1). AIR-030 User Manual...
  • Page 40 Secure the bottom cover with screws (6 screws on bottom cover and 6 screws on left and right side plate). Replace the I-door plate with heatsink for POE module and fasten the four screws back onto the system. AIR-030 User Manual...

  • Page 41: Expansion Kit Installation

    Please ensure the thermal pads are put as following instruction before installation. 2.5.4 Expansion Kit Installation Remove bottom cover. Loosen the 6 screws on left and right side of AIR-030. And loosen the 6 screws on bottom cover. AIR-030 User Manual...
  • Page 42 Screw AMO-R039 riser card on expansion kit. Assembly the two mechanical parts for second layer. And fasten the screws on front and rear plate. AIR-030 User Manual...
  • Page 43 Stack expansion layer with system, and fasten three screw on each rear side. Secure the bottom cover with screws (6 screws on bottom cover and 6 screws on left and right side plate). AIR-030 User Manual...
  • Page 44 AIR-030 User Manual...
  • Page 45 AIR-030 User Manual...
  • Page 46 www.advantech.com Please verify specifications before quoting. This guide is intended for reference purposes only. All product specifications are subject to change without notice. No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher.

This manual is also suitable for:

Air-030-b90a1Air-030-s30a1
