adapt MEN0631 Quick Start Manual

PARTS LIST
1
5
Item Description
1
Wire Rack
Left Hand Slide
2
Right Hand Slide
Bin Wire - Front
3
Bin Wire - Rear
4
Side Wire
5
Trash Bin
6
Plastic Bracket
7
Rack Screw
8
Slide Screw
▪ READ ALL INSTRUCTIONS AND CHECK PARTS BEFORE STARTING INSTALLATION
IMPORTANT
▪ RETAIN ALL PACKING MATERIALS UNTIL INSTALLATION IS COMPLETE
Minimum Minimum
Height (a)
MODEL
H
32 Quart
21" 22-
28 Quart
18" 22-
(a)
Excludes any items that might be placed in
the Trash Bins.
For best access to Trash Bins avoid installing
drawers immediately above unit in standard
height cabinets.
4814108 - MEN0631 32 Qt Soft Close Double Trash Bin
4814110 - MEN0633 28 Qt Soft Close Double Trash Bin
If you have any questions, please contact Customer Care at
2
6
Qty
1
1
1
1
1
2
2
2
4
8
Minimum
Depth Opening
D A
11 / " 18"
16
11 / " 18"
16
DO NOT RETURN TO THE RETAILER
1-800-721-4191
Monday – Friday 8-5 Central Time
3
7
NOTE: Item #7 is small and
packed with Item #8
Part Number
For 32 Qt Model For 28 Qt Model
-
SS-10.1320
SS-10.1321
SS-20.1106
SS-20.1107
SS-20.1108
SS-20.1091
SS-10.1028
SS-10.1030
SS-10.1029
H
Face-Frame
4
8
REQUIRED TOOLS
Part Number
(not included)
Drill
1 /16" Drill Bit
SS-10.1109
Phillips Screwdriver
SS-10.1110
Pencil
SS-20.1111
Tape Measure
SS-20.1092
D
H
A
Frameless
D
A
