Piper Computer Kit V4 Quick Assembly Instructions page 3

1-7
1-1
Display x 1 Speaker x 1
1-3
Nuts x 22 1-4
Battery x 1
1/2"
1-5
Rasperry Pi x 1
1-6
A
2-1
1/2" Screws x 26
USB Type of Cable and
Charger May Vary.
Battery Charger and Cable
1/4"
3/8"
2-3
B C
Breadboards x 2
3/8" Screws x 4 1/4" Screws x 4
2-4
Buttons
Retainer Clips x 4 LEDs Standoffs x 6
2-5
Left Latch Right Latch
200 mm Jumper Wire x 1
2-6
2-2
2-7 3-1
2-8
Piper Computer V4 Version 4.2.0
Power Harness may vary 3.5mm to 3.5mm HDMI Cable may vary
Piper Computer Kit
Gather and organize your supplies
V4
Switches & Buzzers
Power Harness x 1 Audio Cable x 1 HDMI Cable x 1
