JAMES MARTIN VANITIES Mantova Series Assembly/Installation Instructions

Page: 1 of 9
Mantova Series Vanities: 805-V31.5-GW 805-V31.5-WLT
Optional Metal Base (sold separately): 805-B18.1-MBK
Assembly/Installation Instructions
Important Notes:
This vanity cabinet may be used freestanding, or may be mounted to a wall (floating).
If you are using this cabinet as a freestanding unit with the stainless steel base,
please follow the instructions on pages 06 - 09 *.
If you are using this cabinet as a wall mounted (floating) unit, please refer to pages 01 - 05
Materials
for
Installation:
B pre-attached metal mounting
(French Cleat) brackets
- - - - - - -
back of vanity cabinet
Step 1 Notes:
The metal mounting bracket has been pre-installed to the
backside of the cabinet 14 1/2" from the bottom of the
cabinet, remove one piece from the back of the cabinet .
* For your safety and to achieve the best possible installation of this vanity cabinet,
James Martin Vanities always recommends you consult with a professional contractor.
Two people are required for the assembly and installation of this vanity cabinet.
For Warranty information, please visit jamesmartinvanities.com
Customer Service: 512-795-4171
Level
- - - - -·
�
�
T"""
"<j"
T"""
I
JAMES 1\1\ARTIN
805-B18.1-CB 805-B18.1-BNK
Tape
Measuring
Wall
Step 2 Notes:
Draw a horizontal line on the wall at your desired height.
For this cabinet, most people use a height of 28 3/4"
VA N I T I ES
®
*
Pencil
Version:202311
