- Page 1 EN 54-2 EN 54-4 EN 54-16 EN 54-21 EN 12094-1 IPG12, IPG24 Microphone bases Installation and programming manual...
-
Page 2: Table Of Contents
Table of contents 1. Microphone b ases description 1.1 Description of parts 1.2 Technical specifications 1.3 Connections 1.4 Buttons 2. Operation 3. Programming from the base 3.1 Base address and access code 3.2 Microphone type 4. General information 4.1 About this manual 4.2 Manufacturer's details 4.3 Warranty 4.4 Limited warranty 4.5 Documents for the users 4.6 Disposal of the product Installation and programming manual- 110... -
Page 3: Microphone Bases Description
1. Microphone bases description Depending on the model, Inim Electronics S.r.l. microphone bases can be used for voice announcements in PA systems (Public Address systems). They are equipped with a button for opening audio with disengagement on release and a button for opening audio with hold status until the next press. They are equipped with configurable buttons for selecting zones or sound sources. They also have a <speech filter= function which can be enabled during configuration. IPG12 Microphone base for public address announcements equipped with 12 configurable buttons. IPG24 Microphone base for public address announcements equipped with 24 configurable buttons. IPG12, IPG24 | © 2024 Inim Electronics S.r.l. -
Page 4: Description Of Parts
1.1 Description of parts Installation and programming manual- 110... - Page 5 1.1 Description of parts [A] Connector for microphone Buttons and LEDs for selecting/deselecting zones or audio sources IPG12, IPG24 | © 2024 Inim Electronics S.r.l.
-
Page 6: Technical Specifications
[C] Microphone activation LED <Hold= button, to open audio with disengagement on release <Lock= button, to open audio with maintainment until pressed again Mains power active LED [G] Flush mounting screw hole [H] Power-supply connector [I] Line connector 1.2 Technical specifications IPG12 IPG24 from 20 to 30 V power supply from line or from local power supply Operating voltage 25 mA Maximum current draw Connection A/B PAGERS from IFAMEVAC Line Double shielded not crossed cat. 5E SF/UTP Cable 500 m Maximum distance Max. 64 Microphone bases per line XLR 3P receptacle Connector for microphone IP 40... -
Page 7: Buttons
and for interaction with the parts of the emergency system set up in accordance with the con- figuration. Audio start buttons Description of parts, [D] and Description of parts, [E] Microphone activation buttons and playback of the voice message spoken into it or of the message selected using one of the configurable buttons. icon function Hold Audio start button disengages on release of button Lock Audio start button actuation maintained until pressed again If the microphone is used, and no external source has been selected, once one of the two open audio buttons is pressed, the microphone activation LED will light up. Configurable buttons Description of parts, [B] IPG12, IPG24 | © 2024 Inim Electronics S.r.l. - Page 8 Buttons that, through appropriate programming, allow you to select a group of audio zones associated with the button. Following the selection, the relative LED lights up and, by pressing the open audio buttons, the messages will be played on these zones. As an alternative to the zones, these buttons can be associated with pre-recorded voice messages or sound sources. Following the selection, the relative LED lights up and, by pressing the open audio buttons, the messages will be played on the entire system. Installation and programming manual- 110...
-
Page 9: Operation
Playback from sound source 1. Select the audio zones on which the voice message is to be played via the associated buttons (Description of parts, [B]). 2. Select the sound source (pre-recorded message or external audio source, depending on the pro- gramming) via the associated button (Description of parts, [B]). 3. Press the open audio button. Press the <Hold= button if you wish to keep the button pressed until playback ends. Press the <Lock= button if you wish to stop playback by pressing the button again. 4. Playback of the selected message or source starts. 5. Stop playback by releasing the button or by pressing the button. The selections made will be cancelled. IPG12, IPG24 | © 2024 Inim Electronics S.r.l. -
Page 10: Programming From The Base
3. Programming from the base Programming from the base involves setting up the base address, which is used by the control panel to identify the base on the line from the control panel, and the type of the microphone in use. This programming is possible by means of the LEDs and buttons on the base itself. 3.1 Base address and access code Entry into programming 1. Disconnect the power then reconnect the power to the base. 2. During the first 5 seconds after reconnecting the power supply, press and hold the configurable but- ton <1= for several seconds (Description of parts, [B]). 3. Entry into programming is signalled by the rapid flashing of the green power LED. Address programming 4. The base will show the current address. The LED relative to button <1= shows the value of the tens of the address by means of the number of consecutive fast flashes. The LED relative to button <2= shows the value of the unit of the address by means of the number of consecutive fast flashes. -
Page 11: Microphone Type
[B]). 3. Entry into programming is signalled by the slow flashing of the green power LED. Microphone type programming 4. The base will show the current type of microphone type by means of the LED relative to button <1= status: rapid blinking, microphone type will be chosen automatically LED OFF, "gooseneck" microphone LED ON solid, "push-to-talk" microphone 5. Press button <1= to scroll the setting options. 6. Press the "Lock" button to save the microphone type. 7. The base is in normal operating mode. IPG12, IPG24 | © 2024 Inim Electronics S.r.l. -
Page 12: General Information
4. General information 4.1 About this manual Manual code: DCMIINE0IPG Revision: 110 Copyright:The information contained in this document is the sole property of Inim Electronics S.r.l.. Copy- ing, reprinting or modification of this document, in part or as a whole, is not permitted without prior autho- rization in writing from Inim Electronics S.r.l.. All rights reserved. 4.2 Manufacturer's details Manufacturer: Inim Electronics S.r.l. Production plant: Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP), Italy Tel.: +39 0735 705007 Fax: +39 0735 734912 E-mail info@inim.it Web: www.inim.it The persons authorized by the manufacturer to repair or replace the parts of this system have authorization to work only on devices marketed under the brand Inim Electronics. 4.3 Warranty Inim Electronics S.r.l.. (Seller, Our, Us) warrants the original purchaser that this product shall be free from defects in materials and workmanship under normal use for a period of 24 months. As Inim Electronics does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;Inim Electronics does not warrant against loss of quality, degradation of performance of this product or actual damage that results from the use of products, parts or other repla- ceable items (such as consumables) that are neither made nor recommended by Inim Electronics. Seller obligation and liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any product not meeting the specifications. In no event shall Inim Electronics be liable to the purchaser or any other person for any loss or damage whether direct of indirect or consequential or incidental, including without limitation, any damages for lost profits, stolen goods, or claims by any other party caused by defec- tive products or otherwise arising from the incorrect or otherwise improper installation or use of this product. This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover ... -
Page 13: Limited Warranty
4.6 Disposal of the product Informative notice regarding the disposal of electrical and electronic equipment (applicable in countries with differentiated waste collection systems) The crossed-out bin symbol on the equipment or on its packaging indicates that the product must be disposed of correctly at the end of its working life and should never be disposed of together with gene- ral household waste. The user, therefore, must take the equipment that has reached the end of its working life to the appropriate civic amenities site designated to the differentiated collection of electrical and elec- tronic waste. As an alternative to the autonomous-management of electrical and electronic waste, you can hand over the equipment you wish to dispose of to a dealer when purchasing new equipment of the same type. You are also entitled to convey for disposal small electronic-waste products with dimensions of less than 25cm to the premises of electronic retail outlets with sales areas of at least 400m2, free of charge and without any obligation to buy. Appropriate differentiated waste collection for the subsequent recycling of the discarded equipment, its treatment and its environmentally compatible disposal helps to avoid possible negative effects on the environment and on health and favours the re-use and/or recycling of the materials it is made of. IPG12, IPG24 | © 2024 Inim Electronics S.r.l. - Page 14 Installation and programming manual- 110...
- Page 15 4.6 Disposal of the product IPG12, IPG24 | © 2024 Inim Electronics S.r.l.
- Page 16 Inim Electronics S.r.l. Via dei Lavoratori 10, Loc. Centobuchi 63076 Monteprandone (AP) I TALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.it _ www.inim.it DCMIINE0IPG-110-20240205...
