WATER-KING WK4
OPERATING & MAINTENANCE
PHYSICAL WATER CONDITIONERS
Lifescience Products Ltd, Unit 19 Cheltenham Trade Park, Gloucestershire, GL51 8LZ
INSTALLATION,
INSTRUCTIONS
CONTENTS
Introduction &
2
Controller Diagram
Installation
3
Operating & Commissioning
4
Maintenance
6
Specification
7
HIGH PERFORMANCE
T: 01608 811070
E: info@lifescience.co.uk
Advertisement
Summary of Contents for Water King WK4
- Page 1 WATER-KING WK4 INSTALLATION, OPERATING & MAINTENANCE INSTRUCTIONS CONTENTS Introduction & Controller Diagram Installation Operating & Commissioning Maintenance Specification HIGH PERFORMANCE PHYSICAL WATER CONDITIONERS Lifescience Products Ltd, Unit 19 Cheltenham Trade Park, Gloucestershire, GL51 8LZ T: 01608 811070 E: info@lifescience.co.uk...
- Page 2 INTRODUCTION Water-King WK4 is a high performance physical water conditioner designed to treat large commercial applications with pipe sizes up to 108mm. It is frequently used on the boosted water supply to high rise office and residential developments, student accommodation blocks, hotels and hospitals where it can provide continuous treatment against the harmful effects of hard water.
- Page 3 INSTALLATION Location For guidance on where When selecting a location for the device best to locate Water-King the following points must be considered: units, please refer to the Water-King Specifiers Guide* • The aerials require approximately or contact our technical 400mm of pipework helpline on 01608 811707.
- Page 4 (please refer to Aerial Winding section of the Installation page for guidance). At power up the LCD display will show the start-up screen “INITIALISING MODEL TYPE: WK4” for five seconds, during which time the unit completes an initial test. The output monitoring indicators will flash green unless a fault is detected.
- Page 5 “Faulty Ae:--x- TESTING AERIAL X” (where “X” denotes the aerial at fault on the top line and the aerial under test on line 2). The BMS contact will also open. To remedy the fault, ensure that the aerial has been correctly inserted into the output socket and has not been grounded to the pipe.
- Page 6 COMMISSIONING Once the Water-King WK4 has been installed and powered up, the user must follow the operating instructions to set the time and date and clear any faults. When complete the LCD display should read “ALL OUTPUTS O.K.
- Page 7 SPECIFICATION Water-King WK4 Model Maximum pipe diameter 108mm Sizing Maximum heat output 750kW gas/oil fired water heater 100kW electric water heater Maximum flow rate Water-King can treat any flow rate Aerial length 7.0m Output Aerial number Minimum aerial turns Frequency range 1–10kHz...
- Page 8 Scan here to visit www.waterking.co.uk Water-King is manufactured and distributed by Lifescience Products Ltd, Unit 19 Cheltenham Trade Park, Gloucestershire, GL51 8LZ T: 01608 811070 E: info@lifescience.co.uk Lifescience Products Ltd are experts in chemical free water treatment technologies with an enviable reputation of providing the very best in environmentally friendly hard water treatment solutions to consulting engineers, contractors and plumbing merchants.
