Summary of Contents for Kohler Mira Rada Meynell CD & Bonus PEBS0026.1P
- Page 1 CD & Bonus CD & Bonus CD & Bonus CD & Bonus CD & Bonus BATH & THERMOSTATIC SHOWER MIXERS PRODUCT MANUAL INSTALLER Please leave manual with user for future reference to unit operation and maintenance.
-
Page 2: Table Of Contents
INDEX Section Page 1 ..Introduction ..............3 2 ..Pack Contents Checklist ..........4 3 ..Dimensions ..............5 4 ..Specifications ..............6 5 ..Installation Requirements ..........9 6 ..Installation ..............12 7 ..Commissioning ............... 15 8 .. -
Page 3: Introduction
INTRODUCTION Description The Bath Mixer and Thermostatic Shower provides accurate temperature control and flow rates to the shower. The shower control is via a central sequential control. The bath fill is conventional with independent hot and cold tap heads via centre outlet. Caution! If the hot tap head is turned on then the bath fill outlet will deliver the temperature set on the hot water system. -
Page 4: Pack Contents Checklist
PACK CONTENTS ✔ Tick the appropriate boxes to familiarize yourself with the part names and to confirm that the parts are included. CD Bath & Thermostatic Shower Mixer 1 x Outlet Regulator 1 x Bath and Thermostatic Shower Mixer 1 x Sealing Gasket 2 x 3/4 BSP Backnut... - Page 5 ✔ Tick the appropriate boxes to familiarize yourself with the part names and to confirm that the parts are included. Bonus Bath & Thermostatic Shower Mixer 1 x Outlet Regulator 1 x Bath and Thermostatic Shower Mixer 1 x Sealing Gasket 2 x Inlet Strainer...
-
Page 6: Dimensions
DIMENSIONS CD and Bonus Bath & Thermostatic Shower Mixer Cold Dimensions in millimetres... -
Page 7: Specifications
SPECIFICATION Notes The installation, commissioning and maintenance must be carried out in accordance with instructions supplied by the manufacturer, and be installed by qualified or competent persons. The plumbing installation must comply with the requirements of UK Water Regulations/Byelaws (Scotland), Building Regulations or any particular regulations and practices, specified by the local water supplier. - Page 8 Normal Operating Conditions Consider as: Inlet maintained pressures are nominally balanced Daily usage 1-6 hours Installation and usage environment not subject to extremes of temperature, unauthorised tampering or wilful abuse. Operating Parameters: Pressures And Flow Rates For optimum performance, maintained supply pressures should be nominally equal.
- Page 9 Temperature Control Minimum temperature differential between hot supply and outlet temperature: 10°C Optimum temperature control range of mixer: 35 - 45°C Maximum hot water temperature: 85°C (for safety, a recommended hot water storage temperature maintained below 85°C and for ablutionary installations at between 60 to 65°C).
-
Page 10: Installation Requirements
INSTALLATION REQUIREMENTS INSTALLATION Key to Symbols Isolating valve Mixing Valve Overflow Indicator Pressure Reducing Valve Twin Impeller Pump Tempering Valve Mini Expansion Vessel Gravity Fed System - The mixer MUST be fed from a cold water cistern and hot water cylinder providing nominally equal pressure. - Page 11 Gas Heated System - The mixer MUST be installed with a gas water heater or combination boiler of a fully modulating design. A fully modulating boiler is one where the draw off rate is indirectly controlling the gas flow to the boiler, producing a relatively constant hot water temperature.
- Page 12 Mains Pressurised Instantaneous Hot Water System - The mixer installed with systems of this type is supplied hot water via a tempering valve, this provides relatively constant hot water and the shower will compensate for temperature changes should they occur. Pumped System - The mixer can be installed with an inlet pump (twin impeller).
-
Page 13: Installation
INSTALLATION INSTALLATION General Installation must be carried out in accordance with these instructions supplied, and must be conducted by a qualified and competent person. Before starting installation, ensure that all site requirements correspond to information given in the SPECIFICATION section. Do not install product in a position where it could become frozen. - Page 14 Regulators Two flow regulators are supplied with the product. There is a yellow regulator which fits into the cold inlet tail for high pressure systems. There is a white regulator which fits into the shower outlet to limit the maximum flow rate to the shower fitting. The selection table indicates when and where these can be fitted.
- Page 15 Fitting To Bath The hot water must always be connected to the hot inlet on the mixer. This is clearly marked on the base of the mixer. Reversing the connections may cause damage to the product could dangerous to persons using the shower.
-
Page 16: Commissioning
COMMISSIONING Maximum Temperature Setting The Thermostatic Shower has been preset at approximately 42°C at the factory. Site conditions and personal preference may dictate that the maximum temperature be reset. Before commencing ensure that the hot water temperature is at least 10°C above the required maximum showering temperature. -
Page 17: Operation
OPERATION Bath Fill The two outermost controls operate the central bath fill outlet. The red and blue indicator trim relate to the hot and cold taps, or when viewed from front hot - left cold - right. WARNING! If the hot tap head is turned on then the bath fill outlet will deliver the temperature set on the hot water system. -
Page 18: Fault Finding Analysis
FAULT FINDING Symptom Cause/Rectification 1. Only hot or cold Inlet supplies reversed (hot supply to cold water from mixer supply). outlet. No hot water reaching mixer. Check strainers and inlet/outlet fittings for blockage. Installation conditions continuously outside operating parameters: refer SPECIFICATION, and 2.e. - Page 19 Symptom Cause/Rectification Water leaking from Seal wear or damage. mixer or shower. Obtain Seal Kit, renew all seals. Renew shut off head assembly. Flow rate too low (Too low) Refer to symptom 2.a-e. above. or too high. (Too low) Insufficient supply pressures. (Too high) Supply pressure too high.
-
Page 20: Maintenance
MAINTENANCE General This Product is precision engineered and should give continued safe and controlled performance, provided: It is installed, commissioned, operated and maintained in accordance with manufacturers recommendations, and Annual/biannual attention is given, when necessary, to maintain the product in good functional order. The exploded view and parts list illustrates the assembly of the product. - Page 21 NOTES...
-
Page 22: Spare Parts
SPARE PARTS CD Bath & Thermostatic Shower Mixer 122 66 Head Assembly 122 70 Element 122 67 Sleeve Assembly 423 06 Tap Headwork (pair) 423 02 Backnuts and Gasket 423 04 Checkvalve and Strainer (pair) 423 03 Water Separator 423 15 Shower Knob 423 09 Lever Tap Handle (Pair) - Page 23 SPARE PARTS Bonus Bath & Thermostatic Shower Mixer 122 66 Head Assembly 122 70 Element 122 67 Sleeve Assembly 423 05 Tap Headwork (pair) 423 02 Backnuts and Gasket 423 04 Checkvalve and Strainer (pair) 423 03 Water Separator 423 14 Shower Knob 423 07 Tap Handle (Pair)
- Page 24 - without charge, provided that the product has been properly used and maintained. Routine cleaning and maintenance should be carried out in accordance with instructions supplied. The product should not be modified or dismantled except by a person authorised by Kohler Mira Ltd. Your statutory rights are not affected by this guarantee.
