PCB Piezotronics IMI SENSORS HT622B01 Installation And Operating Manual page 19

PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
A
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010

ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
2
SIGNAL/POWER
2.06 [52.2]
.050 [1.27]
7
8 [22] HEX
DRAWN
DIMENSIONS IN MILLIMETERS
KRM
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.8
XX ± 0.25

ANGLES 2 DEGREES
MODEL (EX)(M)(HT)(VO) 622B SERIES
FILLETS AND RADII
0.07 - 0.13
2
REV
B
GROUND
ELECTRICAL CONNECTOR
5/8-24 UNEF - 2A
2-PIN (MIL-C-5015)

3X .870 [22.10]
1/4-28 UNF - 2B
[1/4-28 UNF - 2B
CHECKED ENGINEER
10/23/18 10/23/18
KRM GGS
OUTLINE DRAWING
ACCELEROMETER
1
REVISIONS
DESCRIPTION
REVISED TITLE

.20

5.1]
10/23/18
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
35886
IDENT. NO.
52681
SCALE: 1.5X SHEET
1
DIN
48794
B
A
1 OF 1
