- Page 1 PoE Repeater Quick Start Guide UD36738B...
- Page 2 Preface Applicable Models This manual is applicable to PoE repeaters. Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation,...
- Page 3 (0503DP series) feature one gigabit PoE IN port and two gigabit PoE OUT ports. The devices are plug-and-play, requiring no external power supply. When connected to Hikvision’s PoE switches, PoE repeaters can extend the network transmission distance while providing power.
- Page 4 2 Installation and Wiring Before You Start Ensure that the desktop is stable and firm enough. Desktop Placement Place the device on the desk. Wiring As shown in Figure 2-1, use a network cable to connect the PoE IN port of the PoE repeater to a RJ45 port of the PoE switch, one PoE OUT port of the PoE repeater to the RJ45 port of an IPC, and the other PoE OUT port of the PoE repeater to the PoE IN port of another PoE repeater respectively.
