Summary of Contents for CableTronix CT-STB-DVR
- Page 1 Manual CT-STB-DVR User Manual WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov MADE IN CHINA...
-
Page 2: Table Of Contents
CT-STB-DVR Manual Content Package content/FCC Notice ..................... 3 Safety Warning ........................4-5 Overview of the equipment ......................6-9 1. Front panel ......................6 2. Rear panel ......................6 3. Remote control unit .................... 7 INFO key ......................8 AUDIO key ......................8 PREV/NEXT &... -
Page 3: Package Content/Fcc Notice
• User manual PACKAGE DESCRIPTION Immerse yourself in an elevated entertainment experience with the CableTronix cutting-edge digital TV set-top box. This advanced device effortlessly converts over-the-air and unscrambled cable TV channels to seamlessly integrate with your television. Enjoy the convenience of a favorite channel function and inclusive accessibility with closed captioning (CC) for the hearing impaired. Never miss a moment of your favorite shows, thanks to the built-in DVR that offers convenient recording and playback capabilities. -
Page 4: Safety Warning
CT-STB-DVR Manual IMPORTANT SAFETY INSTRUCTIONS The lighting flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons... - Page 5 CT-STB-DVR Manual PRECAUTIONS Please read these precautions before operating this unit. 1. Place the equipment on a hard, level surface. Leave a 4 inch minimum of clearance on all vented sides of the set top box to permit the airflow required for proper ventilation. Restricting airflow can damage the unit or cause a fire.
-
Page 6: Overview Of The Equipment
CT-STB-DVR Manual OVERVIEW OF THE EQUIPMENT FRONT PANELS FRONT PANEL LED Display Window Remote Control Signal Sensor Change Channel DOWN Button Change Channel UP Button Power ON/OFF Button USB Jack REAR PANELS REAR PANEL RF IN Connect to Off Air Antenna or Cable TV Source... -
Page 7: Remote Control Unit
CT-STB-DVR Manual OVERVIEW OF THE EQUIPMENT REMOTE CONTROL UNIT THE REMOTE KEY LIST STANDBY Press to turn on or standby HDMI Adjust resolution Press to mute the sound of TV audio, press again MUTE will restore the sound Press to enter the required numbers in the input box... -
Page 8: Info Key
CT-STB-DVR Manual OVERVIEW OF THE EQUIPMENT INFO KEY Press “INFO” key to display the Information banner while viewing TV programs. Information banner: AUDIO KEY Some programs may have multilingual audio language and this audio broadcast may be on a different audio mode such as Stereo, Left or Right. All the available audio languages will be displayed on the audio track window when you press the L/R key. -
Page 9: Epg Key
CT-STB-DVR Manual OVERVIEW OF THE EQUIPMENT EPG KEY Press EPG key to display the on screen electronic program guide. This displays a 7 days Electronic Program Guide for all programs being broadcast from all available broadcasters. OK/LIST KEY Press OK key to display all TV channels or all Radio channels. -
Page 10: Cable Connections
CT-STB-DVR Manual CABLE CONNECTIONS Make sure the STB is connected properly as below: CABLE TV SOURCE... -
Page 11: Menu Operation
CT-STB-DVR Manual MENU OPERATION Press MENU key to display the main menu. It consists of 7 items as following: • Program • Picture • Channel Search • Time Setting • Option • System • Note: In any page of the menu, you can use... -
Page 12: Picture
CT-STB-DVR Manual MENU OPERATION PICTURE Aspect Ratio: AUTO, 16:9 Pillar Box, 16:9 Pan & Scan, 4:3 Letter Box, 4:3 Pan & Scan,4:3 Full, 16:9 Wide Screen Resolution: 480i, 480p, 720p, 1080i & 1080p (60Hz) TV Format: NTSC I PAL Figure 5 CHANNEL SEARCH 1. - Page 13 CT-STB-DVR Manual MENU OPERATION 1. Number keys allow user to search by channel and or frequency 2. Auto channel search function will search all frequencies 3. Press EXIT to quit Figure 10 3. Country In the Main menu, use ▲ & ▼ keys to select Auto Search item, and press ⊲...
-
Page 14: Time Setting
CT-STB-DVR Manual MENU OPERATION TIME SETTING Time Zone: select Time and Timezone. Sleep: press►key to select the Sleep Time (1-12 hours). Power ON/OFF: press►key into the setting menu, select Power ON Time or Power OFF Time Figure 13 Figure 14 OPTION OSD Language: English, Spanish, French Figure 16 Figure 15 CC Display CC OFF, CC1, CC2, CC3, CC4, CCS, CC6 CC Position... -
Page 15: Changing Channels From Virtual To Logical
CT-STB-DVR Manual MENU OPERATION CHANGING CHANNELS FROM VIRTUAL TO LOGICAL Figure 17 1. Press the Menu button on the remote 2. Use ▼ and highlight the “Show Channel Type” 3. Press ⊲ to change from Virtual to Logical ( C106 or 50-4) 4. -
Page 16: System Setup
CT-STB-DVR Manual MENU OPERATION SYSTEM SETUP In main, select System Setup item and press OK key to enter into System Setup menu. Press the ▲ & ▼ arrow keys to select item and ⊲ key to enter into sub menu or change current item setting. -
Page 17: Usb
CT-STB-DVR Manual MENU OPERATION 5. Software Update: Insert a USB flash drive while the unit is on, choose upgrade file, press the right directional key to upgrade, make the sure the unit stays on while the upgrade is processing. Figure 25 Figure 26 Multimedia: MENU=>Multimedia You can now select to view Photos, play MP3 music files and view Movie files via the multimedia player. Known supported files are outlined below. NTFS, FAT32 and FAT16 file systems are supported Player Supported Files Photo JPEG, BMP, PNG... -
Page 18: Pvr (Tv Recording)
CT-STB-DVR Manual MENU OPERATION Photo Configure: Here you can choose slide time, mode and aspect ratio (See figure 29) Figure 29 PVR (TV RECORDING) Choose record device, partition. Figure 30 Figure 31 How to record a program: 1. RealTime Recording • To record and save the current TV program, user will need to insert a USB flash drive, and set up the recording and saving route. Refer to Figure 31 Please be advised that all your recording contents are for your personal enjoyment purpose only, they can not be used for commercial distribution. -
Page 19: Time Shift (Pause Live Tv)
CT-STB-DVR Manual PVR (TV RECORDING) Pause Live TV: The Timeshift function allows you to pause the TV program being viewed. Once paused the TV program is being stored on your connected USB Flash Drive. When watching a program, press the PLAY key on the remote control to activate the function. -
Page 20: Programmed Time Recording
CT-STB-DVR Manual PVR (TV RECORDING) 2. Programmed Time Recording Option 1: Press the “TIMER” key on the remote to access the “Programmed Time Record Menu”. (Figure 35) Option 2: Press the “EPG” key enter the TV program interface (Figure 34), and then press the “Enter”... -
Page 21: Appendix
CT-STB-DVR Manual APPENDIX TROUBLESHOOTING If you have difficulty with your digital TV set-top receiver, there are several possibilities you should investigate before calling for a service technician. Problem Problem Causes What To Do The display on the front Check that the power cord is plugged Power cord is not connected panel does not light up... -
Page 22: Specifications
CT-STB-DVR Manual SPECIFICATION Tuner Input and Output ATSC Terrestrial Tuner in/out RF Input Frequency 54-803MHz USB 2.0 Bandwidth 6MHz L/R/CVBS Output Input Level -83 to -5dBm HDMI Output Switchable channel 3 or 4 CH 3/CH 4 RF output RF output... - Page 23 CT-STB-DVR Manual CABLETRONIX - 1 Years Limited Warranty CABLETRONIX. (the “Company”) warrants to the Original Purchaser that the item purchased is free from defects in workmanship or material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser.
- Page 24 CT-STB-DVR Manual the possibility of such damages, or for any claim brought against your by another party. Jurisdic- tions vary with regard to the enforceability of provisions excluding or limiting liability for incidental or consequential damages. You should check the laws of your local jurisdiction to find out whether the above exclusion applies to you.
