WAC EP2NI Installation Instructions Manual

Installation Precautions:
1. Please read the instruction manual completely before installation.
2. The lighting system must be installed by qualified professional electricians and comply with national and
local laws and regulations. To reduce the risk of fire, electric shock, and personal injury, the main power
switch must be turned off before installing or modifying the system.
4. Please keep this manual for future maintenance reference.
5. Failure to install lighting fixtures according to the instructions will result in no quality assurance.
6. The external flexible cable or cord of this lamp cannot be replaced; If the flexible cable is damaged, the
lamp should be scrapped.
7. The light source inside this lamp should be replaced by the manufacturer, its service agent, or someone
with similar qualifications.
Installation accessories (random delivery):
Installation steps and wiring:
1. Install the lamp onto the working surface with screws;
2. Connect each core wire of the lamp to the output wire of the power
driver with an output voltage of 12V, and ensure that the wiring is
properly connected Waterproof treatment, please refer to the
model label and input prompt label on the lamp for details;
3. Lamp input: DC12V, 0.56A; The brownish red core wire is the
"+" positive electrode, and the blue core wire is the "-" negative
electrode;
4. The power on light is on.
Lamp adjustment:
1. Tilt: Loosen the screw, adjust the lamp body to
the appropriate position, and then tighten it;
2. Rotation: Loosen the nut, rotate the lamp body to
the appropriate position, and then tighten it.
Licensed by "WAC" trademark holder - WAC LIGHTING, USA
Chinese Marketing Headquarters
Address
China factory
Address
Discharge hood
Quantity: 1
: WAC Lighting (Shanghai) Co, Ltd.
: 14,Lane 299, Bi Sheng Road, Shanghai 201204,China
: Manufactured WAC Lighting (Dongguan) Co, Ltd.
: 390, Qingfeng Road, Qingxi Town, Dngguan, Guangdong. Postal code: 523653
Installation Instructions
Model: EP2NI Flood light
Screw
tilt
Screw(self provided)
Lighting fixtuers
power cord (12V)
Nut
Rotate
