Cair Heat+ Programming Manual

Programming
Guide
V 1.0
Specifications
Operating Frequency 869.2125 MHz radiating less than 10mW (Other custom frequencies possible)
Dimensions H90 x W90 x D58 mm
Power Supply Sealed lithium battery
Transmitter Battery Life Up to 5 years
Device Life 10 years
Wireless Range Up to 600m line of sight
Compliance CE / RoHS 2 / RED
Warranty 24 months
Batteries / Lifespan of Alarm
The heat alarm contains a non-user replaceable lithium
battery, which should last up to 10 years, dependent upon
use and the environment in which it is located. Extended
periods in alarm mode will significantly reduce the life of
the battery. In the event of a low battery, the unit will beep
every 60 seconds. When the heat alarm battery becomes
low, the complete heat alarm unit must be replaced.
Irrespective of the battery life, the heat alarm has a fixed
10 year lifespan indicated by the date printed on the side
of the alarm. The alarm must be replaced by this date.
The radio transmitter within the pattress contains a 3V
lithium coin cell battery which is also not replaceable by
the user. Typically, the battery will last up to 5 years
dependent upon the application. When the battery
depletes, the complete transmitter unit must be replaced.
It is also recommended that the entire heat alarm is
replaced.
Packing for shipment
The equipment containing cells or batteries must be
packed in strong rigid packaging and must be secured
against movement within the outer packaging to prevent
accidental activation. The sender's name and return
address must be clearly visible on the outer packaging.
Safety
Do not dismantle or alter the unit. Do not open the case.
Indoor use in dry location only.
Disposal
All electronic waste should be disposed of in accordance
with the latest legislation
.
It must be disposed of within the electrical and electronic
waste stream and not be disposed of in the normal waste
stream. Recycling electrical waste products (including the
lithium batteries contained within) help to conserve
natural resources and prevent adverse effects on the
environment. Contact your supplier should you require
more information.
Declaration of Conformity
Hereby, Cair (UK) Ltd declares that the radio equipment
type Heat Alarm is in compliance with Directive
2014/53/EU.
Hanson Lane, Halifax, West Yorkshire, HX1 4SD
T: 01422 399 155 E: sales@we-cair.com W: www.we-cair.com
Heat+
Interlinked Heat Alarm
The Heat+ Alarm is a discreet, compact unit which is specifically designed for
applications where smoke alarms would be unsuitable, such as kitchens, garages
and dusty areas.
Cair (UK) Ltd. It can be easily programmed to interlink with other Smoke+ or Heat+ sensors,
ensuring all connected devices alert when needed.
.
Smart Technology, Made to Care
Programming
Guide
V 1.0
