- Page 1 BENCHVAC BV3000 INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
BENCHVAC BV3000 Carefully read these instructions before use and keep them safely after reading for later reference. INSTRUCTION MANUAL SAFETY PRECAUTIONS WARRANTY WARNINGS 8-10 INSTRUCTIONS 11-12 CONTROLS MAIN PARTS FILTER CHANGE CLEANING THE FILTER SPECIFICATIONS TROUBLESHOOTING 18-19 EU DECLARATION OF CONFORMITY BV3000 MAX-VAC.COM... - Page 3 Thank you for choosing a BV3000 made by MAXVAC. Read ALL instructions carefully before using this product. The BV3000 from MAXVAC has been manufactured with the greatest care, and we hope that you will be happy with the BV3000 you have just purchased. However, if it does not fully comply with your expectations, please contact your supplier.
-
Page 4: Safety Precautions
The user and other people are not allowed to modify, alterate, change, etc. Its products. The transgressor will be responsible for all the risks and damages It is expressly agreed that the guarantee given by MAXVAC is for repairs of the caused by improper and dangerous tampering. -
Page 5: Warnings
WARNINGS WARNINGS Hazard Prevention Risk of Falling Tripping Serious injury, including death Caused by falling objects or loads life threatening • Work on the electrical network and active components may only be carried out • Do not stand under suspended loads. by an electrician. - Page 6 WARNINGS INFORMATION Dust deposits in the piping system Fire Hazard in the Spark Arrestor Filter Traces of dust and accumulation of particles can cause a fire on the air guide plate. Short-term deterioration of the respiratory organs during breathing • Check the connected tubing regularly for dust deposits. •...
-
Page 7: Controls
Operating Time Counter • Check that you are supplying the correct voltage! (Pay attention to the information on the label!) • Only use original MAXVAC spare parts! Qualified Personnel/Trained Personnel Trained personnel Trained personnel are those who are informed about the correct use of the product and are aware of the risks posed by improper use. -
Page 8: Main Parts
Clean the housing, including the back side of the air guide plate, with an industrial vacuum cleaner. The dust should not be dispersed while doing this. 10. Unpack the new original MAXVAC filter cartridges. 11. Check the tightness of the gasket (below) on the filter cartridge and adjust as necessary. -
Page 9: Cleaning The Filter
CLEANING FILTER SPECIFICATIONS Auto Clean Description BV3000 When the filters reach the saturation point, a filter cleaning warning appears on the Power Supply 415 VAC panel and the cleaning is automatically activated. It performs cleaning for the set time of 1 minute. The cycle continues until the alarm is deactivated. Frequency 50 Hz •... -
Page 10: Troubleshooting
Causes Solution Unusual sounds The unit does not suck. Suction holes are clogged. Open the holes to allow The fan is rubbing against Notify MAXVAC service. (Fume extraction cannot be suction. something performed.) Clean/replace filters The work plate is damaged. - Page 11 BV3000 Models: MV-BV3000 Machine: Mobile downdraft table for welding, grinding MAXVAC, hereby declares the above stated models comply with the following or relevant part thereof: Developed, designed and manufactured in accordance with EU directives set out in this declaration. It also fulfills the protection objectives of the following EC / EU directives: 2014/30/EU EU –...
