Assembly Instructions
BKT-CT10
Enclosure
Thank you for purchasing AVFI's BKT-CT10 enclosure.
This product is designed to have many mounting configurations.
Confirm all hardware is included before you begin assembly.
Read these instructions start to finish before beginning installation.
Note: If you cannot understand these instructions or are concerned about safety
of the installation contact a qualified contractor or contact AVFI at 1-877-834-3876.
Supplied Parts
BKT-CT10
Remove face panel by removing nuts behind
1
it. 8-32 nuts x4
www.video-furn.com
Supplied Hardware (Installed on bracket)
8-32 Nut
1/4-20" Bolt
(4)
(1)
288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 | 1.877.834.3876
V
F
I
1
Advertisement
Summary of Contents for AVFI BKT-CT10
- Page 1 Read these instructions start to finish before beginning installation. Note: If you cannot understand these instructions or are concerned about safety of the installation contact a qualified contractor or contact AVFI at 1-877-834-3876. Supplied Hardware (Installed on bracket) Supplied Parts 8-32 Nut 1/4-20”...
- Page 2 Assembly Instructions BKT-CT10 Enclosure Choose from many mounting methods. ( Hardware not included) Foam not shown for visibility. Wall mount to stud. Attach to wall using appropriate hardware Tripod mount. 1/4-20 Bolt Attach to tripod ,tabletop or Shelf Cart/Stand mount.
- Page 3 Assembly Instructions BKT-CT10 Enclosure Once box is mounted , Run cables. Insert Cisco touch 10. reinstall 8-32 nuts x4. Finished unit. www.video-furn.com 288 Don Hillock Drive |Aurora |Ontario|L4G 0G9 | 1.877.834.3876...
