compulocks PK01 Assembly Instructions

Self service kiosk
Hide thumbs
1
2
3

Advertisement

Quick Links

Download this manual
Self Service Kiosk
SKU:PK01
Assembly Instructions
1
Free Standing
2
INSERT PRINTER
PRINTER NOT INCLUDED
©Compulocks Brands Inc. All Rights Reserved
or
0.17in
4.3mm
1.97in
50.0mm
COUNTER MOUNTING PATTERN
3
www.compulocks.com | online@maclocks.com | +1 800-948-0344
Counter Mounting
2.07in
52.5mm
3.44in
87.5mm
CABLE MANAGEMENT
MOUNTING SCREWS
NOT PROVIDED
Sheet 1 of 2
