H3 Group Inc.
TEXZEM /UELEM Series
4
Exit panel for double face
5
Canopy and crossbar
Review the diagrams thoroughly before beginning. If you feel that you do not have enough electrical wiring experience,
please contact a qualified licensed electrician for installation.
Before starting installation, disconnect power by turning off the circuit breaker or by removing the appropriate fuse
at the fuse box. Using a light switch to turn the power off is not sufficient to prevent electrical shock.
All servicing should be performed by qualified personnel only.
H3 Group lnc. 1-800-967 5541
INSTALLATION & OPERATION INSTRUCTIONS
Conversion from double face mirror to single face mirror:
To convert Double Face Mirror to Single Face Mirror, remove protective liner
from adhesive strips supplied on the Mirror film. Center the mirrored film over
the desired unused face and press firmly to adhere.
Remove protective "blue" film from the mirror and faces.
MIRROR FILM
Determine chevron placement:
a. If a chevron is needed,
leave the chevron on and
remove only the film instruction.
b. If no chevron is needed,
remove the chevron and film
instructions together.
STICK MIRROR
FILM TO BACK
SIDE OF PANEL
SINGLE FACE
UNIT ONLY
page 1 of 4
Advertisement
Related Manuals for H3 Group TEXZEM Series
Summary of Contents for H3 Group TEXZEM Series
- Page 1 Determine chevron placement: a. If a chevron is needed, leave the chevron on and remove only the film instruction. b. If no chevron is needed, remove the chevron and film instructions together. H3 Group lnc. 1-800-967 5541 page 1 of 4...
- Page 2 Use a screwdriver to open the from cover to connect the battery connector. Position recessed kits and bar hangers between joists. Make sure the bar hangers are in the correct location. Temporarily position the recessed kits by hammering the "nail-in" tabs on the bar hangers, secure permanently with nails.
- Page 3 The unit can be installed on any flat surface. The EXIT panel can pivot in any angle from 0° to 180°, for wall mounting rotate the panel 90° from the ceiling mounting. Use a screwdriver to open the front cover, then connect the battery.
- Page 4 Battery will require a charge period if product was kept in storage for over 9 months, detail manual refer "BATTERY STOCK AND RECHARGE GUIDELINE". We recommend that the equipment be tested regularly in accordance with local codes. Replace the batteries as needed if discharge time does not achieve the required 90 minutes.
